VW-Porsche 914 1.7 (80 Hp) | Technical specs, data, fuel consumption, Dimensions

Key specs

VW-Porsche 914 1.7 (80 Hp) /Roadster 1969 - 1973/

What is the body type of VW-Porsche 914?

Roadster, 2 Doors, 2 Seats

What is the fuel consumption and economy of VW-Porsche 914 1.7 (80 Hp)?

8 l/100 km
29.4 US mpg
35.3 UK mpg
12.5 km/l

How fast is 1969 914 1.7 (80 Hp)?

177 km/h | 110 mph
0-100 km/h: 13 sec
0-60 mph: 12.4 sec

What is the power output of VW-Porsche 914 Roadster 1969 1.7 (80 Hp)?

80 Hp, 133 Nm
98 lb.-ft.

What is the engine displacement of VW-Porsche 914 Roadster 1969 1.7 (80 Hp)?

1.7 l
1679 cm³
102.46 cu. in.

What is the number of cylinders in 1969 VW-Porsche 1.7 (80 Hp)?

4, Boxer

What is the drivetrain of VW-Porsche 914 Roadster 1969 1.7 (80 Hp)?

Rear wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the rear wheels of the vehicle.

What is the length of 1969 VW-Porsche 914 Roadster?

3985 mm
156.89 in.

What is the width of 1969 VW-Porsche 914 Roadster?

1650 mm
64.96 in.

What is the kerb weight of 1969 VW-Porsche 914 1.7 (80 Hp)?

900 kg
1984 lbs.

What is the maximum permissible mass of 1969 VW-Porsche 914 1.7 (80 Hp)?

1220 kg
2690 lbs.

What are the number of gears and the gearbox type of 1969 VW-Porsche 914 1.7 (80 Hp)?

5, manual transmission

VW-Porsche
- VW-Porsche 914
  - 914
    - 2.0 (110 Hp)
    - 2.0 (100 Hp)
    - 1.8 (86 Hp)
    - 1.7 (80 Hp)

Compare

General information

Brand

VW-Porsche

Model

914

Generation

914

Modification (Engine)

1.7 (80 Hp)

Start of production

1969

End of production

1973

Powertrain Architecture

Internal Combustion engine

Body type

Roadster

Seats

Doors

Looking for VW-Porsche 914 on the used-car market?

Check its history →

Performance specs

Fuel consumption (economy) - combined

8 l/100 km 29.4 US mpg
35.3 UK mpg
12.5 km/l

Fuel Type

Petrol (Gasoline)

Acceleration 0 - 100 km/h

13 sec

Acceleration 0 - 62 mph

13 sec

Acceleration 0 - 60 mph (Calculated by Auto-Data.net)

12.4 sec

Maximum speed

177 km/h 110 mph

Weight-to-power ratio

11.3 kg/Hp, 88.9 Hp/tonne

Weight-to-torque ratio

6.8 kg/Nm, 147.8 Nm/tonne

Engine specs

Power

80 Hp @ 4900 rpm.

Power per litre

47.6 Hp/l

Torque

133 Nm @ 2700 rpm. 98 lb.-ft. @ 2700 rpm.

Engine layout

Middle, Longitudinal

Engine Model/Code

022

Engine displacement

1679 cm³ 102.46 cu. in.

Number of cylinders

Engine configuration

Boxer

Cylinder Bore

90 mm 3.54 in.

Piston Stroke

66 mm 2.6 in.

Compression ratio

8.2:1

Fuel injection system

Multi-port manifold injection

Engine aspiration

Naturally aspirated engine

Engine oil capacity

3.5 l 3.7 US qt | 3.08 UK qt

Engine oil specification

Volume and weights

Kerb Weight

900 kg 1984 lbs.

Max. weight

1220 kg 2690 lbs.

Max load

320 kg 705 lbs.

Fuel tank capacity

62 l 16.38 US gal | 13.64 UK gal

Dimensions

Length

3985 mm 156.89 in.

Width

1650 mm 64.96 in.

Height

1230 mm 48.43 in.

Wheelbase

2450 mm 96.46 in.

Front track

1337 mm 52.64 in.

Rear (Back) track

1374 mm 54.09 in.

Ride height (ground clearance)

120 mm 4.72 in.

Minimum turning circle (turning diameter)

11 m 36.09 ft.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) drives the rear wheels of the vehicle.

Drive wheel

Rear wheel drive

Number of gears and type of gearbox

5 gears, manual transmission

Front suspension

Suspension strut, Wishbone

Rear suspension

Trailing arm, Coil spring

Front brakes

Ventilated discs, 281 mm

Rear brakes

Disc, 282 mm

Steering type

Steering rack and pinion

Wheel rim size

4.5J x 15

Specs of VW-Porsche 914 1.7 (80 Hp) /1969, 1970, 1971, 1972, 1973/
