Voyah Passion 82 kWh (510 Hp) 4WD Electric | Technical specs, data, battery, electric range, Dimensions

Key specs

Voyah Passion 82 kWh (510 Hp) 4WD Electric /Sedan 2022 - /

What is the body type of Voyah Passion?

Sedan, 4 Doors, 5 Seats

What is the all-electric range of 82 kWh (510 Hp) 4WD Electric?

580 km
360 mi

What is the electricity consumption of Voyah Passion 82 kWh (510 Hp) 4WD Electric?

15.6 kWh/100 km
25.11 kWh/100 mi
134 MPGe
6.4 km/kWh
4 mi/kWh

How fast is 2022 Passion 82 kWh (510 Hp) 4WD Electric?

210 km/h | 130 mph

What is the power output of Voyah Passion Sedan 2022 82 kWh (510 Hp) 4WD Electric?

510 Hp, 730 Nm
538 lb.-ft.

What is the drivetrain of Voyah Passion Sedan 2022 82 kWh (510 Hp) 4WD Electric?

All wheel drive (4x4). BEV (Electric Vehicle). One electric motor drives the front wheels, one electric motor drives the rear wheels.

What is the length of 2022 Voyah Passion Sedan?

5088 mm
200.31 in.

What is the width of 2022 Voyah Passion Sedan?

1970 mm
77.56 in.

What is the kerb weight of 2022 Voyah Passion 82 kWh (510 Hp) 4WD Electric?

2266 kg
4996 lbs.

What is the maximum permissible mass of 2022 Voyah Passion 82 kWh (510 Hp) 4WD Electric?

2641 kg
5822 lbs.

What is the number of gears in What is the gearbox type of 2022 Voyah Passion 82 kWh (510 Hp) 4WD Electric?

1, automatic transmission

Voyah
- Voyah Passion
  - Passion
    - 82 kWh (510 Hp) 4WD Electric
    - 109 kWh (510 Hp) 4WD Electric
    - 1.5 TD (530 Hp) Plug-in Hybrid 4WD

Compare

General information

Brand

Voyah

Model

Passion

Generation

Passion

Modification (Engine)

82 kWh (510 Hp) 4WD Electric

Start of production

December, 2022 year

Powertrain Architecture

BEV (Electric Vehicle)

Body type

Sedan

Seats

Doors

Looking for Voyah Passion on the used-car market?

Check its history →

Performance specs

Fuel Type

Electricity

Maximum speed

210 km/h 130 mph

Weight-to-power ratio

4.4 kg/Hp, 225.1 Hp/tonne

Weight-to-torque ratio

3.1 kg/Nm, 322.2 Nm/tonne

Electric cars and hybrids specs

Gross battery capacity

82 kWh

Battery technology

Lithium-ion (Li-Ion)

Battery location

Below the floor

Electric range

580 km 360 mi

Average Energy consumption

15.6 kWh/100 km 25.11 kWh/100 mi
134 MPGe
6.4 km/kWh
4 mi/kWh

Charging ports

Electric motor 1

Electric motor power

292 Hp

Electric motor Torque

420 Nm 310 lb.-ft.

Electric motor location

Rear axle, Transverse

Electric motor type

Synchronous

Electric motor 2

Electric motor power

218 Hp

Electric motor Torque

310 Nm 229 lb.-ft.

Electric motor location

Front axle, Transverse

Electric motor type

Synchronous

System power

510 Hp

System torque

730 Nm 538 lb.-ft.

Volume and weights

Kerb Weight

2266 kg 4996 lbs.

Max. weight

2641 kg 5822 lbs.

Max load

375 kg 827 lbs.

Dimensions

Length

5088 mm 200.31 in.

Width

1970 mm 77.56 in.

Height

1515 mm 59.65 in.

Wheelbase

3000 mm 118.11 in.

Front track

1691 mm 66.57 in.

Rear (Back) track

1699 mm 66.89 in.

Drag coefficient (C_d)

0.22

Drivetrain, brakes and suspension specs

Drivetrain Architecture

One electric motor drives the front wheels, one electric motor drives the rear wheels.

Drive wheel

All wheel drive (4x4)

Number of gears and type of gearbox

1 gears, automatic transmission

Front suspension

Double wishbone

Rear suspension

Independent multi-link suspension

Front brakes

Ventilated discs

Rear brakes

Ventilated discs

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Electric Steering

Tires size

245/45 R20

Wheel rims size

Specs of Voyah Passion 82 kWh (510 Hp) 4WD Electric /2022, 2023, 2024, 2025, 2026/
