Scion FR-S 2.0 (200 Hp) | Technical Specs, Fuel consumption, Dimensions

Key specs

Scion FR-S 2.0 (200 Hp) /Coupe 2013 - 2016/

What is the body type of Scion FR-S?

Coupe, 2 Doors, 4 Seats

What is the fuel consumption and economy of Scion FR-S 2.0 (200 Hp)?

7.8 l/100 km
30.2 US mpg
36.2 UK mpg
12.8 km/l

How environmentally friendly is Scion FR-S 2.0 (200 Hp)?

181 g/km CO₂

How fast is 2013 FR-S 2.0 (200 Hp)?

225 km/h | 140 mph
0-100 km/h: 7.6 sec
0-60 mph: 7.2 sec

What is the power output of Scion FR-S Coupe 2013 2.0 (200 Hp)?

200 Hp, 205 Nm
151 lb.-ft.

What is the engine displacement of Scion FR-S Coupe 2013 2.0 (200 Hp)?

2.0 l
1998 cm³
121.93 cu. in.

What is the number of cylinders in 2013 Scion 2.0 (200 Hp)?

4, Boxer

What is the drivetrain of Scion FR-S Coupe 2013 2.0 (200 Hp)?

Rear wheel drive. ICE. The Internal combustion engine (ICE) drives the rear wheels of the vehicle.

What is the length of 2013 Scion FR-S Coupe?

4234 mm
166.69 in.

What is the width of 2013 Scion FR-S Coupe?

1775 mm
69.88 in.

What is the kerb weight of 2013 Scion FR-S 2.0 (200 Hp)?

1251 kg
2758 lbs.

What is the trunk (boot) capacity of 2013 Scion FR-S Coupe?

195 l
6.9 cu. ft.

What are the number of gears and the gearbox type of 2013 Scion FR-S 2.0 (200 Hp)?

6, manual transmission

Scion FR-S 2.0 (200 Hp)

Scion
- Scion FR-S
  - FR-S
    - 2.0 (200 Hp) Automatic
    - 2.0 (200 Hp)

Compare

General information

Brand

Scion

Model

FR-S

Generation

FR-S

Modification (Engine)

2.0 (200 Hp)

Start of production

2013

End of production

2016

Powertrain Architecture

Internal Combustion engine

Body type

Coupe

Seats

Doors

Looking for Scion FR-S on the used-car market?

Check its history →

Performance specs

Fuel consumption (economy) - urban

10.4 l/100 km 22.6 US mpg
27.2 UK mpg
9.6 km/l

Fuel consumption (economy) - extra urban

6.4 l/100 km 36.8 US mpg
44.1 UK mpg
15.6 km/l

Fuel consumption (economy) - combined

7.8 l/100 km 30.2 US mpg
36.2 UK mpg
12.8 km/l

CO₂ emissions

181 g/km

Fuel Type

Petrol (Gasoline)

Acceleration 0 - 100 km/h

7.6 sec

Acceleration 0 - 62 mph

7.6 sec

Acceleration 0 - 60 mph (Calculated by Auto-Data.net)

7.2 sec

Maximum speed

225 km/h 140 mph

Weight-to-power ratio

6.3 kg/Hp, 159.9 Hp/tonne

Weight-to-torque ratio

6.1 kg/Nm, 163.9 Nm/tonne

Engine specs

Power

200 Hp @ 7000 rpm.

Power per litre

100.1 Hp/l

Torque

205 Nm @ 6400-6600 rpm. 151 lb.-ft. @ 6400-6600 rpm.

Engine layout

Front, Longitudinal

Engine Model/Code

FA20

Engine displacement

1998 cm³ 121.93 cu. in.

Number of cylinders

Engine configuration

Boxer

Cylinder Bore

86 mm 3.39 in.

Piston Stroke

86 mm 3.39 in.

Compression ratio

12.5:1

Number of valves per cylinder

Fuel injection system

Direct injection

Engine aspiration

Naturally aspirated engine

Valvetrain

DOHC

Engine oil capacity

5.4 l 5.71 US qt | 4.75 UK qt

Engine oil specification

Coolant

7.2 l 7.61 US qt | 6.34 UK qt

Volume and weights

Kerb Weight

1251 kg 2758 lbs.

Trunk (boot) space - minimum

195 l 6.9 cu. ft.

Fuel tank capacity

50 l 13.21 US gal | 11 UK gal

Dimensions

Length

4234 mm 166.69 in.

Width

1775 mm 69.88 in.

Height

1285 mm 50.59 in.

Wheelbase

2570 mm 101.18 in.

Front track

1519 mm 59.8 in.

Rear (Back) track

1539 mm 60.59 in.

Ride height (ground clearance)

124 mm 4.88 in.

Drag coefficient (C_d)

0.27

Minimum turning circle (turning diameter)

11.0 m 36.09 ft.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) drives the rear wheels of the vehicle.

Drive wheel

Rear wheel drive

Number of gears and type of gearbox

6 gears, manual transmission

Front suspension

Independent, McPherson type

Rear suspension

Double wishbone

Front brakes

Ventilated discs

Rear brakes

Ventilated discs

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Electric Steering

Tire size

215/45 R17

Wheel rim size

7.0J x 17

Scion FR-S 2.0 (200 Hp)2013, 2014, 2015, 2016: specs, Fuel consumption, Dimensions
