Volkswagen ID.ERA 9X 1.5 TSI 51.1 kWh (503 Hp) Plug-in Hybrid AWD | Technical specs, data, fuel consumption, Dimensions

Key specs

Volkswagen ID.ERA 9X 1.5 TSI 51.1 kWh (503 Hp) Plug-in Hybrid AWD /SUV 2026 - /

What is the body type of Volkswagen ID.ERA 9X?

SUV, 5 Doors, 6 Seats

What is the fuel consumption and economy of Volkswagen ID.ERA 9X 1.5 TSI 51.1 kWh (503 Hp) Plug-in Hybrid AWD?

0.34-6.27 l/100 km
691.8 - 37.5 US mpg
830.8 - 45.1 UK mpg
294.1 - 15.9 km/l

How environmentally friendly is Volkswagen ID.ERA 9X 1.5 TSI 51.1 kWh (503 Hp) Plug-in Hybrid AWD?

China VI

What is the all-electric range of 1.5 TSI 51.1 kWh (503 Hp) Plug-in Hybrid AWD?

255-347 km
158 - 216 mi

What is the electricity consumption of Volkswagen ID.ERA 9X 1.5 TSI 51.1 kWh (503 Hp) Plug-in Hybrid AWD?

20.9 kWh/100 km
33.64 kWh/100 mi
100 MPGe
4.8 km/kWh
3 mi/kWh

How fast is 2026 ID.ERA 9X 1.5 TSI 51.1 kWh (503 Hp) Plug-in Hybrid AWD?

200 km/h | 124 mph
0-100 km/h: 5.6 sec
0-60 mph: 5.3 sec

What is the power output of Volkswagen ID.ERA 9X SUV 2026 1.5 TSI 51.1 kWh (503 Hp) Plug-in Hybrid AWD?

503 Hp, 660 Nm
487 lb.-ft.

What is the engine displacement of Volkswagen ID.ERA 9X SUV 2026 1.5 TSI 51.1 kWh (503 Hp) Plug-in Hybrid AWD?

1.5 l
1498 cm³
91.41 cu. in.

What is the number of cylinders in 2026 Volkswagen 1.5 TSI 51.1 kWh (503 Hp) Plug-in Hybrid AWD?

4, Inline

What is the drivetrain of Volkswagen ID.ERA 9X SUV 2026 1.5 TSI 51.1 kWh (503 Hp) Plug-in Hybrid AWD?

All wheel drive (4x4). PHEV (Plug-in Hybrid Electric Vehicle). The Internal combustion engine (ICE) drives the generator only, with no mechanical connection to the drive. Two electric motors drive the front and rear wheels.

What is the length of 2026 Volkswagen ID.ERA 9X SUV?

5207 mm
205 in.

What is the width of 2026 Volkswagen ID.ERA 9X SUV?

1997 mm
78.62 in.

What is the kerb weight of 2026 Volkswagen ID.ERA 9X 1.5 TSI 51.1 kWh (503 Hp) Plug-in Hybrid AWD?

2680 kg
5908 lbs.

What is the maximum permissible mass of 2026 Volkswagen ID.ERA 9X 1.5 TSI 51.1 kWh (503 Hp) Plug-in Hybrid AWD?

3165 kg
6978 lbs.

What is the trunk (boot) capacity of 2026 Volkswagen ID.ERA 9X SUV?

210 - 1014 l
7.4 - 35.8 cu. ft.

What is the number of gears in What is the gearbox type of 2026 Volkswagen ID.ERA 9X 1.5 TSI 51.1 kWh (503 Hp) Plug-in Hybrid AWD?

1, automatic transmission

Volkswagen
- Volkswagen ID.ERA 9X
  - ID.ERA 9X
    - 1.5 TSI 65.2 kWh (517 Hp) Plug-in Hybrid AWD
    - 1.5 TSI 51.1 kWh (503 Hp) Plug-in Hybrid AWD

Compare

General information

Brand

Volkswagen

Model

ID.ERA 9X

Generation

ID.ERA 9X

Modification (Engine)

1.5 TSI 51.1 kWh (503 Hp) Plug-in Hybrid AWD

Start of production

March, 2026 year

Powertrain Architecture

PHEV (Plug-in Hybrid Electric Vehicle)

Body type

SUV

Seats

Doors

Looking for Volkswagen ID.ERA 9X on the used-car market?

