Renault Symbol II 1.6 16V (105 Hp) Automatic | Technical specs, data, fuel consumption, Dimensions

Key specs

Renault Symbol II 1.6 16V (105 Hp) Automatic /Sedan 2008 - 2013/

What is the body type of Renault Symbol II?

Sedan, 4 Doors, 5 Seats

What is the fuel consumption and economy of Renault Symbol II 1.6 16V (105 Hp) Automatic?

7.6 l/100 km
30.9 US mpg
37.2 UK mpg
13.2 km/l

How environmentally friendly is Renault Symbol 1.6 16V (105 Hp) Automatic?

180 g/km CO₂
Euro 4

How fast is 2008 Symbol II 1.6 16V (105 Hp) Automatic?

185 km/h | 115 mph
0-100 km/h: 11.9 sec
0-60 mph: 11.3 sec

What is the power output of Renault Symbol Sedan 2008 1.6 16V (105 Hp) Automatic?

105 Hp, 148 Nm
109 lb.-ft.

What is the engine displacement of Renault Symbol Sedan 2008 1.6 16V (105 Hp) Automatic?

1.6 l
1598 cm³
97.52 cu. in.

What is the number of cylinders in 2008 Renault 1.6 16V (105 Hp) Automatic?

4, Inline

What is the drivetrain of Renault Symbol II Sedan 2008 1.6 16V (105 Hp) Automatic?

Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle.

What is the length of 2008 Renault Symbol Sedan?

4261 mm
167.76 in.

What is the width of 2008 Renault Symbol Sedan?

1940 mm
76.38 in.

What is the kerb weight of 2008 Renault Symbol II 1.6 16V (105 Hp) Automatic?

1039 kg
2291 lbs.

What is the maximum permissible mass of 2008 Renault Symbol II 1.6 16V (105 Hp) Automatic?

1555 kg
3428 lbs.

What is the trunk (boot) capacity of 2008 Renault Symbol Sedan?

506 l
17.9 cu. ft.

What is the number of gears in What is the gearbox type of 2008 Renault Symbol II 1.6 16V (105 Hp) Automatic?

4, automatic transmission

Renault
- Renault Symbol
  - Symbol II
    - 1.6 16V (105 Hp) Automatic
    - 1.6 16V (105 Hp)
    - 1.5 dCi (85 Hp)
    - 1.5 dCi (65 Hp)
    - 1.4 8V (75 Hp)
    - 1.4 16V (98 Hp) Automatic
    - 1.4 16V (98 Hp)
    - 1.2 16V (75 Hp)

Compare

General information

Brand

Renault

Model

Symbol

Generation

Symbol II

Modification (Engine)

1.6 16V (105 Hp) Automatic

Start of production

2008 year

End of production

2013 year

Powertrain Architecture

Internal Combustion engine

Body type

Sedan

Seats

Doors

Looking for Renault Symbol on the used-car market?

Check its history →

Performance specs

Fuel consumption (economy) - urban (NEDC)

10.7 l/100 km 22 US mpg
26.4 UK mpg
9.3 km/l

Fuel consumption (economy) - extra urban (NEDC)

5.9 l/100 km 39.9 US mpg
47.9 UK mpg
16.9 km/l

Fuel consumption (economy) - combined (NEDC)

7.6 l/100 km 30.9 US mpg
37.2 UK mpg
13.2 km/l

CO₂ emissions (NEDC)

180 g/km

Fuel Type

Petrol (Gasoline)

Acceleration 0 - 100 km/h

11.9 sec

Acceleration 0 - 62 mph

11.9 sec

Acceleration 0 - 60 mph (Calculated by Auto-Data.net)

11.3 sec

Maximum speed

185 km/h 115 mph

Emission standard

Euro 4

Weight-to-power ratio

9.9 kg/Hp, 101.1 Hp/tonne

Weight-to-torque ratio

7 kg/Nm, 142.4 Nm/tonne

Engine specs

Power

105 Hp @ 5750 rpm.

Power per litre

65.7 Hp/l

Torque

148 Nm @ 3750 rpm. 109 lb.-ft. @ 3750 rpm.

Engine layout

Front, Transverse

Engine Model/Code

K4M 745

Engine displacement

1598 cm³ 97.52 cu. in.

Number of cylinders

Engine configuration

Inline

Cylinder Bore

79.5 mm 3.13 in.

Piston Stroke

80.5 mm 3.17 in.

Compression ratio

9.8:1

Number of valves per cylinder

Fuel injection system

Multi-port manifold injection

Engine aspiration

Naturally aspirated engine

Valvetrain

DOHC

Engine oil capacity

4.8 l 5.07 US qt | 4.22 UK qt

Engine oil specification

Coolant

5.7 l 6.02 US qt | 5.02 UK qt

Volume and weights

Kerb Weight

1039 kg 2291 lbs.

Max. weight

1555 kg 3428 lbs.

Max load

516 kg 1138 lbs.

Trunk (boot) space - minimum

506 l 17.9 cu. ft.

Fuel tank capacity

50 l 13.21 US gal | 11 UK gal

Permitted trailer load with brakes (12%)

850 kg 1874 lbs.

Permitted trailer load without brakes

555 kg 1224 lbs.

Dimensions

Length

4261 mm 167.76 in.

Width including mirrors

1940 mm 76.38 in.

Height

1439 mm 56.65 in.

Wheelbase

2473 mm 97.36 in.

Front track

1406 mm 55.35 in.

Rear (Back) track

1385 mm 54.53 in.

Front overhang

788 mm 31.02 in.

Rear overhang

1001 mm 39.41 in.

Ride height (ground clearance)

140 mm 5.51 in.

Minimum turning circle (turning diameter)

10.7 m 35.1 ft.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) drives the front wheels of the vehicle.

Drive wheel

Front wheel drive

Number of gears and type of gearbox

4 gears, automatic transmission

Front suspension

Independent, McPherson type with coil spring and anti-roll bar

Rear suspension

Elastic beam

Front brakes

Ventilated discs, 259 mm

Rear brakes

Drum, 203.2 mm

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Hydraulic Steering

Tires size

175/65 R14

Wheel rims size

5.5J x 14

Specs of Renault Symbol II 1.6 16V (105 Hp) Automatic /2008, 2009, 2010, 2011, 2012, 2013/
