SMA C61 1.6 (105 Hp) | Technical Specs, Fuel consumption, Dimensions

Key specs

SMA C61 1.6 (105 Hp) /Sedan 2005 - 2016/

What is the body type of SMA C61?

Sedan, 4 Doors, 5 Seats

How environmentally friendly is SMA C61 1.6 (105 Hp)?

Euro 3

How fast is 2005 C61 1.6 (105 Hp)?

170 km/h | 106 mph

What is the power output of SMA C61 Sedan 2005 1.6 (105 Hp)?

105 Hp, 137 Nm
101 lb.-ft.

What is the engine displacement of SMA C61 Sedan 2005 1.6 (105 Hp)?

1.6 l
1587 cm³
96.84 cu. in.

What is the number of cylinders in 2005 SMA 1.6 (105 Hp)?

4, Inline

What is the drivetrain of SMA C61 Sedan 2005 1.6 (105 Hp)?

Front wheel drive. ICE. The Internal combustion engine (ICE) drives the front wheels of the vehicle.

What is the length of 2005 SMA C61 Sedan?

4435 mm
174.61 in.

What is the width of 2005 SMA C61 Sedan?

1710 mm
67.32 in.

What is the kerb weight of 2005 SMA C61 1.6 (105 Hp)?

1160 kg
2557 lbs.

What is the maximum permissible mass of 2005 SMA C61 1.6 (105 Hp)?

1540 kg
3395 lbs.

What is the trunk (boot) capacity of 2005 SMA C61 Sedan?

520 l
18.4 cu. ft.

What are the number of gears and the gearbox type of 2005 SMA C61 1.6 (105 Hp)?

5, manual transmission

SMA C61 1.6 (105 Hp)

SMA
- SMA C61
  - C61
    - 1.6 (105 Hp)

Compare

General information

Brand

SMA

Model

C61

Generation

C61

Modification (Engine)

1.6 (105 Hp)

Start of production

2005

End of production

2016

Powertrain Architecture

Internal Combustion engine

Body type

Sedan

Seats

Doors

Looking for SMA C61 on the used-car market?

Check its history →

Performance specs

Fuel consumption (economy) - extra urban

7 l/100 km 33.6 US mpg
40.4 UK mpg
14.3 km/l

Fuel Type

Petrol (Gasoline)

Maximum speed

170 km/h 106 mph

Emission standard

Euro 3

Weight-to-power ratio

11 kg/Hp, 90.5 Hp/tonne

Weight-to-torque ratio

8.5 kg/Nm, 118.1 Nm/tonne

Engine specs

Power

105 Hp @ 6000 rpm.

Power per litre

66.2 Hp/l

Torque

137 Nm @ 4400 rpm. 101 lb.-ft. @ 4400 rpm.

Engine layout

Front, Transverse

Engine Model/Code

JL481QA

Engine displacement

1587 cm³ 96.84 cu. in.

Number of cylinders

Engine configuration

Inline

Compression ratio

9.6:1

Number of valves per cylinder

Fuel injection system

Multi-port manifold injection

Engine aspiration

Naturally aspirated engine

Valvetrain

DOHC

Volume and weights

Kerb Weight

1160 kg 2557 lbs.

Max. weight

1540 kg 3395 lbs.

Max load

380 kg 838 lbs.

Trunk (boot) space - maximum

520 l 18.4 cu. ft.

Fuel tank capacity

51 l 13.47 US gal | 11.22 UK gal

Dimensions

Length

4435 mm 174.61 in.

Width

1710 mm 67.32 in.

Height

1430 mm 56.3 in.

Wheelbase

2540 mm 100 in.

Front track

1423 mm 56.02 in.

Rear (Back) track

1424 mm 56.06 in.

Minimum turning circle (turning diameter)

10.5 m 34.45 ft.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) drives the front wheels of the vehicle.

Drive wheel

Front wheel drive

Number of gears and type of gearbox

5 gears, manual transmission

Front suspension

Independent, McPherson type with coil spring and anti-roll bar

Rear suspension

Semi-independent suspension, longitudinal arms with transverse torsion shafts

Front brakes

Ventilated discs

Rear brakes

Drum

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Hydraulic Steering

Tire size

175/65 R14

SMA C61 1.6 (105 Hp)2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016: specs, Fuel consumption, Dimensions
