Volvo V50 2.4 i 20V (170 Hp) Automatic | Technical specs, data, fuel consumption, Dimensions

Key specs

Volvo V50 2.4 i 20V (170 Hp) Automatic /Station wagon (estate) 2004 - 2007/

What is the body type of Volvo V50?

Station wagon (estate), 5 Doors, 5 Seats

What is the fuel consumption and economy of Volvo V50 2.4 i 20V (170 Hp) Automatic?

9.2 l/100 km
25.6 US mpg
30.7 UK mpg
10.9 km/l

How environmentally friendly is Volvo V50 2.4 i 20V (170 Hp) Automatic?

220 g/km CO₂

How fast is 2004 V50 2.4 i 20V (170 Hp) Automatic?

215 km/h | 134 mph
0-100 km/h: 9 sec
0-60 mph: 8.6 sec

What is the power output of Volvo V50 Station wagon (estate) 2004 2.4 i 20V (170 Hp) Automatic?

170 Hp, 230 Nm
170 lb.-ft.

What is the engine displacement of Volvo V50 Station wagon (estate) 2004 2.4 i 20V (170 Hp) Automatic?

2.4 l
2435 cm³
148.59 cu. in.

What is the number of cylinders in 2004 Volvo 2.4 i 20V (170 Hp) Automatic?

5, Inline

What is the drivetrain of Volvo V50 Station wagon (estate) 2004 2.4 i 20V (170 Hp) Automatic?

Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle.

What is the length of 2004 Volvo V50 Station wagon (estate)?

4514 mm
177.72 in.

What is the width of 2004 Volvo V50 Station wagon (estate)?

1770 mm
69.69 in.

What is the kerb weight of 2004 Volvo V50 2.4 i 20V (170 Hp) Automatic?

1452 kg
3201 lbs.

What is the trunk (boot) capacity of 2004 Volvo V50 Station wagon (estate)?

417 - 1307 l
14.7 - 46.2 cu. ft.

What are the number of gears and the gearbox type of 2004 Volvo V50 2.4 i 20V (170 Hp) Automatic?

5, automatic transmission

Volvo
- Volvo V50
  - V50
    - 2.5 T5 20V (220 Hp) Automatic
    - 2.5 T5 20V (220 Hp)
    - 2.5 T5 (220 Hp) AWD Automatic
    - 2.5 T5 (220 Hp) AWD
    - 2.4 i 20V (170 Hp) Automatic
    - 2.4 i 20V (170 Hp)
    - 2.4 20V (140 Hp) Automatic
    - 2.4 20V (140 Hp)
    - 2.0 D (136 Hp)
    - 1.8 i 16V (125 Hp)
    - 1.6 i 16V (101 Hp)
    - 1.6 D (110 Hp)

Compare

General information

Brand

Volvo

Model

V50

Generation

V50

Modification (Engine)

2.4 i 20V (170 Hp) Automatic

Start of production

2004

End of production

2007

Powertrain Architecture

Internal Combustion engine

Body type

Station wagon (estate)

Seats

Doors

Looking for Volvo V50 on the used-car market?

Check its history →

Performance specs

Fuel consumption (economy) - combined

9.2 l/100 km 25.6 US mpg
30.7 UK mpg
10.9 km/l

CO₂ emissions

220 g/km

Fuel Type

Petrol (Gasoline)

Acceleration 0 - 100 km/h

9 sec

Acceleration 0 - 62 mph

9 sec

Acceleration 0 - 60 mph (Calculated by Auto-Data.net)

8.6 sec

Maximum speed

215 km/h 134 mph

Weight-to-power ratio

8.5 kg/Hp, 117.1 Hp/tonne

Weight-to-torque ratio

6.3 kg/Nm, 158.4 Nm/tonne

Engine specs

Power

170 Hp @ 5900 rpm.

Power per litre

69.8 Hp/l

Torque

230 Nm @ 4500 rpm. 170 lb.-ft. @ 4500 rpm.

Engine layout

Front, Transverse

Engine Model/Code

B5244S4

Engine displacement

2435 cm³ 148.59 cu. in.

Number of cylinders

Engine configuration

Inline

Cylinder Bore

83 mm 3.27 in.

Piston Stroke

90 mm 3.54 in.

Compression ratio

10.3:1

Number of valves per cylinder

Fuel injection system

Multi-port manifold injection

Engine aspiration

Naturally aspirated engine

Valvetrain

DOHC

Engine oil capacity

5.8 l 6.13 US qt | 5.1 UK qt

Engine oil specification

Coolant

8.5 l 8.98 US qt | 7.48 UK qt

Volume and weights

Kerb Weight

1452 kg 3201 lbs.

Trunk (boot) space - minimum

417 l 14.7 cu. ft.

Trunk (boot) space - maximum

1307 l 46.2 cu. ft.

Fuel tank capacity

62 l 16.38 US gal | 13.64 UK gal

Dimensions

Length

4514 mm 177.72 in.

Width

1770 mm 69.69 in.

Height

1452 mm 57.17 in.

Wheelbase

2640 mm 103.94 in.

Front track

1535 mm 60.43 in.

Rear (Back) track

1531 mm 60.28 in.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) drives the front wheels of the vehicle.

Drive wheel

Front wheel drive

Number of gears and type of gearbox

5 gears, automatic transmission

Front suspension

Anti-roll bar

Rear suspension

Anti-roll bar

Front brakes

Ventilated discs

Rear brakes

Ventilated discs

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Specs of Volvo V50 2.4 i 20V (170 Hp) Automatic /2004, 2005, 2006, 2007/
