RAM 1500 Quad Cab (DS) 4.7 V8 (310 Hp) 4x4 Automatic | Technical specs, data, fuel consumption, Dimensions

Key specs

RAM 1500 Quad Cab (DS) 4.7 V8 (310 Hp) 4x4 Automatic /Pick-up 2010 - 2012/

What is the body type of RAM 1500 Quad Cab (DS)?

Pick-up, 4 Doors, 5-6 Seats

What is the power output of RAM 1500 Pick-up 2010 4.7 V8 (310 Hp) 4x4 Automatic?

310 Hp, 447 Nm
330 lb.-ft.

What is the engine displacement of RAM 1500 Pick-up 2010 4.7 V8 (310 Hp) 4x4 Automatic?

4.7 l
4701 cm³
286.87 cu. in.

What is the number of cylinders in 2010 RAM 4.7 V8 (310 Hp) 4x4 Automatic?

8, V-engine

What is the drivetrain of RAM 1500 Quad Cab (DS) Pick-up 2010 4.7 V8 (310 Hp) 4x4 Automatic?

All wheel drive (4x4). Internal Combustion engine.

What is the length of 2010 RAM 1500 Pick-up?

5816 mm
228.98 in.

What is the width of 2010 RAM 1500 Pick-up?

2016 mm
79.37 in.

What is the kerb weight of 2010 RAM 1500 Quad Cab (DS) 4.7 V8 (310 Hp) 4x4 Automatic?

2363 kg
5210 lbs.

What is the maximum permissible mass of 2010 RAM 1500 Quad Cab (DS) 4.7 V8 (310 Hp) 4x4 Automatic?

3039 kg
6700 lbs.

What is the trunk (boot) capacity of 2010 RAM 1500 Pick-up?

1628 l
57.5 cu. ft.

What is the number of gears in What is the gearbox type of 2010 RAM 1500 Quad Cab (DS) 4.7 V8 (310 Hp) 4x4 Automatic?

5, automatic transmission

RAM
- RAM 1500
  - 1500 Quad Cab (DS)
    - 5.7 Hemi V8 (390 Hp) Automatic
    - 5.7 Hemi V8 (390 Hp) 4x4 Automatic
    - 4.7 V8 (310 Hp) Automatic
    - 4.7 V8 (310 Hp) 4x4 Automatic
    - 3.7 V6 (215 Hp) Automatic

Compare

General information

Brand

RAM

Model

1500

Generation

1500 Quad Cab (DS)

Modification (Engine)

4.7 V8 (310 Hp) 4x4 Automatic

Start of production

2010 year

End of production

2012 year

Powertrain Architecture

Internal Combustion engine

Body type

Pick-up

Seats

5-6

Doors

Looking for RAM 1500 on the used-car market?

Check its history →

Performance specs

Fuel consumption (economy) - urban

16.7 l/100 km 14.1 US mpg
16.9 UK mpg
6 km/l

Fuel consumption (economy) - extra urban

11.4 l/100 km 20.6 US mpg
24.8 UK mpg
8.8 km/l

Fuel Type

Petrol (Gasoline)

Weight-to-power ratio

7.6 kg/Hp, 131.2 Hp/tonne

Weight-to-torque ratio

5.3 kg/Nm, 189.2 Nm/tonne

Engine specs

Power

310 Hp @ 5650 rpm.

Power per litre

65.9 Hp/l

Torque

447 Nm @ 3950 rpm. 330 lb.-ft. @ 3950 rpm.

Maximum engine speed

6000 rpm.

Engine layout

Front, Longitudinal

Engine Model/Code

EVE

Engine displacement

4701 cm³ 286.87 cu. in.

Number of cylinders

Engine configuration

V-engine

Cylinder Bore

93 mm 3.66 in.

Piston Stroke

86.5 mm 3.41 in.

Compression ratio

9.8:1

Number of valves per cylinder

Fuel injection system

Multi-port manifold injection

Engine aspiration

Naturally aspirated engine

Valvetrain

SOHC

Engine oil capacity

5.7 l 6.02 US qt | 5.02 UK qt

Engine oil specification

Coolant

13 l 13.74 US qt | 11.44 UK qt

Volume and weights

Kerb Weight

2363 kg 5210 lbs.

Max. weight

3039 kg 6700 lbs.

Max load

676 kg 1490 lbs.

Trunk (boot) space - maximum

1628 l 57.5 cu. ft.

Fuel tank capacity

98 l 25.89 US gal | 21.56 UK gal

Permitted trailer load with brakes (12%)

2767 kg 6100 lbs.

Dimensions

Length

5816 mm 228.98 in.

Width including mirrors

2016 mm 79.37 in.

Height

1922 mm 75.67 in.

Wheelbase

3569 mm 140.51 in.

Front track

1732 mm 68.19 in.

Rear (Back) track

1714 mm 67.48 in.

Drag coefficient (C_d)

0.36

Minimum turning circle (turning diameter)

13.8 m 45.28 ft.

Approach angle

20.5°

Departure angle

25.4°

Ramp-over (brakeover) angle

16.6°

Drivetrain, brakes and suspension specs

Drive wheel

All wheel drive (4x4)

Number of gears and type of gearbox

5 gears, automatic transmission

Front suspension

Double wishbone

Rear suspension

Independent multi-link suspension

Front brakes

Ventilated discs

Rear brakes

Disc

Assisting systems

ABS (Anti-lock braking system)

Tires size

265/70 R17

Wheel rims size

7.0J x 17
