Hyundai Tucson IV 1.6 T-GDi (265 Hp) Plug-in Hybrid 4WD Automatic | Technical specs, data, fuel consumption, Dimensions

Key specs

Hyundai Tucson IV 1.6 T-GDi (265 Hp) Plug-in Hybrid 4WD Automatic /SUV (Sport Utility Vehicle) 2021 - 2024/

What is the body type of Hyundai Tucson IV?

SUV (Sport Utility Vehicle), 5 Doors, 5 Seats

What is the fuel consumption and economy of Hyundai Tucson IV 1.6 T-GDi (265 Hp) Plug-in Hybrid 4WD Automatic?

1.4 l/100 km
168 US mpg
201.8 UK mpg
71.4 km/l

How environmentally friendly is Hyundai Tucson 1.6 T-GDi (265 Hp) Plug-in Hybrid 4WD Automatic?

31 g/km CO₂
Euro 6d

What is the all-electric range of 1.6 T-GDi (265 Hp) Plug-in Hybrid 4WD Automatic?

62 km
39 mi

What is the electricity consumption of Hyundai Tucson IV 1.6 T-GDi (265 Hp) Plug-in Hybrid 4WD Automatic?

17.7 kWh/100 km
28.49 kWh/100 mi
118 MPGe
5.6 km/kWh
3.5 mi/kWh

How fast is 2021 Tucson IV 1.6 T-GDi (265 Hp) Plug-in Hybrid 4WD Automatic?

191 km/h | 119 mph
0-100 km/h: 8.2 sec
0-60 mph: 7.8 sec

What is the power output of Hyundai Tucson SUV (Sport Utility Vehicle) 2021 1.6 T-GDi (265 Hp) Plug-in Hybrid 4WD Automatic?

265 Hp, 350 Nm
258 lb.-ft.

What is the engine displacement of Hyundai Tucson SUV (Sport Utility Vehicle) 2021 1.6 T-GDi (265 Hp) Plug-in Hybrid 4WD Automatic?

1.6 l
1598 cm³
97.52 cu. in.

What is the number of cylinders in 2021 Hyundai 1.6 T-GDi (265 Hp) Plug-in Hybrid 4WD Automatic?

4, Inline

What is the drivetrain of Hyundai Tucson IV SUV (Sport Utility Vehicle) 2021 1.6 T-GDi (265 Hp) Plug-in Hybrid 4WD Automatic?

All wheel drive (4x4). PHEV (Plug-in Hybrid Electric Vehicle). The Internal combustion engine (ICE) and the electric motor permanently drive the front wheels of the vehicle, capable of running in full electric or mixed mode, and if necessary through the electrically or mechanically controlled clutch, the rear wheels are driven.

What is the length of 2021 Hyundai Tucson SUV (Sport Utility Vehicle)?

4500 mm
177.17 in.

What is the width of 2021 Hyundai Tucson SUV (Sport Utility Vehicle)?

1865 mm
73.43 in.

What is the kerb weight of 2021 Hyundai Tucson IV 1.6 T-GDi (265 Hp) Plug-in Hybrid 4WD Automatic?

1818-1924 kg
4008 - 4242 lbs.

What is the maximum permissible mass of 2021 Hyundai Tucson IV 1.6 T-GDi (265 Hp) Plug-in Hybrid 4WD Automatic?

2415 kg
5324 lbs.

What is the trunk (boot) capacity of 2021 Hyundai Tucson SUV (Sport Utility Vehicle)?

558 - 1721 l
19.7 - 60.8 cu. ft.

What are the number of gears and the gearbox type of 2021 Hyundai Tucson IV 1.6 T-GDi (265 Hp) Plug-in Hybrid 4WD Automatic?

6, automatic transmission

Compare

General information

Brand

Hyundai

Model

Tucson

Generation

Tucson IV

Modification (Engine)

1.6 T-GDi (265 Hp) Plug-in Hybrid 4WD Automatic

Start of production

May, 2021

End of production

May, 2024

Powertrain Architecture

PHEV (Plug-in Hybrid Electric Vehicle)

Body type

SUV (Sport Utility Vehicle)

Seats

Doors

Looking for Hyundai Tucson on the used-car market?

