McLaren F1 GT 6.1 V12 (627 Hp) | Technical specs, data, fuel consumption, Dimensions

Key specs

McLaren F1 GT 6.1 V12 (627 Hp) /Coupe 1997 - 1997/

What is the body type of McLaren F1?

Coupe, 2 Doors, 3 Seats

What is the power output of McLaren F1 Coupe 1997 GT 6.1 V12 (627 Hp)?

627 Hp, 650 Nm
479 lb.-ft.

What is the engine displacement of McLaren F1 Coupe 1997 GT 6.1 V12 (627 Hp)?

6.1 l
6064 cm³
370.05 cu. in.

What is the number of cylinders in 1997 McLaren GT 6.1 V12 (627 Hp)?

12, V-engine

What is the drivetrain of McLaren F1 Coupe 1997 GT 6.1 V12 (627 Hp)?

Rear wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the rear wheels of the vehicle.

What is the length of 1997 McLaren F1 Coupe?

4928 mm
194.02 in.

What is the width of 1997 McLaren F1 Coupe?

1940 mm
76.38 in.

What is the kerb weight of 1997 McLaren F1 GT 6.1 V12 (627 Hp)?

1120 kg
2469 lbs.

What is the trunk (boot) capacity of 1997 McLaren F1 Coupe?

227 - 283 l
8 - 10 cu. ft.

What are the number of gears and the gearbox type of 1997 McLaren F1 GT 6.1 V12 (627 Hp)?

6, manual transmission

McLaren
- McLaren F1
  - F1
    - GT 6.1 V12 (627 Hp)
    - 6.1 V12 (627 Hp)

Compare

General information

Brand

McLaren

Model

Generation

Modification (Engine)

GT 6.1 V12 (627 Hp)

Start of production

1997

End of production

1997

Powertrain Architecture

Internal Combustion engine

Body type

Coupe

Seats

Doors

Looking for McLaren F1 on the used-car market?

Check its history →

Performance specs

Fuel Type

Petrol (Gasoline)

Weight-to-power ratio

1.8 kg/Hp, 559.8 Hp/tonne

Weight-to-torque ratio

1.7 kg/Nm, 580.4 Nm/tonne

Engine specs

Power

627 Hp @ 7400 rpm.

Power per litre

103.4 Hp/l

Torque

650 Nm @ 5600 rpm. 479 lb.-ft. @ 5600 rpm.

Engine layout

Middle, Longitudinal

Engine Model/Code

BMW S70/2

Engine displacement

6064 cm³ 370.05 cu. in.

Number of cylinders

Engine configuration

V-engine

Cylinder Bore

86 mm 3.39 in.

Piston Stroke

87 mm 3.43 in.

Compression ratio

11:1

Number of valves per cylinder

Fuel injection system

Multi-port manifold injection

Engine aspiration

Naturally aspirated engine

Valvetrain

DOHC

Engine oil capacity

6 l 6.34 US qt | 5.28 UK qt

Engine oil specification

Volume and weights

Kerb Weight

1120 kg 2469 lbs.

Trunk (boot) space - minimum

227 l 8 cu. ft.

Trunk (boot) space - maximum

283 l 10 cu. ft.

Fuel tank capacity

90 l 23.78 US gal | 19.8 UK gal

Dimensions

Length

4928 mm 194.02 in.

Width

1940 mm 76.38 in.

Height

1200 mm 47.24 in.

Wheelbase

2718 mm 107.01 in.

Front track

1620 mm 63.78 in.

Rear (Back) track

1582 mm 62.28 in.

Ride height (ground clearance)

120 mm 4.72 in.

Drag coefficient (C_d)

0.32

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) drives the rear wheels of the vehicle.

Drive wheel

Rear wheel drive

Number of gears and type of gearbox

6 gears, manual transmission

Front suspension

Coil spring, Double wishbone, Anti-roll bar

Rear suspension

Double wishbone, Coil spring

Front brakes

Ventilated discs, 332x32 mm

Rear brakes

Ventilated discs, 305x26 mm

Steering type

Steering rack and pinion

Tire size

Front wheel tires: 235/45 R17
Rear wheel tires: 315/45 R17

Wheel rim size

Front wheel rims: 9J x 17
Rear wheel rims: 11.5J x 17