Check its history →

Performance specs

Fuel consumption (economy) - combined (WLTC)

0.34-6.27 l/100 km 691.8 - 37.5 US mpg
830.8 - 45.1 UK mpg
294.1 - 15.9 km/l

Fuel Type

Petrol / electricity

Acceleration 0 - 100 km/h

5.6 sec

Acceleration 0 - 62 mph

5.6 sec

Acceleration 0 - 60 mph (Calculated by Auto-Data.net)

5.3 sec

Maximum speed

200 km/h 124 mph

Emission standard

China VI

Weight-to-power ratio

5.3 kg/Hp, 187.7 Hp/tonne

Weight-to-torque ratio

4.1 kg/Nm, 246.3 Nm/tonne

Electric cars and hybrids specs

Gross battery capacity

51.1 kWh

Battery voltage

800 V

Battery technology

Lithium iron phosphate (LiFePO₄)

Battery location

Below the floor

Electric range

255-347 km 158 - 216 mi

Average Energy consumption

20.9 kWh/100 km 33.64 kWh/100 mi
100 MPGe
4.8 km/kWh
3 mi/kWh

Charging ports

Electric motor 1

Electric motor power

204 Hp

Electric motor Torque

240 Nm 177 lb.-ft.

Electric motor location

Front axle, Transverse

Electric motor type

Synchronous

Electric motor 2

Electric motor power

299 Hp

Electric motor Torque

420 Nm 310 lb.-ft.

Electric motor model/code

TZ210XS1131

Electric motor location

Rear axle, Transverse

Electric motor type

Synchronous

System power

503 Hp

System torque

660 Nm 487 lb.-ft.

Internal combustion engine specs

Power

143 Hp @ 4500 rpm.

Power per litre

95.5 Hp/l

Torque

240 Nm @ 1750-4000 rpm. 177 lb.-ft. @ 1750-4000 rpm.

Engine layout

Front, Transverse

Engine Model/Code

EA211 / ERV

Engine displacement

1498 cm³ 91.41 cu. in.

Number of cylinders

Engine configuration

Inline

Cylinder Bore

74.5 mm 2.93 in.

Piston Stroke

85.9 mm 3.38 in.

Number of valves per cylinder

Fuel injection system

Direct injection

Engine aspiration

Turbocharger, Intercooler

Valvetrain

DOHC

Engine systems

Start & Stop System

Volume and weights

Kerb Weight

2680 kg 5908 lbs.

Max. weight

3165 kg 6978 lbs.

Max load

485 kg 1069 lbs.

Trunk (boot) space - minimum

210 l 7.4 cu. ft.

Trunk (boot) space - maximum

1014 l 35.8 cu. ft.

Fuel tank capacity

59 l 15.59 US gal | 12.98 UK gal

Dimensions

Length

5207 mm 205 in.

Width

1997 mm 78.62 in.

Height

1810 mm 71.26 in.

Wheelbase

3070 mm 120.87 in.

Front track

1718 mm 67.64 in.

Rear (Back) track

1728 mm 68.03 in.

Ride height (ground clearance)

170 mm 6.69 in.

Drag coefficient (C_d)

0.253

Minimum turning circle (turning diameter)

9.7 m 31.82 ft.

Approach angle

18°

Departure angle

20°

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) drives the generator only, with no mechanical connection to the drive. Two electric motors drive the front and rear wheels.

Drive wheel

All wheel drive (4x4)

Number of gears and type of gearbox

1 gears, automatic transmission

Front suspension

Coil spring, Double wishbone, Anti-roll bar

Rear suspension

Independent multi-link spring suspension with anti-roll bar

Front brakes

Ventilated discs

Rear brakes

Ventilated discs

Assisting systems

ABS (Anti-lock braking system)
4-wheel steering (4WS, active rear steering)

Steering type

Steering rack and pinion

Power steering

Electric Steering

Tires size

255/50 R20

Wheel rims size
