Honda Pilot IV 3.5 V6 (285 Hp) AWD Automatic | Technical Specs, Fuel consumption, Dimensions

Key specs

Honda Pilot IV 3.5 V6 (285 Hp) AWD Automatic /SUV, Crossover 2022 - 2025/

What is the body type of Honda Pilot IV?

SUV, Crossover, 5 Doors, 8 Seats

What is the fuel consumption and economy of Honda Pilot IV 3.5 V6 (285 Hp) AWD Automatic?

11.0-11.2 l/100 km
21.4 - 21 US mpg
25.7 - 25.2 UK mpg
9.1 - 8.9 km/l

How environmentally friendly is Honda Pilot 3.5 V6 (285 Hp) AWD Automatic?

Tier 3 Bin 30

What is the power output of Honda Pilot SUV, Crossover 2022 3.5 V6 (285 Hp) AWD Automatic?

285 Hp, 355 Nm
262 lb.-ft.

What is the engine displacement of Honda Pilot SUV, Crossover 2022 3.5 V6 (285 Hp) AWD Automatic?

3.5 l
3471 cm³
211.81 cu. in.

What is the number of cylinders in 2022 Honda 3.5 V6 (285 Hp) AWD Automatic?

6, V-engine

What is the drivetrain of Honda Pilot IV SUV, Crossover 2022 3.5 V6 (285 Hp) AWD Automatic?

All wheel drive (4x4). ICE. The Internal combustion engine (ICE) drives the front wheels permanently, and the rear wheels are driven through an electrically or mechanically operated clutch if necessary.

What is the length of 2022 Honda Pilot SUV, Crossover?

5077 mm
199.88 in.

What is the width of 2022 Honda Pilot SUV, Crossover?

2090 mm
82.28 in.

What is the kerb weight of 2022 Honda Pilot IV 3.5 V6 (285 Hp) AWD Automatic?

2051-2118 kg
4522 - 4669 lbs.

What is the maximum permissible mass of 2022 Honda Pilot IV 3.5 V6 (285 Hp) AWD Automatic?

2810 kg
6195 lbs.

What is the trunk (boot) capacity of 2022 Honda Pilot SUV, Crossover?

635 - 3183 l
22.4 - 112.4 cu. ft.

What are the number of gears and the gearbox type of 2022 Honda Pilot IV 3.5 V6 (285 Hp) AWD Automatic?

10, automatic transmission

Honda Pilot IV 3.5 V6 (285 Hp) AWD Automatic

Honda
- Honda Pilot
  - Pilot IV
    - TrailSport 3.5 V6 (285 Hp) AWD Automatic
    - 3.5 V6 (285 Hp) AWD Automatic
    - 3.5 V6 (285 Hp) Automatic

Compare

General information

Brand

Honda

Model

Pilot

Generation

Pilot IV

Modification (Engine)

3.5 V6 (285 Hp) AWD Automatic

Start of production

December, 2022

End of production

December, 2025

Powertrain Architecture

Internal Combustion engine

Body type

SUV (Sport Utility Vehicle), Crossover

Seats

Doors

Looking for Honda Pilot on the used-car market?

Check its history →

Performance specs

Fuel consumption (economy) - urban

12.4-12.7 l/100 km 19 - 18.5 US mpg
22.8 - 22.2 UK mpg
8.1 - 7.9 km/l

Fuel consumption (economy) - extra urban

9.3-9.4 l/100 km 25.3 - 25 US mpg
30.4 - 30.1 UK mpg
10.8 - 10.6 km/l

Fuel consumption (economy) - combined

11.0-11.2 l/100 km 21.4 - 21 US mpg
25.7 - 25.2 UK mpg
9.1 - 8.9 km/l

Fuel Type

Petrol (Gasoline)

Emission standard

Tier 3 Bin 30

Weight-to-power ratio

7.2 kg/Hp, 139 Hp/tonne

Weight-to-torque ratio

5.8 kg/Nm, 173.1 Nm/tonne

Engine specs

Power

285 Hp @ 6100 rpm.

Power per litre

82.1 Hp/l

Torque

355 Nm @ 5000 rpm. 262 lb.-ft. @ 5000 rpm.

Engine layout

Front, Longitudinal

Engine Model/Code

J35Y8

Engine displacement

3471 cm³ 211.81 cu. in.

Number of cylinders

Engine configuration

V-engine

Cylinder Bore

89 mm 3.5 in.

Piston Stroke

93 mm 3.66 in.

Compression ratio

11.5:1

Number of valves per cylinder

Fuel injection system

Direct injection

Engine aspiration

Naturally aspirated engine

Valvetrain

DOHC, i-VTEC

Engine oil capacity

5.5 l 5.81 US qt | 4.84 UK qt

Engine oil specification

Coolant

7.67 l 8.1 US qt | 6.75 UK qt

Engine systems

Start & Stop System

Volume and weights

Kerb Weight

2051-2118 kg 4522 - 4669 lbs.

Max. weight

2810 kg 6195 lbs.

Max load

692-759 kg 1526 - 1673 lbs.

Trunk (boot) space - minimum

635 l 22.4 cu. ft.

Trunk (boot) space - maximum

3183 l 112.4 cu. ft.

Fuel tank capacity

70 l 18.49 US gal | 15.4 UK gal

Permitted trailer load with brakes (12%)

2268 kg 5000 lbs.

Dimensions

Length

5077 mm 199.88 in.

Width with mirrors folded

2090 mm 82.28 in.

Width including mirrors

2254 mm 88.74 in.

Height

1801-1803 mm 70.91 - 70.98 in.

Wheelbase

2891 mm 113.82 in.

Front track

1715 mm 67.52 in.

Rear (Back) track

1722 mm 67.8 in.

Ride height (ground clearance)

185 mm 7.28 in.

Minimum turning circle (turning diameter)

11.52 m 37.8 ft.

Approach angle

18.3°

Departure angle

20.3-21.1°

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) drives the front wheels permanently, and the rear wheels are driven through an electrically or mechanically operated clutch if necessary.

Drive wheel

All wheel drive (4x4)

Number of gears and type of gearbox

10 gears, automatic transmission

Front suspension

Independent, McPherson type with coil spring and anti-roll bar

Rear suspension

Independent multi-link spring suspension with anti-roll bar

Front brakes

Ventilated discs

Rear brakes

Disc

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Electric Steering

Tire size

255/60 R18 108H; 255/50 R20 105H

Wheel rim size

18; 20
