| What is the body type, Volkswagen Passat Variant (B5)? | Station wagon (estate), 5 Doors, 5 Seats |
|---|---|
| How fast is the car, 1997 Passat Variant (B5) 1.8 T 20V (150 Hp) Automatic? | 211 km/h | 131.11 mph 0-100 km/h: 10.3 sec 0-60 mph: 9.8 sec |
| How much power, Volkswagen Passat Station wagon (estate) 1997 1.8 T 20V (150 Hp) Automatic? | 150 Hp, 210 Nm 154.89 lb.-ft. |
| What is the engine size, Volkswagen Passat Station wagon (estate) 1997 1.8 T 20V (150 Hp) Automatic? | 1.8 l 1781 cm3 108.68 cu. in. |
| How many cylinders, 1997 Volkswagen 1.8 T 20V (150 Hp) Automatic? | 4, Inline |
| What is the drivetrain, Volkswagen Passat Variant (B5) Station wagon (estate) 1997 1.8 T 20V (150 Hp) Automatic? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 1997 Volkswagen Passat Station wagon (estate)? | 4675 mm 184.06 in. |
| How wide is the vehicle, 1997 Volkswagen Passat Station wagon (estate)? | 1740 mm 68.5 in. |
| What is the curb weight, 1997 Volkswagen Passat Variant (B5) 1.8 T 20V (150 Hp) Automatic? | 1385 kg 3053.4 lbs. |
| What is the gross weight, 1997 Volkswagen Passat Variant (B5) 1.8 T 20V (150 Hp) Automatic? | 1960 kg 4321.06 lbs. |
| How much trunk (boot) space, 1997 Volkswagen Passat Station wagon (estate)? | 495 - 1600 l 17.48 - 56.5 cu. ft. |
| How many gears, What type is the gearbox, 1997 Volkswagen Passat Variant (B5) 1.8 T 20V (150 Hp) Automatic? | 4, automatic transmission |
| General information | |
|---|---|
| Brand | Volkswagen |
| Model | Passat |
| Generation | Passat Variant (B5) |
| Modification (Engine) | 1.8 T 20V (150 Hp) Automatic |
| Start of production | 1997 year |
| End of production | 2000 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Station wagon (estate) |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) - urban | 13.3 l/100 km
17.7 US mpg 21.2 UK mpg 7.5 km/l |
| Fuel consumption (economy) - extra urban | 7.1 l/100 km
33.1 US mpg 39.8 UK mpg 14.1 km/l |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 - 100 km/h | 10.3 sec |
| Acceleration 0 - 62 mph | 10.3 sec |
| Acceleration 0 - 60 mph (Calculated by Auto-Data.net) | 9.8 sec |
| Maximum speed | 211 km/h 131.11 mph |
| Weight-to-power ratio | 9.2 kg/Hp, 108.3 Hp/tonne |
| Weight-to-torque ratio | 6.6 kg/Nm, 151.6 Nm/tonne |
| Engine specs | |
| Power | 150 Hp @ 5700 rpm. |
| Power per litre | 84.2 Hp/l |
| Torque | 210 Nm @ 1750 rpm. 154.89 lb.-ft. @ 1750 rpm. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | AEB, ANB, APU, ATW, AUG, AWT, BGC |
| Engine displacement | 1781 cm3 108.68 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 81 mm 3.19 in. |
| Piston Stroke | 86.4 mm 3.4 in. |
| Compression ratio | 9.5:1 |
| Number of valves per cylinder | 5 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Turbocharger |
| Valvetrain | DOHC |
| Engine oil capacity | 3.5 l 3.7 US qt | 3.08 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 7 l 7.4 US qt | 6.16 UK qt |
| Space, Volume and weights | |
| Kerb Weight | 1385 kg 3053.4 lbs. |
| Max. weight | 1960 kg 4321.06 lbs. |
| Max load | 575 kg 1267.66 lbs. |
| Trunk (boot) space - minimum | 495 l 17.48 cu. ft. |
| Trunk (boot) space - maximum | 1600 l 56.5 cu. ft. |
| Fuel tank capacity | 62 l 16.38 US gal | 13.64 UK gal |
| Dimensions | |
| Length | 4675 mm 184.06 in. |
| Width | 1740 mm 68.5 in. |
| Height | 1459 mm 57.44 in. |
| Wheelbase | 2703 mm 106.42 in. |
| Front track | 1498 mm 58.98 in. |
| Rear (Back) track | 1500 mm 59.06 in. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 4 gears, automatic transmission |
| Front suspension | Coil spring |
| Rear suspension | Coil spring |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Hydraulic Steering |
| Tires size | 195/65 R15 |
| Wheel rims size | 6J x 15 |
