Tank 500 2.0T (346 Hp) Hybrid 4WD Automatic | Technical specs, data, fuel consumption, Dimensions

Key specs

Tank 500 2.0T (346 Hp) Hybrid 4WD Automatic /SUV (Sport Utility Vehicle) 2023 - /

What is the body type of Tank 500?

SUV (Sport Utility Vehicle), 5 Doors, 7 Seats

What is the fuel consumption and economy of Tank 500 2.0T (346 Hp) Hybrid 4WD Automatic?

8.5 l/100 km
27.7 US mpg
33.2 UK mpg
11.8 km/l

How environmentally friendly is Tank 500 2.0T (346 Hp) Hybrid 4WD Automatic?

199 g/km CO₂
Euro 5

How fast is 2023 500 2.0T (346 Hp) Hybrid 4WD Automatic?

0-100 km/h: 8.3 sec
0-60 mph: 7.9 sec

What is the power output of Tank 500 SUV (Sport Utility Vehicle) 2023 2.0T (346 Hp) Hybrid 4WD Automatic?

346 Hp, 648 Nm
478 lb.-ft.

What is the engine displacement of Tank 500 SUV (Sport Utility Vehicle) 2023 2.0T (346 Hp) Hybrid 4WD Automatic?

2.0 l
1998 cm³
121.93 cu. in.

What is the number of cylinders in 2023 Tank 2.0T (346 Hp) Hybrid 4WD Automatic?

4, Inline

What is the drivetrain of Tank 500 SUV (Sport Utility Vehicle) 2023 2.0T (346 Hp) Hybrid 4WD Automatic?

All wheel drive (4x4). FHEV (Full Hybrid Electric Vehicle). The Internal combustion engine (ICE) and the electric motor permanently drive the rear wheels of the vehicle, capable of running in full electric or mixed mode, and if necessary through the electrically or mechanically controlled clutch, the front wheels are driven.

What is the length of 2023 Tank 500 SUV (Sport Utility Vehicle)?

5078 mm
199.92 in.

What is the width of 2023 Tank 500 SUV (Sport Utility Vehicle)?

1934 mm
76.14 in.

What is the kerb weight of 2023 Tank 500 2.0T (346 Hp) Hybrid 4WD Automatic?

2605 kg
5743 lbs.

What is the maximum permissible mass of 2023 Tank 500 2.0T (346 Hp) Hybrid 4WD Automatic?

3395 kg
7485 lbs.

What is the trunk (boot) capacity of 2023 Tank 500 SUV (Sport Utility Vehicle)?

98 - 1489 l
3.5 - 52.6 cu. ft.

What are the number of gears and the gearbox type of 2023 Tank 500 2.0T (346 Hp) Hybrid 4WD Automatic?

9, automatic transmission

Tank
- Tank 500
  - 500

Compare

General information

Brand

Tank

Model

500

Generation

500

Modification (Engine)

2.0T (346 Hp) Hybrid 4WD Automatic

Start of production

September, 2023

Powertrain Architecture

FHEV (Full Hybrid Electric Vehicle)

Body type

SUV (Sport Utility Vehicle)

Seats

Doors

Looking for Tank 500 on the used-car market?

Check its history →

Performance specs

Fuel consumption (economy) - combined

8.5 l/100 km 27.7 US mpg
33.2 UK mpg
11.8 km/l

CO₂ emissions

199 g/km

Fuel Type

Petrol (Gasoline)

Acceleration 0 - 100 km/h

8.3 sec

Acceleration 0 - 62 mph

8.3 sec

Acceleration 0 - 60 mph (Calculated by Auto-Data.net)

7.9 sec

Emission standard

Euro 5

Weight-to-power ratio

7.5 kg/Hp, 132.8 Hp/tonne

Weight-to-torque ratio

4 kg/Nm, 248.8 Nm/tonne

Electric and hybrid car specs

Battery technology

Lithium-ion (Li-Ion)

Electric motor 1

Electric motor power

106 Hp

Electric motor Torque

268 Nm 198 lb.-ft.

Electric motor location

Between the combustion engine and the transmission

Electric motor type

Synchronous

System power

346 Hp

System torque

648 Nm 478 lb.-ft.

Internal combustion engine specs

Power

244 Hp @ 5500-6000 rpm.

Power per litre

122.1 Hp/l

Torque

380 Nm @ 1700-4000 rpm. 280 lb.-ft. @ 1700-4000 rpm.

Engine layout

Front, Longitudinal

Engine displacement

1998 cm³ 121.93 cu. in.

Number of cylinders

Engine configuration

Inline

Cylinder Bore

82 mm 3.23 in.

Piston Stroke

94.6 mm 3.72 in.

Compression ratio

11:1

Number of valves per cylinder

Fuel injection system

Direct injection

Engine aspiration

Turbocharger, Intercooler

Valvetrain

DOHC

Engine oil capacity

5.9 l 6.23 US qt | 5.19 UK qt

Engine oil specification

Engine systems

Start & Stop System

Volume and weights

Kerb Weight

2605 kg 5743 lbs.

Max. weight

3395 kg 7485 lbs.

Max load

790 kg 1742 lbs.

Trunk (boot) space - minimum

98 l 3.5 cu. ft.

Trunk (boot) space - maximum

1489 l 52.6 cu. ft.

Fuel tank capacity

75 l 19.81 US gal | 16.5 UK gal

Permitted trailer load with brakes (12%)

3000 kg 6614 lbs.

Permitted trailer load without brakes

750 kg 1653 lbs.

Dimensions

Length

5078 mm 199.92 in.

Width

1934 mm 76.14 in.

Height

1905 mm 75 in.

Wheelbase

2850 mm 112.2 in.

Front track

1635 mm 64.37 in.

Rear (Back) track

1635 mm 64.37 in.

Ride height (ground clearance)

224 mm 8.82 in.

Minimum turning circle (turning diameter)

11.2 m 36.75 ft.

Approach angle

30°

Departure angle

24°

Ramp-over (breakover) angle

22.5°

Climb angle

36.9°

Wading depth

800 mm 31.5 in.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) and the electric motor permanently drive the rear wheels of the vehicle, capable of running in full electric or mixed mode, and if necessary through the electrically or mechanically controlled clutch, the front wheels are driven.

Drive wheel

All wheel drive (4x4)

Number of gears and type of gearbox

9 gears, automatic transmission

Front suspension

Double wishbone, Independent coil spring, Anti-roll bar

Rear suspension

Rigid axle suspension, Anti-roll bar, Coil spring

Front brakes

Ventilated discs

Rear brakes

Ventilated discs

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Electric Steering

Tire size

265/60 R18; 265/50 R20

Wheel rim size

8J x 18; 8.5J x 20
