Acura CSX 2.0 i 16V (157 Hp) | Technical specs, data, fuel consumption, Dimensions

Key specs

Acura CSX 2.0 i 16V (157 Hp) /Sedan 2005 - 2008/

What is the body type of Acura CSX?

Sedan, 4 Doors, 5 Seats

How environmentally friendly is Acura CSX 2.0 i 16V (157 Hp)?

Euro 4

What is the power output of Acura CSX Sedan 2005 2.0 i 16V (157 Hp)?

157 Hp, 188 Nm
139 lb.-ft.

What is the engine displacement of Acura CSX Sedan 2005 2.0 i 16V (157 Hp)?

2.0 l
1998 cm³
121.93 cu. in.

What is the number of cylinders in 2005 Acura 2.0 i 16V (157 Hp)?

4, Inline

What is the drivetrain of Acura CSX Sedan 2005 2.0 i 16V (157 Hp)?

Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle.

What is the length of 2005 Acura CSX Sedan?

4544 mm
178.9 in.

What is the width of 2005 Acura CSX Sedan?

1752 mm
68.98 in.

What is the kerb weight of 2005 Acura CSX 2.0 i 16V (157 Hp)?

1290 kg
2844 lbs.

What is the trunk (boot) capacity of 2005 Acura CSX Sedan?

340 l
12 cu. ft.

What is the number of gears in What is the gearbox type of 2005 Acura CSX 2.0 i 16V (157 Hp)?

5, manual transmission

Acura
- Acura CSX
  - CSX
    - 2.0 i 16V (157 Hp)

Compare

General information

Brand

Acura

Model

CSX

Generation

CSX

Modification (Engine)

2.0 i 16V (157 Hp)

Start of production

2005 year

End of production

2008 year

Powertrain Architecture

Internal Combustion engine

Body type

Sedan

Seats

Doors

Looking for Acura CSX on the used-car market?

Check its history →

Performance specs

Fuel consumption (economy) - urban

8.4 l/100 km 28 US mpg
33.6 UK mpg
11.9 km/l

Fuel consumption (economy) - extra urban

6.4 l/100 km 36.8 US mpg
44.1 UK mpg
15.6 km/l

Fuel Type

Petrol (Gasoline)

Emission standard

Euro 4

Weight-to-power ratio

8.2 kg/Hp, 121.7 Hp/tonne

Weight-to-torque ratio

6.9 kg/Nm, 145.7 Nm/tonne

Engine specs

Power

157 Hp @ 6000 rpm.

Power per litre

78.6 Hp/l

Torque

188 Nm @ 4500 rpm. 139 lb.-ft. @ 4500 rpm.

Engine layout

Front, Transverse

Engine Model/Code

K20Z2

Engine displacement

1998 cm³ 121.93 cu. in.

Number of cylinders

Engine configuration

Inline

Cylinder Bore

86 mm 3.39 in.

Piston Stroke

86 mm 3.39 in.

Compression ratio

9.6:1

Number of valves per cylinder

Fuel injection system

Multi-port manifold injection

Engine aspiration

Naturally aspirated engine

Valvetrain

DOHC

Engine oil capacity

4.2 l 4.44 US qt | 3.7 UK qt

Engine oil specification

Coolant

6.5 l 6.87 US qt | 5.72 UK qt

Volume and weights

Kerb Weight

1290 kg 2844 lbs.

Trunk (boot) space - maximum

340 l 12 cu. ft.

Fuel tank capacity

50 l 13.21 US gal | 11 UK gal

Dimensions

Length

4544 mm 178.9 in.

Width

1752 mm 68.98 in.

Height

1435 mm 56.5 in.

Wheelbase

2700 mm 106.3 in.

Front track

1499 mm 59.02 in.

Rear (Back) track

1528 mm 60.16 in.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) drives the front wheels of the vehicle.

Drive wheel

Front wheel drive

Number of gears and type of gearbox

5 gears, manual transmission

Front suspension

Independent, McPherson type with coil spring and anti-roll bar

Rear suspension

Independent multi-link spring suspension with anti-roll bar

Front brakes

Disc

Rear brakes

Disc

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Tires size

205/55R16

Specs of Acura CSX 2.0 i 16V (157 Hp) /2005, 2006, 2007, 2008/