Check its history →

Performance specs

Combined fuel consumption (WLTP)

1.4 l/100 km 168 US mpg
201.8 UK mpg
71.4 km/l

CO₂ emissions (WLTP)

31 g/km

Fuel Type

Petrol / electricity

Acceleration 0 - 100 km/h

8.2 sec

Acceleration 0 - 62 mph

8.2 sec

Acceleration 0 - 60 mph (Calculated by Auto-Data.net)

7.8 sec

Maximum speed

191 km/h 119 mph

Emission standard

Euro 6d

Weight-to-power ratio

6.9 kg/Hp, 145.8 Hp/tonne

Weight-to-torque ratio

5.2 kg/Nm, 192.5 Nm/tonne

Electric and hybrid car specs

Gross battery capacity

13.8 kWh

Battery voltage

360 V

Battery technology

Lithium-polymer (LiPo)

Battery location

Below the floor, under the front seats

Electric range (WLTP)

62 km 39 mi

Average Energy consumption (WLTP)

17.7 kWh/100 km 28.49 kWh/100 mi
118 MPGe
5.6 km/kWh
3.5 mi/kWh

Charging ports

Charging times

Electric motor 1

Electric motor power

91 Hp @ 2100-3300 rpm.

Electric motor Torque

304 Nm @ 1500-4500 rpm. 224 lb.-ft. @ 1500-4500 rpm.

Electric motor location

Between the combustion engine and the transmission

System power

265 Hp @ 5500 rpm.

System torque

350 Nm @ 1500-4500 rpm. 258 lb.-ft. @ 1500-4500 rpm.

Internal combustion engine specs

Power

180 Hp @ 5500 rpm.

Power per litre

112.6 Hp/l

Torque

265 Nm @ 1500-4500 rpm. 195 lb.-ft. @ 1500-4500 rpm.

Engine layout

Front, Transverse

Engine Model/Code

G4FP

Engine displacement

1598 cm³ 97.52 cu. in.

Number of cylinders

Engine configuration

Inline

Cylinder Bore

75.6 mm 2.98 in.

Piston Stroke

89 mm 3.5 in.

Compression ratio

10.5:1

Number of valves per cylinder

Fuel injection system

Direct injection

Engine aspiration

Turbocharger, Intercooler

Valvetrain

DOHC

Engine oil capacity

4.8 l 5.07 US qt | 4.22 UK qt

Engine oil specification

Coolant

6.8 l 7.19 US qt | 5.98 UK qt

Engine systems

Start & Stop System
Particulate filter

Volume and weights

Kerb Weight

1818-1924 kg 4008 - 4242 lbs.

Max. weight

2415 kg 5324 lbs.

Max load

491-597 kg 1082 - 1316 lbs.

Trunk (boot) space - minimum

558 l 19.7 cu. ft.

Trunk (boot) space - maximum

1721 l 60.8 cu. ft.

Fuel tank capacity

42 l 11.1 US gal | 9.24 UK gal

Max. roof load

100 kg 220 lbs.

Permitted trailer load with brakes (12%)

1350 kg 2976 lbs.

Permitted trailer load without brakes

750 kg 1653 lbs.

Permitted towbar download

100 kg 220 lbs.

Dimensions

Length

4500 mm 177.17 in.

Width

1865 mm 73.43 in.

Height

1650 mm 64.96 in.

Wheelbase

2680 mm 105.51 in.

Front track

1615 mm 63.58 in.

Rear (Back) track

1622 mm 63.86 in.

Ride height (ground clearance)

170 mm 6.69 in.

Minimum turning circle (turning diameter)

10.9 m 35.76 ft.

Approach angle

17.4°

Departure angle

25.7°

Ramp-over (breakover) angle

15.6°

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) and the electric motor permanently drive the front wheels of the vehicle, capable of running in full electric or mixed mode, and if necessary through the electrically or mechanically controlled clutch, the rear wheels are driven.

Drive wheel

All wheel drive (4x4)

Number of gears and type of gearbox

6 gears, automatic transmission

Front suspension

Independent, McPherson type

Rear suspension

Independent multi-link suspension

Front brakes

Ventilated discs

Rear brakes

Disc

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Electric Steering

Tire size

235/50 R19

Wheel rim size

7.5J x 19

Specs of Hyundai Tucson IV 1.6 T-GDi (265 Hp) Plug-in Hybrid 4WD Automatic /2021, 2022, 2023, 2024/
