Renault Clio IV (Phase I) 1.5 Energy dCi (90 Hp) Start&Stop | Technical specs, data, fuel consumption, Dimensions

2012 Renault Clio IV (Phase I) - Photo 1

Key specs

Renault Clio IV (Phase I) 1.5 Energy dCi (90 Hp) Start&Stop /Hatchback 2012 - 2016/

What is the body type of Renault Clio IV (Phase I)?

Hatchback, 5 Doors, 5 Seats

What is the fuel consumption and economy of Renault Clio IV (Phase I) 1.5 Energy dCi (90 Hp) Start&Stop?

3.6 l/100 km
65.3 US mpg
78.5 UK mpg
27.8 km/l

How environmentally friendly is Renault Clio 1.5 Energy dCi (90 Hp) Start&Stop?

Euro 5

How fast is 2012 Clio IV (Phase I) 1.5 Energy dCi (90 Hp) Start&Stop?

181 km/h | 112 mph
0-100 km/h: 11.7 sec
0-60 mph: 11.1 sec

What is the power output of Renault Clio Hatchback 2012 1.5 Energy dCi (90 Hp) Start&Stop?

90 Hp, 220 Nm
162 lb.-ft.

What is the engine displacement of Renault Clio Hatchback 2012 1.5 Energy dCi (90 Hp) Start&Stop?

1.5 l
1461 cm³
89.16 cu. in.

What is the number of cylinders in 2012 Renault 1.5 Energy dCi (90 Hp) Start&Stop?

4, Inline

What is the drivetrain of Renault Clio IV (Phase I) Hatchback 2012 1.5 Energy dCi (90 Hp) Start&Stop?

Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle.

What is the length of 2012 Renault Clio Hatchback?

4062 mm
159.92 in.

What is the width of 2012 Renault Clio Hatchback?

1777 mm
69.96 in.

What is the kerb weight of 2012 Renault Clio IV (Phase I) 1.5 Energy dCi (90 Hp) Start&Stop?

1071 kg
2361 lbs.

What is the maximum permissible mass of 2012 Renault Clio IV (Phase I) 1.5 Energy dCi (90 Hp) Start&Stop?

1658 kg
3655 lbs.

What are the number of gears and the gearbox type of 2012 Renault Clio IV (Phase I) 1.5 Energy dCi (90 Hp) Start&Stop?

5, manual transmission

Renault
- Renault Clio
  - Clio IV (Phase I)
    - 1.6 (200 Hp) RS Automatic
    - 1.5 Energy dCi (90 Hp) Start&Stop
    - 1.5 dCi (75 Hp)
    - 1.2 TCe (120 Hp) GT Automatic
    - 1.2 16V (75 Hp)
    - 0.9 (90 Hp) Energy TCE Start&Stop

Compare

General information

Brand

Renault

Model

Clio

Generation

Clio IV (Phase I)

Modification (Engine)

1.5 Energy dCi (90 Hp) Start&Stop

Start of production

2012

End of production

2016

Powertrain Architecture

Internal Combustion engine

Body type

Hatchback

Seats

Doors

Looking for Renault Clio on the used-car market?

Check its history →

Performance specs

Fuel consumption (economy) - urban

4.1 l/100 km 57.4 US mpg
68.9 UK mpg
24.4 km/l

Fuel consumption (economy) - extra urban

3.3 l/100 km 71.3 US mpg
85.6 UK mpg
30.3 km/l

Fuel consumption (economy) - combined

3.6 l/100 km 65.3 US mpg
78.5 UK mpg
27.8 km/l

Fuel Type

Diesel

Acceleration 0 - 100 km/h

11.7 sec

Acceleration 0 - 62 mph

11.7 sec

Acceleration 0 - 60 mph (Calculated by Auto-Data.net)

11.1 sec

Maximum speed

181 km/h 112 mph

Emission standard

Euro 5

Weight-to-power ratio

11.9 kg/Hp, 84 Hp/tonne

Weight-to-torque ratio

4.9 kg/Nm, 205.4 Nm/tonne

Engine specs

Power

90 Hp @ 4000 rpm.

Power per litre

61.6 Hp/l

Torque

220 Nm @ 1750 rpm. 162 lb.-ft. @ 1750 rpm.

Engine layout

Front, Transverse

Engine Model/Code

K9K 628

Engine displacement

1461 cm³ 89.16 cu. in.

Number of cylinders

Engine configuration

Inline

Number of valves per cylinder

Fuel injection system

Diesel Commonrail

Engine aspiration

Turbocharger, Intercooler

Engine oil capacity

4.5 l 4.76 US qt | 3.96 UK qt

Engine oil specification

Coolant

5 l 5.28 US qt | 4.4 UK qt

Engine systems

Start & Stop System
Particulate filter

Volume and weights

Kerb Weight

1071 kg 2361 lbs.

Max. weight

1658 kg 3655 lbs.

Max load

587 kg 1294 lbs.

Fuel tank capacity

45 l 11.89 US gal | 9.9 UK gal

Dimensions

Length

4062 mm 159.92 in.

Width

1777 mm 69.96 in.

Height

1448 mm 57.01 in.

Wheelbase

2589 mm 101.93 in.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) drives the front wheels of the vehicle.

Drive wheel

Front wheel drive

Number of gears and type of gearbox

5 gears, manual transmission

Front suspension

Independent, McPherson type with coil spring and anti-roll bar

Front brakes

Ventilated discs

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Electric Steering

Tire size

185/65 R15 88t; 195/55 R16 87H

Wheel rim size

15; 16

Specs of Renault Clio IV (Phase I) 1.5 Energy dCi (90 Hp) Start&Stop /2012, 2013, 2014, 2015, 2016/
