McLaren F1 6.1 V12 (627 Hp) | Technical specs, data, fuel consumption, Dimensions

Key specs

McLaren F1 6.1 V12 (627 Hp) /Coupe 1992 - 2000/

What is the body type of McLaren F1?

Coupe, 2 Doors, 3 Seats

How fast is 1992 F1 6.1 V12 (627 Hp)?

386 km/h | 240 mph
0-60 mph: 3.2 sec

What is the power output of McLaren F1 Coupe 1992 6.1 V12 (627 Hp)?

627 Hp, 651 Nm
480 lb.-ft.

What is the engine displacement of McLaren F1 Coupe 1992 6.1 V12 (627 Hp)?

6.1 l
6064 cm³
370.05 cu. in.

What is the number of cylinders in 1992 McLaren 6.1 V12 (627 Hp)?

12, V-engine

What is the drivetrain of McLaren F1 Coupe 1992 6.1 V12 (627 Hp)?

Rear wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the rear wheels of the vehicle.

What is the length of 1992 McLaren F1 Coupe?

4287 mm
168.78 in.

What is the width of 1992 McLaren F1 Coupe?

1820 mm
71.65 in.

What is the kerb weight of 1992 McLaren F1 6.1 V12 (627 Hp)?

1140 kg
2513 lbs.

What is the trunk (boot) capacity of 1992 McLaren F1 Coupe?

227 - 283 l
8 - 10 cu. ft.

What are the number of gears and the gearbox type of 1992 McLaren F1 6.1 V12 (627 Hp)?

6, manual transmission

McLaren
- McLaren F1
  - F1
    - GT 6.1 V12 (627 Hp)
    - 6.1 V12 (627 Hp)

Compare

General information

Brand

McLaren

Model

Generation

Modification (Engine)

6.1 V12 (627 Hp)

Start of production

1992

End of production

2000

Powertrain Architecture

Internal Combustion engine

Body type

Coupe

Seats

Doors

Looking for McLaren F1 on the used-car market?

Check its history →

Performance specs

Fuel Type

Petrol (Gasoline)

Acceleration 0 - 60 mph

3.2 sec

Maximum speed

386 km/h 240 mph

Weight-to-power ratio

1.8 kg/Hp, 550 Hp/tonne

Weight-to-torque ratio

1.8 kg/Nm, 571.1 Nm/tonne

Engine specs

Power

627 Hp @ 7500 rpm.

Power per litre

103.4 Hp/l

Torque

651 Nm @ 5600 rpm. 480 lb.-ft. @ 5600 rpm.

Engine layout

Middle, Longitudinal

Engine Model/Code

S70/2

Engine displacement

6064 cm³ 370.05 cu. in.

Number of cylinders

Engine configuration

V-engine

Cylinder Bore

86 mm 3.39 in.

Piston Stroke

87 mm 3.43 in.

Compression ratio

11:1

Number of valves per cylinder

Fuel injection system

Multi-port manifold injection

Engine aspiration

Naturally aspirated engine

Valvetrain

DOHC

Engine oil capacity

6 l 6.34 US qt | 5.28 UK qt

Engine oil specification

Volume and weights

Kerb Weight

1140 kg 2513 lbs.

Trunk (boot) space - minimum

227 l 8 cu. ft.

Trunk (boot) space - maximum

283 l 10 cu. ft.

Fuel tank capacity

90 l 23.78 US gal | 19.8 UK gal

Dimensions

Length

4287 mm 168.78 in.

Width

1820 mm 71.65 in.

Height

1140 mm 44.88 in.

Wheelbase

2718 mm 107.01 in.

Front track

1568 mm 61.73 in.

Rear (Back) track

1472 mm 57.95 in.

Front overhang

970 mm 38.19 in.

Rear overhang

599 mm 23.58 in.

Ride height (ground clearance)

120 mm 4.72 in.

Drag coefficient (C_d)

0.32

Minimum turning circle (turning diameter)

13 m 42.65 ft.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) drives the rear wheels of the vehicle.

Drive wheel

Rear wheel drive

Number of gears and type of gearbox

6 gears, manual transmission

Front suspension

Coil spring, Double wishbone, Anti-roll bar

Rear suspension

Double wishbone, Coil spring

Front brakes

Ventilated discs, 332x32 mm

Rear brakes

Ventilated discs, 305x26 mm

Steering type

Steering rack and pinion

Tire size

Front wheel tires: 235/45 ZR17
Rear wheel tires: 315/45 ZR17

Wheel rim size

Front wheel rims: 9J x 17
Rear wheel rims: 11.5J x 17

Specs of McLaren F1 6.1 V12 (627 Hp) /1992, 1993, 1994, 1995, 1996, 1997, 1998, 1999, 2000/
