Suzuki XL6 1.5 (105 Hp) Mild Hybrid | Technical specs, data, fuel consumption, Dimensions

Key specs

Suzuki XL6 1.5 (105 Hp) Mild Hybrid /SUV, Crossover 2019 - 2022/

What is the body type of Suzuki XL6?

SUV, Crossover, 5 Doors, 6 Seats

What is the fuel consumption and economy of Suzuki XL6 1.5 (105 Hp) Mild Hybrid?

5.3 l/100 km
44.4 US mpg
53.3 UK mpg
18.9 km/l

How environmentally friendly is Suzuki XL6 1.5 (105 Hp) Mild Hybrid?

BS VI

What is the power output of Suzuki XL6 SUV, Crossover 2019 1.5 (105 Hp) Mild Hybrid?

105 Hp, 138 Nm
102 lb.-ft.

What is the engine displacement of Suzuki XL6 SUV, Crossover 2019 1.5 (105 Hp) Mild Hybrid?

1.5 l
1462 cm³
89.22 cu. in.

What is the number of cylinders in 2019 Suzuki 1.5 (105 Hp) Mild Hybrid?

4, Inline

What is the drivetrain of Suzuki XL6 SUV, Crossover 2019 1.5 (105 Hp) Mild Hybrid?

Front wheel drive. MHEV (Mild Hybrid Electric Vehicle, power-assist hybrid, battery-assisted hybrid vehicles, BAHV). The Internal combustion engine (ICE) and electric motor drive the front wheels of the car with the ability to work only in mixed mode.

What is the length of 2019 Suzuki XL6 SUV, Crossover?

4445 mm
175 in.

What is the width of 2019 Suzuki XL6 SUV, Crossover?

1775 mm
69.88 in.

What is the kerb weight of 2019 Suzuki XL6 1.5 (105 Hp) Mild Hybrid?

1180 kg
2601 lbs.

What is the maximum permissible mass of 2019 Suzuki XL6 1.5 (105 Hp) Mild Hybrid?

1730 kg
3814 lbs.

What is the trunk (boot) capacity of 2019 Suzuki XL6 SUV, Crossover?

209 - 692 l
7.4 - 24.4 cu. ft.

What are the number of gears and the gearbox type of 2019 Suzuki XL6 1.5 (105 Hp) Mild Hybrid?

5, manual transmission

Suzuki
- Suzuki XL6
  - XL6
    - 1.5 (105 Hp) Mild Hybrid Automatic
    - 1.5 (105 Hp) Mild Hybrid

Compare

General information

Brand

Suzuki

Model

XL6

Generation

XL6

Modification (Engine)

1.5 (105 Hp) Mild Hybrid

Start of production

August, 2019

End of production

April, 2022

Powertrain Architecture

MHEV (Mild Hybrid Electric Vehicle, power-assist hybrid, battery-assisted hybrid vehicles, BAHV)

Body type

SUV, Crossover

Seats

Doors

Looking for Suzuki XL6 on the used-car market?

Check its history →

Performance specs

Fuel consumption (economy) - combined

5.3 l/100 km 44.4 US mpg
53.3 UK mpg
18.9 km/l

Fuel Type

Petrol (Gasoline)

Emission standard

BS VI

Weight-to-power ratio

11.2 kg/Hp, 89 Hp/tonne

Weight-to-torque ratio

8.6 kg/Nm, 116.9 Nm/tonne

Electric and hybrid car specs

Battery technology

Lithium-ion (Li-Ion)

Electric motor 1

Electric motor location

Integrated into the transmission

Internal combustion engine specs

Power

105 Hp @ 6000 rpm.

Power per litre

71.8 Hp/l

Torque

138 Nm @ 4400 rpm. 102 lb.-ft. @ 4400 rpm.

Engine layout

Front, Transverse

Engine Model/Code

K15B

Engine displacement

1462 cm³ 89.22 cu. in.

Number of cylinders

Engine configuration

Inline

Cylinder Bore

74 mm 2.91 in.

Piston Stroke

85 mm 3.35 in.

Compression ratio

10.5:1

Number of valves per cylinder

Fuel injection system

Multi-port manifold injection

Engine aspiration

Naturally aspirated engine

Engine oil capacity

3.1 l 3.28 US qt | 2.73 UK qt

Engine oil specification

Coolant

4 l 4.23 US qt | 3.52 UK qt

Engine systems

Start & Stop System

Volume and weights

Kerb Weight

1180 kg 2601 lbs.

Max. weight

1730 kg 3814 lbs.

Max load

550 kg 1213 lbs.

Trunk (boot) space - minimum

209 l 7.4 cu. ft.

Trunk (boot) space - maximum

692 l 24.4 cu. ft.

Fuel tank capacity

45 l 11.89 US gal | 9.9 UK gal

Dimensions

Length

4445 mm 175 in.

Width

1775 mm 69.88 in.

Height

1700 mm 66.93 in.

Wheelbase

2740 mm 107.87 in.

Front track

1510 mm 59.45 in.

Rear (Back) track

1520 mm 59.84 in.

Minimum turning circle (turning diameter)

10.4 m 34.12 ft.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) and electric motor drive the front wheels of the car with the ability to work only in mixed mode.

Drive wheel

Front wheel drive

Number of gears and type of gearbox

5 gears, manual transmission

Front suspension

Coil spring, Independent, McPherson type

Rear suspension

Coil spring, Torsion bar

Front brakes

Ventilated discs

Rear brakes

Drum

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Electric Steering

Tire size

185/65 R15

Wheel rim size

Specs of Suzuki XL6 1.5 (105 Hp) Mild Hybrid /2019, 2020, 2021, 2022/
