Hyundai Tucson IV 1.6 T-GDI (230 Hp) HEV Automatic | Technical specs, data, fuel consumption, Dimensions

Key specs

Hyundai Tucson IV 1.6 T-GDI (230 Hp) HEV Automatic /SUV 2020 - 2024/

What is the body type of Hyundai Tucson IV?

SUV, 5 Doors, 5 Seats

What is the fuel consumption and economy of Hyundai Tucson IV 1.6 T-GDI (230 Hp) HEV Automatic?

5.6-5.7 l/100 km
42 - 41.3 US mpg
50.4 - 49.6 UK mpg
17.9 - 17.5 km/l

How environmentally friendly is Hyundai Tucson 1.6 T-GDI (230 Hp) HEV Automatic?

127-131 g/km CO₂
Euro 6d

How fast is 2020 Tucson IV 1.6 T-GDI (230 Hp) HEV Automatic?

193 km/h | 120 mph
0-100 km/h: 8.0 sec
0-60 mph: 7.6 sec

What is the power output of Hyundai Tucson SUV 2020 1.6 T-GDI (230 Hp) HEV Automatic?

230 Hp, 265 Nm
195 lb.-ft.

What is the engine displacement of Hyundai Tucson SUV 2020 1.6 T-GDI (230 Hp) HEV Automatic?

1.6 l
1598 cm³
97.52 cu. in.

What is the number of cylinders in 2020 Hyundai 1.6 T-GDI (230 Hp) HEV Automatic?

4, Inline

What is the drivetrain of Hyundai Tucson IV SUV 2020 1.6 T-GDI (230 Hp) HEV Automatic?

Front wheel drive. FHEV (Full Hybrid Electric Vehicle). The Internal combustion engine (ICE) and electric motor drive the front wheels of the car with the ability to work in full electric or mixed mode.

What is the length of 2020 Hyundai Tucson SUV?

4500 mm
177.17 in.

What is the width of 2020 Hyundai Tucson SUV?

1865 mm
73.43 in.

What is the kerb weight of 2020 Hyundai Tucson IV 1.6 T-GDI (230 Hp) HEV Automatic?

1564-1685 kg
3448 - 3715 lbs.

What is the maximum permissible mass of 2020 Hyundai Tucson IV 1.6 T-GDI (230 Hp) HEV Automatic?

2175 kg
4795 lbs.

What is the trunk (boot) capacity of 2020 Hyundai Tucson SUV?

616 - 1795 l
21.8 - 63.4 cu. ft.

What is the number of gears in What is the gearbox type of 2020 Hyundai Tucson IV 1.6 T-GDI (230 Hp) HEV Automatic?

6, automatic transmission

Compare

General information

Brand

Hyundai

Model

Tucson

Generation

Tucson IV

Modification (Engine)

1.6 T-GDI (230 Hp) HEV Automatic

Start of production

December, 2020 year

End of production

May, 2024 year

Powertrain Architecture

FHEV (Full Hybrid Electric Vehicle)

Body type

SUV

Seats

Doors

Looking for Hyundai Tucson on the used-car market?

Check its history →

Performance specs

Fuel consumption at Low speed (WLTP)

5.7-5.9 l/100 km 41.3 - 39.9 US mpg
49.6 - 47.9 UK mpg
17.5 - 16.9 km/l

Fuel consumption at Medium speed (WLTP)

4.7-4.8 l/100 km 50 - 49 US mpg
60.1 - 58.9 UK mpg
21.3 - 20.8 km/l

Fuel consumption at high speed (WLTP)

4.8-4.9 l/100 km 49 - 48 US mpg
58.9 - 57.6 UK mpg
20.8 - 20.4 km/l

Fuel consumption at very high speed (WLTP)

6.7-7 l/100 km 35.1 - 33.6 US mpg
42.2 - 40.4 UK mpg
14.9 - 14.3 km/l

Combined fuel consumption (WLTP)

5.6-5.7 l/100 km 42 - 41.3 US mpg
50.4 - 49.6 UK mpg
17.9 - 17.5 km/l

CO₂ emissions (WLTP)

127-131 g/km

Fuel consumption (economy) - urban (NEDC, WLTP equivalent)

5.3 l/100 km 44.4 US mpg
53.3 UK mpg
18.9 km/l

Fuel consumption (economy) - extra urban (NEDC, WLTP equivalent)

