Aion RT 55.1 kWh (204 Hp) | Technical specs, data, battery, electric range, Dimensions

Key specs

Aion RT 55.1 kWh (204 Hp) /Sedan 2024 - /

What is the body type of Aion RT?

Sedan, 4 Doors, 5 Seats

What is the all-electric range of 55.1 kWh (204 Hp)?

520 km
323 mi

What is the electricity consumption of Aion RT 55.1 kWh (204 Hp)?

11.7 kWh/100 km
18.83 kWh/100 mi
179 MPGe
8.5 km/kWh
5.3 mi/kWh

How fast is 2024 RT 55.1 kWh (204 Hp)?

163 km/h | 101 mph
0-100 km/h: 7.5 sec
0-60 mph: 7.1 sec

What is the power output of Aion RT Sedan 2024 55.1 kWh (204 Hp)?

204 Hp, 240 Nm
177 lb.-ft.

What is the drivetrain of Aion RT Sedan 2024 55.1 kWh (204 Hp)?

Front wheel drive. BEV (Electric Vehicle). One electric motor drives the front wheels.

What is the length of 2024 Aion RT Sedan?

4865 mm
191.54 in.

What is the width of 2024 Aion RT Sedan?

1875 mm
73.82 in.

What is the kerb weight of 2024 Aion RT 55.1 kWh (204 Hp)?

1670-1700 kg
3682 - 3748 lbs.

What is the maximum permissible mass of 2024 Aion RT 55.1 kWh (204 Hp)?

2120 kg
4674 lbs.

What is the trunk (boot) capacity of 2024 Aion RT Sedan?

540 l
19.1 cu. ft.

What are the number of gears and the gearbox type of 2024 Aion RT 55.1 kWh (204 Hp)?

1, automatic transmission

Aion
- Aion RT
  - RT
    - 68.1 kWh (224 Hp)
    - 55.1 kWh (204 Hp)

Compare

General information

Brand

Aion

Model

Generation

Modification (Engine)

55.1 kWh (204 Hp)

Start of production

November, 2024

Powertrain Architecture

BEV (Electric Vehicle)

Body type

Sedan

Seats

Doors

Looking for Aion RT on the used-car market?

Check its history →

Performance specs

Fuel Type

Electricity

Acceleration 0 - 100 km/h

7.5 sec

Acceleration 0 - 62 mph

7.5 sec

Acceleration 0 - 60 mph (Calculated by Auto-Data.net)

7.1 sec

Maximum speed

163 km/h 101 mph

Weight-to-power ratio

8.2 kg/Hp, 122.2 Hp/tonne

Weight-to-torque ratio

7 kg/Nm, 143.7 Nm/tonne

Electric and hybrid car specs

Gross battery capacity

55.1 kWh

Battery technology

Lithium iron phosphate (LiFePO₄)

Battery location

Below the floor

Electric range (CLTC)

520 km 323 mi

Average Energy consumption (CLTC)

11.7 kWh/100 km 18.83 kWh/100 mi
179 MPGe
8.5 km/kWh
5.3 mi/kWh

Charging ports

Electric motor 1

Electric motor power

204 Hp

Electric motor Torque

240 Nm 177 lb.-ft.

Electric motor model/code

TZ180XYXOF51

Electric motor location

Front axle, Transverse

Electric motor type

Synchronous

System power

204 Hp

System torque

240 Nm 177 lb.-ft.

Volume and weights

Kerb Weight

1670-1700 kg 3682 - 3748 lbs.

Max. weight

2120 kg 4674 lbs.

Max load

420-450 kg 926 - 992 lbs.

Trunk (boot) space - minimum

540 l 19.1 cu. ft.

Dimensions

Length

4865 mm 191.54 in.

Width

1875 mm 73.82 in.

Height

1520 mm 59.84 in.

Wheelbase

2775 mm 109.25 in.

Front track

1602 mm 63.07 in.

Rear (Back) track

1606 mm 63.23 in.

Approach angle

14°

Departure angle

17°

Drivetrain, brakes and suspension specs

Drivetrain Architecture

One electric motor drives the front wheels.

Drive wheel

Front wheel drive

Number of gears and type of gearbox

1 gears, automatic transmission

Front suspension

Independent, McPherson type with coil spring and anti-roll bar

Rear suspension

Semi-independent, coil spring, Torsion bar

Front brakes

Ventilated discs

Rear brakes

Disc

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Electric Steering

Tire size

215/55 R17; 235/45 R18

Wheel rim size

17; 18

Specs of Aion RT 55.1 kWh (204 Hp) /2024, 2025, 2026/
