Saab 9-2X 2.0 i 16V T Aero (230 Hp) | Technical specs, data, fuel consumption, Dimensions

Key specs

Saab 9-2X 2.0 i 16V T Aero (230 Hp) /Station wagon (estate) 2004 - 2006/

What is the body type of Saab 9-2X?

Station wagon (estate), 5 Doors, 5 Seats

How fast is 2004 9-2X 2.0 i 16V T Aero (230 Hp)?

227 km/h | 141 mph

What is the power output of Saab 9-2X Station wagon (estate) 2004 2.0 i 16V T Aero (230 Hp)?

230 Hp, 294 Nm
217 lb.-ft.

What is the engine displacement of Saab 9-2X Station wagon (estate) 2004 2.0 i 16V T Aero (230 Hp)?

2.0 l
1994 cm³
121.68 cu. in.

What is the number of cylinders in 2004 Saab 2.0 i 16V T Aero (230 Hp)?

4, Boxer

What is the drivetrain of Saab 9-2X Station wagon (estate) 2004 2.0 i 16V T Aero (230 Hp)?

All wheel drive (4x4). Internal Combustion engine.

What is the length of 2004 Saab 9-2X Station wagon (estate)?

4460 mm
175.59 in.

What is the width of 2004 Saab 9-2X Station wagon (estate)?

1695 mm
66.73 in.

What is the kerb weight of 2004 Saab 9-2X 2.0 i 16V T Aero (230 Hp)?

1445 kg
3186 lbs.

What is the trunk (boot) capacity of 2004 Saab 9-2X Station wagon (estate)?

790 - 1744 l
27.9 - 61.6 cu. ft.

What is the number of gears in What is the gearbox type of 2004 Saab 9-2X 2.0 i 16V T Aero (230 Hp)?

5, manual transmission

Saab
- Saab 9-2X
  - 9-2X
    - 2.5i 16V (173 Hp)
    - 2.0 i 16V T Aero (230 Hp)

Compare

General information

Brand

Saab

Model

9-2X

Generation

9-2X

Modification (Engine)

2.0 i 16V T Aero (230 Hp)

Start of production

2004 year

End of production

2006 year

Powertrain Architecture

Internal Combustion engine

Body type

Station wagon (estate)

Seats

Doors

Performance specs

Fuel consumption (economy) - urban

11.8 l/100 km 19.9 US mpg
23.9 UK mpg
8.5 km/l

Fuel consumption (economy) - extra urban

8.7 l/100 km 27 US mpg
32.5 UK mpg
11.5 km/l

Fuel Type

Petrol (Gasoline)

Maximum speed

227 km/h 141 mph

Weight-to-power ratio

6.3 kg/Hp, 159.2 Hp/tonne

Weight-to-torque ratio

4.9 kg/Nm, 203.5 Nm/tonne

Engine specs

Power

230 Hp @ 6000 rpm.

Power per litre

115.3 Hp/l

Torque

294 Nm @ 4000 rpm. 217 lb.-ft. @ 4000 rpm.

Engine layout

Front, Longitudinal

Engine Model/Code

EJ205

Engine displacement

1994 cm³ 121.68 cu. in.

Number of cylinders

Engine configuration

Boxer

Cylinder Bore

92 mm 3.62 in.

Piston Stroke

75 mm 2.95 in.

Compression ratio

8:1

Number of valves per cylinder

Fuel injection system

Multi-port manifold injection

Engine aspiration

Turbocharger, Intercooler

Engine oil capacity

4 l 4.23 US qt | 3.52 UK qt

Engine oil specification

Coolant

8.1 l 8.56 US qt | 7.13 UK qt

Volume and weights

Kerb Weight

1445 kg 3186 lbs.

Trunk (boot) space - minimum

790 l 27.9 cu. ft.

Trunk (boot) space - maximum

1744 l 61.6 cu. ft.

Fuel tank capacity

60 l 15.85 US gal | 13.2 UK gal

Dimensions

Length

4460 mm 175.59 in.

Width

1695 mm 66.73 in.

Height

1465 mm 57.68 in.

Wheelbase

2525 mm 99.41 in.

Front track

1465 mm 57.68 in.

Rear (Back) track

1455 mm 57.28 in.

Minimum turning circle (turning diameter)

10.8 m 35.43 ft.

Drivetrain, brakes and suspension specs

Drive wheel

All wheel drive (4x4)

Number of gears and type of gearbox

5 gears, manual transmission

Front suspension

Suspension strut

Rear suspension

Suspension strut

Front brakes

Ventilated discs

Rear brakes

Disc

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Tires size

215/45 R17

Specs of Saab 9-2X 2.0 i 16V T Aero (230 Hp) /2004, 2005, 2006/
