Volkswagen Tera 1.0 TSI (109 Hp) Tiptronic | Technical specs, data, fuel consumption, Dimensions

Key specs

Volkswagen Tera 1.0 TSI (109 Hp) Tiptronic /SUV 2025 - /

What is the body type of Volkswagen Tera?

SUV, 5 Doors, 5 Seats

How fast is 2025 Tera 1.0 TSI (109 Hp) Tiptronic?

180 km/h | 112 mph
0-100 km/h: 11.8 sec
0-60 mph: 11.2 sec

What is the power output of Volkswagen Tera SUV 2025 1.0 TSI (109 Hp) Tiptronic?

109 Hp, 170 Nm
125 lb.-ft.

What is the engine displacement of Volkswagen Tera SUV 2025 1.0 TSI (109 Hp) Tiptronic?

1.0 l
999 cm³
60.96 cu. in.

What is the number of cylinders in 2025 Volkswagen 1.0 TSI (109 Hp) Tiptronic?

3, Inline

What is the drivetrain of Volkswagen Tera SUV 2025 1.0 TSI (109 Hp) Tiptronic?

Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle.

What is the length of 2025 Volkswagen Tera SUV?

4151 mm
163.43 in.

What is the width of 2025 Volkswagen Tera SUV?

1777 mm
69.96 in.

What is the trunk (boot) capacity of 2025 Volkswagen Tera SUV?

350 l
12.4 cu. ft.

What are the number of gears and the gearbox type of 2025 Volkswagen Tera 1.0 TSI (109 Hp) Tiptronic?

6, automatic transmission Tiptronic

Volkswagen
- Volkswagen Tera
  - Tera
    - 1.6 MSI (110 Hp)
    - 1.0 TSI (109/116 Hp) TOTALFLEX Tiptronic
    - 1.0 TSI (109/116 Hp) TOTALFLEX
    - 1.0 TSI (109 Hp) Tiptronic
    - 1.0 MPI (77/84 Hp) TOTALFLEX

Compare

General information

Brand

Volkswagen

Model

Tera

Generation

Tera

Modification (Engine)

1.0 TSI (109 Hp) Tiptronic

Start of production

2025

Powertrain Architecture

Internal Combustion engine

Body type

SUV

Seats

Doors

Looking for Volkswagen Tera on the used-car market?

Check its history →

Performance specs

Fuel Type

Petrol (Gasoline)

Acceleration 0 - 100 km/h

11.8 sec

Acceleration 0 - 62 mph

11.8 sec

Acceleration 0 - 60 mph (Calculated by Auto-Data.net)

11.2 sec

Maximum speed

180 km/h 112 mph

Engine specs

Power

109 Hp @ 5000 rpm.

Power per litre

109.1 Hp/l

Torque

170 Nm @ 1750-4250 rpm. 125 lb.-ft. @ 1750-4250 rpm.

Engine layout

Front, Transverse

Engine displacement

999 cm³ 60.96 cu. in.

Number of cylinders

Engine configuration

Inline

Number of valves per cylinder

Fuel injection system

Direct injection

Engine aspiration

Turbocharger, Intercooler

Valvetrain

DOHC

Engine oil capacity

4 l 4.23 US qt | 3.52 UK qt

Engine oil specification

Engine systems

Start & Stop System

Volume and weights

Trunk (boot) space - minimum

350 l 12.4 cu. ft.

Fuel tank capacity

52 l 13.74 US gal | 11.44 UK gal

Max. roof load

50 kg 110 lbs.

Dimensions

Length

4151 mm 163.43 in.

Width

1777 mm 69.96 in.

Width including mirrors

1986 mm 78.19 in.

Height

1504 mm 59.21 in.

Wheelbase

2566 mm 101.02 in.

Front track

1532-1534 mm 60.31 - 60.39 in.

Rear (Back) track

1516-1517 mm 59.69 - 59.72 in.

Minimum turning circle (turning diameter)

10.8 m 35.43 ft.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) drives the front wheels of the vehicle.

Drive wheel

Front wheel drive

Number of gears and type of gearbox

6 gears, automatic transmission Tiptronic

Front suspension

Independent, McPherson type with coil spring and anti-roll bar

Rear suspension

Semi-independent, coil spring, Trailing arm

Front brakes

Ventilated discs

Rear brakes

Disc

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Electric Steering

Tire size

205/60 R16; 205/55 R17

Wheel rim size

6J x 16; 6.5J x 17

Specs of Volkswagen Tera 1.0 TSI (109 Hp) Tiptronic /2025, 2026/
