Volvo 480 E 1.7 (109 Hp) | Technical Specs, Fuel consumption, Dimensions

Key specs

Volvo 480 E 1.7 (109 Hp) /Coupe 1986 - 1988/

What is the body type of Volvo 480 E?

Coupe, 2 Doors, 4 Seats

What is the fuel consumption and economy of Volvo 480 E 1.7 (109 Hp)?

7.3 l/100 km
32.2 US mpg
38.7 UK mpg
13.7 km/l

How fast is 1986 480 E 1.7 (109 Hp)?

190 km/h | 118 mph
0-100 km/h: 10 sec
0-60 mph: 9.5 sec

What is the power output of Volvo 480 E Coupe 1986 1.7 (109 Hp)?

109 Hp, 145 Nm
107 lb.-ft.

What is the engine displacement of Volvo 480 E Coupe 1986 1.7 (109 Hp)?

1.7 l
1721 cm³
105.02 cu. in.

What is the number of cylinders in 1986 Volvo 1.7 (109 Hp)?

4, Inline

What is the drivetrain of Volvo 480 E Coupe 1986 1.7 (109 Hp)?

Front wheel drive. ICE. The Internal combustion engine (ICE) drives the front wheels of the vehicle.

What is the length of 1986 Volvo 480 E Coupe?

4258 mm
167.64 in.

What is the width of 1986 Volvo 480 E Coupe?

1710 mm
67.32 in.

What is the kerb weight of 1986 Volvo 480 E 1.7 (109 Hp)?

1030 kg
2271 lbs.

What is the maximum permissible mass of 1986 Volvo 480 E 1.7 (109 Hp)?

1410 kg
3109 lbs.

What is the trunk (boot) capacity of 1986 Volvo 480 E Coupe?

160 - 660 l
5.7 - 23.3 cu. ft.

What are the number of gears and the gearbox type of 1986 Volvo 480 E 1.7 (109 Hp)?

5, manual transmission

Volvo 480 E 1.7 (109 Hp)

Volvo
- Volvo 480 E
  - 480 E
    - 2.0 (110 Hp) Automatic
    - 2.0 (110 Hp)
    - 2.0 (109 Hp)
    - 1.7 Turbo (122 Hp)
    - 1.7 Turbo (120 Hp)
    - 1.7 (95 Hp)
    - 1.7 (109 Hp)
    - 1.7 (102 Hp)

Compare

General information

Brand

Volvo

Model

480 E

Generation

480 E

Modification (Engine)

1.7 (109 Hp)

Start of production

1986

End of production

1988

Powertrain Architecture

Internal Combustion engine

Body type

Coupe

Seats

Doors

Looking for Volvo 480 E on the used-car market?

Check its history →

Performance specs

Fuel consumption (economy) - urban

10.6 l/100 km 22.2 US mpg
26.6 UK mpg
9.4 km/l

Fuel consumption (economy) - extra urban

5.9 l/100 km 39.9 US mpg
47.9 UK mpg
16.9 km/l

Fuel consumption (economy) - combined

7.3 l/100 km 32.2 US mpg
38.7 UK mpg
13.7 km/l

Fuel Type

Petrol (Gasoline)

Acceleration 0 - 100 km/h

10 sec

Acceleration 0 - 62 mph

10 sec

Acceleration 0 - 60 mph (Calculated by Auto-Data.net)

9.5 sec

Maximum speed

190 km/h 118 mph

Weight-to-power ratio

9.4 kg/Hp, 105.8 Hp/tonne

Weight-to-torque ratio

7.1 kg/Nm, 140.8 Nm/tonne

Engine specs

Power

109 Hp @ 5800 rpm.

Power per litre

63.3 Hp/l

Torque

145 Nm @ 4500 rpm. 107 lb.-ft. @ 4500 rpm.

Engine layout

Front, Transverse

Engine Model/Code

B18E

Engine displacement

1721 cm³ 105.02 cu. in.

Number of cylinders

Engine configuration

Inline

Cylinder Bore

81 mm 3.19 in.

Piston Stroke

83.5 mm 3.29 in.

Compression ratio

10.1:1

Number of valves per cylinder

Fuel injection system

Multi-port manifold injection

Engine aspiration

Naturally aspirated engine

Valvetrain

OHC

Engine oil capacity

5.3 l 5.6 US qt | 4.66 UK qt

Engine oil specification

Coolant

7 l 7.4 US qt | 6.16 UK qt

Volume and weights

Kerb Weight

1030 kg 2271 lbs.

Max. weight

1410 kg 3109 lbs.

Max load

380 kg 838 lbs.

Trunk (boot) space - minimum

160 l 5.7 cu. ft.

Trunk (boot) space - maximum

660 l 23.3 cu. ft.

Fuel tank capacity

60 l 15.85 US gal | 13.2 UK gal

Dimensions

Length

4258 mm 167.64 in.

Width

1710 mm 67.32 in.

Height

1323 mm 52.09 in.

Wheelbase

2503 mm 98.54 in.

Front track

1416 mm 55.75 in.

Rear (Back) track

1426 mm 56.14 in.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) drives the front wheels of the vehicle.

Drive wheel

Front wheel drive

Number of gears and type of gearbox

5 gears, manual transmission

Front suspension

Wishbone

Rear suspension

Coil spring

Front brakes

Disc

Rear brakes

Disc

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Hydraulic Steering

Tire size

185/60 R14

Wheel rim size
