Seat Ibiza III 1.4 16V (100 Hp) | Technical specs, data, fuel consumption, Dimensions

Key specs

Seat Ibiza III 1.4 16V (100 Hp) /Hatchback 2002 - 2006/

What is the body type of Seat Ibiza III?

Hatchback, 3-5 Doors, 5 Seats

What is the fuel consumption and economy of Seat Ibiza III 1.4 16V (100 Hp)?

6.9 l/100 km
34.1 US mpg
40.9 UK mpg
14.5 km/l

How fast is 2002 Ibiza III 1.4 16V (100 Hp)?

191 km/h | 119 mph
0-100 km/h: 11.2 sec
0-60 mph: 10.6 sec

What is the power output of Seat Ibiza Hatchback 2002 1.4 16V (100 Hp)?

100 Hp, 126 Nm
93 lb.-ft.

What is the engine displacement of Seat Ibiza Hatchback 2002 1.4 16V (100 Hp)?

1.4 l
1390 cm³
84.82 cu. in.

What is the number of cylinders in 2002 Seat 1.4 16V (100 Hp)?

4, Inline

What is the drivetrain of Seat Ibiza III Hatchback 2002 1.4 16V (100 Hp)?

Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle.

What is the length of 2002 Seat Ibiza Hatchback?

3955 mm
155.71 in.

What is the width of 2002 Seat Ibiza Hatchback?

1700 mm
66.93 in.

What is the kerb weight of 2002 Seat Ibiza III 1.4 16V (100 Hp)?

1050 kg
2315 lbs.

What is the trunk (boot) capacity of 2002 Seat Ibiza Hatchback?

265 - 1030 l
9.4 - 36.4 cu. ft.

What are the number of gears and the gearbox type of 2002 Seat Ibiza III 1.4 16V (100 Hp)?

5, manual transmission

Seat
- Seat Ibiza
  - Ibiza III

Compare

General information

Brand

Seat

Model

Ibiza

Generation

Ibiza III

Modification (Engine)

1.4 16V (100 Hp)

Start of production

2002

End of production

2006

Powertrain Architecture

Internal Combustion engine

Body type

Hatchback

Seats

Doors

3-5

Looking for Seat Ibiza on the used-car market?

Check its history →

Performance specs

Fuel consumption (economy) - urban

9.4 l/100 km 25 US mpg
30.1 UK mpg
10.6 km/l

Fuel consumption (economy) - extra urban

5.5 l/100 km 42.8 US mpg
51.4 UK mpg
18.2 km/l

Fuel consumption (economy) - combined

6.9 l/100 km 34.1 US mpg
40.9 UK mpg
14.5 km/l

Fuel Type

Petrol (Gasoline)

Acceleration 0 - 100 km/h

11.2 sec

Acceleration 0 - 62 mph

11.2 sec

Acceleration 0 - 60 mph (Calculated by Auto-Data.net)

10.6 sec

Maximum speed

191 km/h 119 mph

Weight-to-power ratio

10.5 kg/Hp, 95.2 Hp/tonne

Weight-to-torque ratio

8.3 kg/Nm, 120 Nm/tonne

Engine specs

Power

100 Hp @ 6000 rpm.

Power per litre

71.9 Hp/l

Torque

126 Nm @ 4400 rpm. 93 lb.-ft. @ 4400 rpm.

Engine layout

Front, Transverse

Engine Model/Code

AUB, BBZ

Engine displacement

1390 cm³ 84.82 cu. in.

Number of cylinders

Engine configuration

Inline

Cylinder Bore

76.5 mm 3.01 in.

Piston Stroke

75.6 mm 2.98 in.

Compression ratio

10.5:1

Number of valves per cylinder

Fuel injection system

Multi-port manifold injection

Engine aspiration

Naturally aspirated engine

Valvetrain

DOHC

Engine oil capacity

3.2 l 3.38 US qt | 2.82 UK qt

Engine oil specification

Coolant

5.6 l 5.92 US qt | 4.93 UK qt

Volume and weights

Kerb Weight

1050 kg 2315 lbs.

Trunk (boot) space - minimum

265 l 9.4 cu. ft.

Trunk (boot) space - maximum

1030 l 36.4 cu. ft.

Fuel tank capacity

45 l 11.89 US gal | 9.9 UK gal

Dimensions

Length

3955 mm 155.71 in.

Width

1700 mm 66.93 in.

Height

1440 mm 56.69 in.

Wheelbase

2460 mm 96.85 in.

Front track

1435 mm 56.5 in.

Rear (Back) track

1425 mm 56.1 in.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) drives the front wheels of the vehicle.

Drive wheel

Front wheel drive

Number of gears and type of gearbox

5 gears, manual transmission

Front suspension

Wishbone

Rear suspension

Suspension strut

Front brakes

Ventilated discs

Rear brakes

Disc

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Hydraulic Steering

Tire size

185/60 R14

Specs of Seat Ibiza III 1.4 16V (100 Hp) /2002, 2003, 2004, 2005, 2006/
