Roewe iMAX8 2.0T 400TGI (234 Hp) Aisin | Technical specs, data, fuel consumption, Dimensions

Key specs

Roewe iMAX8 2.0T 400TGI (234 Hp) Aisin /Minivan 2020 - /

What is the body type of Roewe iMAX8?

Minivan, 5 Doors, 7 Seats

What is the fuel consumption and economy of Roewe iMAX8 2.0T 400TGI (234 Hp) Aisin?

8.4 l/100 km
28 US mpg
33.6 UK mpg
11.9 km/l

How environmentally friendly is Roewe iMAX8 2.0T 400TGI (234 Hp) Aisin?

China VI

How fast is 2020 iMAX8 2.0T 400TGI (234 Hp) Aisin?

200 km/h | 124 mph

What is the power output of Roewe iMAX8 Minivan 2020 2.0T 400TGI (234 Hp) Aisin?

234 Hp, 360 Nm
266 lb.-ft.

What is the engine displacement of Roewe iMAX8 Minivan 2020 2.0T 400TGI (234 Hp) Aisin?

2.0 l
1986 cm³
121.19 cu. in.

What is the number of cylinders in 2020 Roewe 2.0T 400TGI (234 Hp) Aisin?

4, Inline

What is the drivetrain of Roewe iMAX8 Minivan 2020 2.0T 400TGI (234 Hp) Aisin?

Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle.

What is the length of 2020 Roewe iMAX8 Minivan?

5016 mm
197.48 in.

What is the width of 2020 Roewe iMAX8 Minivan?

1909 mm
75.16 in.

What is the kerb weight of 2020 Roewe iMAX8 2.0T 400TGI (234 Hp) Aisin?

2058 kg
4537 lbs.

What are the number of gears and the gearbox type of 2020 Roewe iMAX8 2.0T 400TGI (234 Hp) Aisin?

8, automatic transmission Aisin

Roewe
- Roewe iMAX8
  - iMAX8
    - 2.0T 400TGI (234 Hp) Aisin

Compare

General information

Brand

Roewe

Model

iMAX8

Generation

iMAX8

Modification (Engine)

2.0T 400TGI (234 Hp) Aisin

Start of production

October, 2020

Powertrain Architecture

Internal Combustion engine

Body type

Minivan

Seats

Doors

Looking for Roewe iMAX8 on the used-car market?

Check its history →

Performance specs

Fuel consumption (economy) - combined

8.4 l/100 km 28 US mpg
33.6 UK mpg
11.9 km/l

Fuel Type

Petrol (Gasoline)

Maximum speed

200 km/h 124 mph

Emission standard

China VI

Weight-to-power ratio

8.8 kg/Hp, 113.7 Hp/tonne

Weight-to-torque ratio

5.7 kg/Nm, 174.9 Nm/tonne

Engine specs

Power

234 Hp @ 5000-5500 rpm.

Power per litre

117.8 Hp/l

Torque

360 Nm @ 1500-4000 rpm. 266 lb.-ft. @ 1500-4000 rpm.

Engine layout

Front, Transverse

Engine Model/Code

20A4E

Engine displacement

1986 cm³ 121.19 cu. in.

Number of cylinders

Engine configuration

Inline

Number of valves per cylinder

Fuel injection system

Direct injection

Engine aspiration

Turbocharger, Intercooler

Engine oil capacity

4.8 l 5.07 US qt | 4.22 UK qt

Engine oil specification

Coolant

9.6 l 10.14 US qt | 8.45 UK qt

Engine systems

Start & Stop System

Volume and weights

Kerb Weight

2058 kg 4537 lbs.

Fuel tank capacity

70 l 18.49 US gal | 15.4 UK gal

Dimensions

Length

5016 mm 197.48 in.

Width

1909 mm 75.16 in.

Height

1782 mm 70.16 in.

Wheelbase

3000 mm 118.11 in.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) drives the front wheels of the vehicle.

Drive wheel

Front wheel drive

Number of gears and type of gearbox

8 gears, automatic transmission Aisin

Front suspension

Independent, McPherson type

Rear suspension

Independent multi-link suspension

Front brakes

Ventilated discs

Rear brakes

Ventilated discs

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Electric Steering

Tire size

225/55 R18

Specs of Roewe iMAX8 2.0T 400TGI (234 Hp) Aisin /2020, 2021, 2022, 2023, 2024, 2025, 2026/
