NIO EC6 II 75 kWh (490 Hp) 4WD Electric | Technical specs, data, battery, electric range, Dimensions

Key specs

NIO EC6 II 75 kWh (490 Hp) 4WD Electric /Coupe, SUV 2023 - 2025/

What is the body type of NIO EC6 II?

Coupe, SUV, 5 Doors, 5 Seats

What is the all-electric range of 75 kWh (490 Hp) 4WD Electric?

495 km
308 mi

How fast is 2023 EC6 II 75 kWh (490 Hp) 4WD Electric?

200 km/h | 124 mph
0-100 km/h: 4.4 sec
0-60 mph: 4.2 sec

What is the power output of NIO EC6 Coupe, SUV 2023 75 kWh (490 Hp) 4WD Electric?

490 Hp, 700 Nm
516 lb.-ft.

What is the drivetrain of NIO EC6 II Coupe, SUV 2023 75 kWh (490 Hp) 4WD Electric?

All wheel drive (4x4). BEV (Electric Vehicle). One electric motor drives the front wheels, one electric motor drives the rear wheels.

What is the length of 2023 NIO EC6 Coupe, SUV?

4849 mm
190.91 in.

What is the width of 2023 NIO EC6 Coupe, SUV?

1995 mm
78.54 in.

What is the kerb weight of 2023 NIO EC6 II 75 kWh (490 Hp) 4WD Electric?

2292 kg
5053 lbs.

What is the maximum permissible mass of 2023 NIO EC6 II 75 kWh (490 Hp) 4WD Electric?

2826 kg
6230 lbs.

What is the trunk (boot) capacity of 2023 NIO EC6 Coupe, SUV?

505 - 1402 l
17.8 - 49.5 cu. ft.

What is the number of gears in What is the gearbox type of 2023 NIO EC6 II 75 kWh (490 Hp) 4WD Electric?

1, automatic transmission

NIO
- NIO EC6
  - EC6 II
    - 75 kWh (490 Hp) 4WD Electric
    - 100 kWh (490 Hp) 4WD Electric

Compare

General information

Brand

NIO

Model

EC6

Generation

EC6 II

Modification (Engine)

75 kWh (490 Hp) 4WD Electric

Start of production

September, 2023 year

End of production

May, 2025 year

Powertrain Architecture

BEV (Electric Vehicle)

Body type

Coupe, SUV

Seats

Doors

Looking for NIO EC6 on the used-car market?

Check its history →

Performance specs

Fuel Type

Electricity

Acceleration 0 - 100 km/h

4.4 sec

Acceleration 0 - 62 mph

4.4 sec

Acceleration 0 - 60 mph (Calculated by Auto-Data.net)

4.2 sec

Maximum speed

200 km/h 124 mph

Weight-to-power ratio

4.7 kg/Hp, 213.8 Hp/tonne

Weight-to-torque ratio

3.3 kg/Nm, 305.4 Nm/tonne

Electric cars and hybrids specs

Gross battery capacity

75 kWh

Battery technology

Lithium iron phosphate (LiFePO₄)

Battery location

Below the floor

Electric range (CLTC)

495 km 308 mi

Charging ports

Electric motor 1

Electric motor power

204 Hp

Electric motor Torque

280 Nm 207 lb.-ft.

Electric motor location

Front axle, Transverse

Electric motor type

Asynchronous

Electric motor 2

Electric motor power

286 Hp

Electric motor Torque

420 Nm 310 lb.-ft.

Electric motor location

Rear axle, Transverse

Electric motor type

Synchronous

System power

490 Hp

System torque

700 Nm 516 lb.-ft.

Volume and weights

Kerb Weight

2292 kg 5053 lbs.

Max. weight

2826 kg 6230 lbs.

Max load

534 kg 1177 lbs.

Trunk (boot) space - minimum

505 l 17.8 cu. ft.

Trunk (boot) space - maximum

1402 l 49.5 cu. ft.

Dimensions

Length

4849 mm 190.91 in.

Width

1995 mm 78.54 in.

Height

1697 mm 66.81 in.

Wheelbase

2915 mm 114.76 in.

Front track

1711 mm 67.36 in.

Rear (Back) track

1711 mm 67.36 in.

Drag coefficient (C_d)

0.24

Drivetrain, brakes and suspension specs

Drivetrain Architecture

One electric motor drives the front wheels, one electric motor drives the rear wheels.

Drive wheel

All wheel drive (4x4)

Number of gears and type of gearbox

1 gears, automatic transmission

Front suspension

Independent multi-link suspension

Rear suspension

Independent multi-link suspension

Front brakes

Ventilated discs

Rear brakes

Ventilated discs

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Electric Steering

Tires size

255/50 R20

Wheel rims size

Specs of NIO EC6 II 75 kWh (490 Hp) 4WD Electric /2023, 2024, 2025/
