Skoda Kodiaq II iV 1.5 TSI (204 Hp) Plug-in Hybrid DSG | Technical specs, data, fuel consumption, Dimensions

Key specs

Skoda Kodiaq II iV 1.5 TSI (204 Hp) Plug-in Hybrid DSG /SUV 2024 - /

What is the body type of Skoda Kodiaq II?

SUV, 5 Doors, 5 Seats

How environmentally friendly is Skoda Kodiaq iV 1.5 TSI (204 Hp) Plug-in Hybrid DSG?

Euro 6e

What is the all-electric range of iV 1.5 TSI (204 Hp) Plug-in Hybrid DSG?

100 km
62 mi

How fast is 2024 Kodiaq II iV 1.5 TSI (204 Hp) Plug-in Hybrid DSG?

210 km/h | 130 mph
0-100 km/h: 8.4 sec
0-60 mph: 8 sec

What is the power output of Skoda Kodiaq SUV 2024 iV 1.5 TSI (204 Hp) Plug-in Hybrid DSG?

204 Hp, 350 Nm
258 lb.-ft.

What is the engine displacement of Skoda Kodiaq SUV 2024 iV 1.5 TSI (204 Hp) Plug-in Hybrid DSG?

1.5 l
1498 cm³
91.41 cu. in.

What is the number of cylinders in 2024 Skoda iV 1.5 TSI (204 Hp) Plug-in Hybrid DSG?

4, Inline

What is the drivetrain of Skoda Kodiaq II SUV 2024 iV 1.5 TSI (204 Hp) Plug-in Hybrid DSG?

Front wheel drive. PHEV (Plug-in Hybrid Electric Vehicle). The Internal combustion engine (ICE) and electric motor drive the front wheels of the car with the ability to work in full electric or mixed mode.

What is the length of 2024 Skoda Kodiaq SUV?

4758 mm
187.32 in.

What is the width of 2024 Skoda Kodiaq SUV?

1864 mm
73.39 in.

What is the kerb weight of 2024 Skoda Kodiaq II iV 1.5 TSI (204 Hp) Plug-in Hybrid DSG?

1838-2009 kg
4052 - 4429 lbs.

What is the maximum permissible mass of 2024 Skoda Kodiaq II iV 1.5 TSI (204 Hp) Plug-in Hybrid DSG?

2432 kg
5362 lbs.

What is the trunk (boot) capacity of 2024 Skoda Kodiaq SUV?

745 - 1945 l
26.3 - 68.7 cu. ft.

What is the number of gears in What is the gearbox type of 2024 Skoda Kodiaq II iV 1.5 TSI (204 Hp) Plug-in Hybrid DSG?

6, automatic transmission DSG

Skoda
- Skoda Kodiaq
  - Kodiaq II

Compare

General information

Brand

Skoda

Model

Kodiaq

Generation

Kodiaq II

Modification (Engine)

iV 1.5 TSI (204 Hp) Plug-in Hybrid DSG

Start of production

January, 2024 year

Powertrain Architecture

PHEV (Plug-in Hybrid Electric Vehicle)

Body type

SUV

Seats

Doors

Looking for Skoda Kodiaq on the used-car market?

Check its history →

Performance specs

Fuel Type

Petrol / electricity

Acceleration 0 - 100 km/h

8.4 sec

Acceleration 0 - 62 mph

8.4 sec

Acceleration 0 - 60 mph (Calculated by Auto-Data.net)

8 sec

Maximum speed

210 km/h 130 mph

Emission standard

Euro 6e

Weight-to-power ratio

9 kg/Hp, 111 Hp/tonne

Weight-to-torque ratio

5.3 kg/Nm, 190.4 Nm/tonne

Electric cars and hybrids specs

Gross battery capacity

25.7 kWh

Net (usable) battery capacity

19.7 kWh

Battery technology

Lithium nickel manganese cobalt oxides (Li-NMC)

Battery location

Under the rear seats

Electric range (WLTP)

100 km 62 mi

Charging ports

Electric motor 1

Electric motor power

116 Hp

Electric motor Torque

330 Nm 243 lb.-ft.

Electric motor location

Between the combustion engine and the transmission

Electric motor type

Synchronous

System power

204 Hp

System torque

350 Nm 258 lb.-ft.

Internal combustion engine specs

Power

150 Hp @ 5000-6000 rpm.

Power per litre

100.1 Hp/l

Torque

250 Nm @ 1500-4000 rpm. 184 lb.-ft. @ 1500-4000 rpm.

Engine layout

Front, Transverse

Engine Model/Code

EA211 evo2 / DUCB

Engine displacement

1498 cm³ 91.41 cu. in.

Number of cylinders

Engine configuration

Inline

Cylinder Bore

74.5 mm 2.93 in.

Piston Stroke

85.9 mm 3.38 in.

Compression ratio

11.5:1

Number of valves per cylinder

Fuel injection system

Direct injection

Engine aspiration

Turbocharger, Intercooler

Valvetrain

DOHC

Engine oil capacity

4.3 l 4.54 US qt | 3.78 UK qt

Engine oil specification

Engine systems

Start & Stop System
Particulate filter

Volume and weights

Kerb Weight

1838-2009 kg 4052 - 4429 lbs.

Max. weight

2432 kg 5362 lbs.

Max load

423-594 kg 933 - 1310 lbs.

Trunk (boot) space - minimum

745 l 26.3 cu. ft.

Trunk (boot) space - maximum

1945 l 68.7 cu. ft.

Fuel tank capacity

45 l 11.89 US gal | 9.9 UK gal

Max. roof load

75 kg 165 lbs.

Permitted trailer load with brakes (8%)

1800 kg 3968 lbs.

Permitted trailer load with brakes (12%)

1800 kg 3968 lbs.

Permitted trailer load without brakes

750 kg 1653 lbs.

Permitted towbar download

100 kg 220 lbs.

Dimensions

Length

4758 mm 187.32 in.

Width

1864 mm 73.39 in.

Width with mirrors folded

1924 mm 75.75 in.

Width including mirrors

2133 mm 83.98 in.

Height

1659 mm 65.31 in.

Wheelbase

2791 mm 109.88 in.

Front track

1586 mm 62.44 in.

Rear (Back) track

1576 mm 62.05 in.

Front overhang

927 mm 36.5 in.

Rear overhang

1041 mm 40.98 in.

Ride height (ground clearance)

189 mm 7.44 in.

Drag coefficient (C_d)

0.296-0.324

Minimum turning circle (turning diameter)

11.2 m 36.75 ft.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) and electric motor drive the front wheels of the car with the ability to work in full electric or mixed mode.

Drive wheel

Front wheel drive

Number of gears and type of gearbox

6 gears, automatic transmission DSG

Front suspension

Independent, McPherson type with coil spring and anti-roll bar

Rear suspension

Independent multi-link spring suspension with anti-roll bar

Front brakes

Ventilated discs

Rear brakes

Disc

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Electric Steering

Tires size

215/65 R17; 235/55 R18; 235/50 R19; 235/45 R20

Wheel rims size

7J x 17; 7.5J x 18; 7.5J x 19; 8J x 20

Specs of Skoda Kodiaq II iV 1.5 TSI (204 Hp) Plug-in Hybrid DSG /2024, 2025, 2026/