4.7 l/100 km 50 US mpg
60.1 UK mpg
21.3 km/l

Fuel consumption (economy) - combined (NEDC, WLTP equivalent)

4.9 l/100 km 48 US mpg
57.6 UK mpg
20.4 km/l

CO₂ emissions (NEDC, WLTP equivalent)

112 g/km

Fuel Type

Petrol (Gasoline)

Acceleration 0 - 100 km/h

8.0 sec

Acceleration 0 - 62 mph

8.0 sec

Acceleration 0 - 60 mph (Calculated by Auto-Data.net)

7.6 sec

Maximum speed

193 km/h 120 mph

Emission standard

Euro 6d

Weight-to-power ratio

6.8 kg/Hp, 147.1 Hp/tonne

Weight-to-torque ratio

5.9 kg/Nm, 169.4 Nm/tonne

Electric cars and hybrids specs

Gross battery capacity

1.49 kWh

Battery voltage

270 V

Battery technology

Lithium-polymer (LiPo)

Electric motor 1

Electric motor power

60 Hp

Electric motor Torque

264 Nm @ 1600 rpm. 195 lb.-ft. @ 1600 rpm.

Electric motor type

Synchronous

System power

230 Hp @ 5500 rpm.

Internal combustion engine specs

Power

180 Hp @ 5500 rpm.

Power per litre

112.6 Hp/l

Torque

265 Nm @ 1500-4500 rpm. 195 lb.-ft. @ 1500-4500 rpm.

Engine layout

Front, Transverse

Engine Model/Code

G4FT

Engine displacement

1598 cm³ 97.52 cu. in.

Number of cylinders

Engine configuration

Inline

Cylinder Bore

75.6 mm 2.98 in.

Piston Stroke

89 mm 3.5 in.

Compression ratio

10.5:1

Number of valves per cylinder

Fuel injection system

Direct injection

Engine aspiration

Twin Turbo, Intercooler

Valvetrain

DOHC

Engine oil capacity

4.8 l 5.07 US qt | 4.22 UK qt

Engine oil specification

Coolant

7.8 l 8.24 US qt | 6.86 UK qt

Engine systems

Start & Stop System
Particulate filter

Volume and weights

Kerb Weight

1564-1685 kg 3448 - 3715 lbs.

Max. weight

2175 kg 4795 lbs.

Max load

490-611 kg 1080 - 1347 lbs.

Trunk (boot) space - minimum

616 l 21.8 cu. ft.

Trunk (boot) space - maximum

1795 l 63.4 cu. ft.

Fuel tank capacity

52 l 13.74 US gal | 11.44 UK gal

Max. roof load

100 kg 220 lbs.

Permitted trailer load with brakes (12%)

1650 kg 3638 lbs.

Permitted trailer load without brakes

750 kg 1653 lbs.

Permitted towbar download

100 kg 220 lbs.

Dimensions

Length

4500 mm 177.17 in.

Width

1865 mm 73.43 in.

Width including mirrors

2130 mm 83.86 in.

Height

1651 mm 65 in.

Wheelbase

2680 mm 105.51 in.

Front track

1615-1630 mm 63.58 - 64.17 in.

Rear (Back) track

1622-1637 mm 63.86 - 64.45 in.

Front overhang

895 mm 35.24 in.

Rear overhang

925 mm 36.42 in.

Ride height (ground clearance)

170 mm 6.69 in.

Drag coefficient (C_d)

0.315

Minimum turning circle (turning diameter)

10.92 m 35.83 ft.

Approach angle

17.4°

Departure angle

25.7°

Ramp-over (brakeover) angle

17.3°

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) and electric motor drive the front wheels of the car with the ability to work in full electric or mixed mode.

Drive wheel

Front wheel drive

Number of gears and type of gearbox

6 gears, automatic transmission

Front suspension

Independent, McPherson type with coil spring and anti-roll bar

Rear suspension

Independent multi-link spring suspension with anti-roll bar

Front brakes

Ventilated discs, 291 mm

Rear brakes

Disc, 302 mm

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Electric Steering

Tires size

215/65 R17; 235/50 R19

Wheel rims size

7.0J x 17; 7.5J x 19

Specs of Hyundai Tucson IV 1.6 T-GDI (230 Hp) HEV Automatic /2020, 2021, 2022, 2023, 2024/
