Porsche 911 Targa (G) 3.0 Carrera (200 Hp) | Technical specs, data, fuel consumption, Dimensions

Key specs

Porsche 911 Targa (G) 3.0 Carrera (200 Hp) /Targa 1977 - 1979/

What is the body type of Porsche 911 Targa (G)?

Targa, 2 Doors, 4 Seats

What is the power output of Porsche 911 Targa 1977 3.0 Carrera (200 Hp)?

200 Hp, 255 Nm
188 lb.-ft.

What is the engine displacement of Porsche 911 Targa 1977 3.0 Carrera (200 Hp)?

3.0 l
2993 cm³
182.64 cu. in.

What is the number of cylinders in 1977 Porsche 3.0 Carrera (200 Hp)?

6, Boxer

What is the drivetrain of Porsche 911 Targa (G) Targa 1977 3.0 Carrera (200 Hp)?

Rear wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the rear wheels of the vehicle.

What is the length of 1977 Porsche 911 Targa?

4291 mm
168.94 in.

What is the width of 1977 Porsche 911 Targa?

1652 mm
65.04 in.

What are the number of gears and the gearbox type of 1977 Porsche 911 Targa (G) 3.0 Carrera (200 Hp)?

5, manual transmission

Porsche
- Porsche 911
  - 911 Targa (G)
    - 3.0 SC (188 Hp)
    - 3.0 SC (180 Hp)
    - 3.0 Carrera (200 Hp)
    - 2.7 S (175 Hp)
    - 2.7 (165 Hp)
    - 2.7 (150 Hp)

Compare

General information

Brand

Porsche

Model

911

Generation

911 Targa (G)

Modification (Engine)

3.0 Carrera (200 Hp)

Start of production

1977

End of production

1979

Powertrain Architecture

Internal Combustion engine

Body type

Targa

Seats

Doors

Looking for Porsche 911 on the used-car market?

Check its history →

Performance specs

Fuel Type

Petrol (Gasoline)

Engine specs

Power

200 Hp @ 6000 rpm.

Power per litre

66.8 Hp/l

Torque

255 Nm @ 4200 rpm. 188 lb.-ft. @ 4200 rpm.

Maximum engine speed

6800 rpm.

Engine layout

Rear, Longitudinal

Engine Model/Code

930.02

Engine displacement

2993 cm³ 182.64 cu. in.

Number of cylinders

Engine configuration

Boxer

Cylinder Bore

95 mm 3.74 in.

Piston Stroke

70.4 mm 2.77 in.

Compression ratio

8.5:1

Number of valves per cylinder

Fuel injection system

Multi-port manifold injection

Engine aspiration

Naturally aspirated engine

Valvetrain

SOHC

Engine oil capacity

10 l 10.57 US qt | 8.8 UK qt

Engine oil specification

Dimensions

Length

4291 mm 168.94 in.

Width

1652 mm 65.04 in.

Height

1320 mm 51.97 in.

Wheelbase

2272 mm 89.45 in.

Front track

1369 mm 53.9 in.

Rear (Back) track

1380 mm 54.33 in.

Front overhang

932 mm 36.69 in.

Rear overhang

1087 mm 42.8 in.

Ride height (ground clearance)

120 mm 4.72 in.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) drives the rear wheels of the vehicle.

Drive wheel

Rear wheel drive

Number of gears and type of gearbox

5 gears, manual transmission

Front suspension

Suspension strut, Wishbone

Rear suspension

Trailing arm

Front brakes

Ventilated discs, 282.5 mm

Rear brakes

Ventilated discs, 290 mm

Steering type

Steering rack and pinion

Tire size

Front wheel tires: 185/70 R15; 205/55 R16
Rear wheel tires: 215/60 R15, 225/50 R16

Wheel rim size

Front wheel rims: 6J x 15; 6 J x 16
Rear wheel rims: 7J x 15, 7J x 16

Specs of Porsche 911 Targa (G) 3.0 Carrera (200 Hp) /1977, 1978, 1979/
