Porsche 911 Coupe (G) 3.2 Carrera CAT (217 Hp) | Technical specs, data, fuel consumption, Dimensions

Key specs

Porsche 911 Coupe (G) 3.2 Carrera CAT (217 Hp) /Coupe 1986 - 1989/

What is the body type of Porsche 911 Coupe (G)?

Coupe, 2 Doors, 4 Seats

How fast is 1986 911 Coupe (G) 3.2 Carrera CAT (217 Hp)?

240 km/h | 149 mph
0-100 km/h: 6.3 sec
0-60 mph: 6 sec

What is the power output of Porsche 911 Coupe 1986 3.2 Carrera CAT (217 Hp)?

217 Hp, 265 Nm
195 lb.-ft.

What is the engine displacement of Porsche 911 Coupe 1986 3.2 Carrera CAT (217 Hp)?

3.2 l
3164 cm³
193.08 cu. in.

What is the number of cylinders in 1986 Porsche 3.2 Carrera CAT (217 Hp)?

6, Boxer

What is the drivetrain of Porsche 911 Coupe (G) Coupe 1986 3.2 Carrera CAT (217 Hp)?

Rear wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the rear wheels of the vehicle.

What is the length of 1986 Porsche 911 Coupe?

4291 mm
168.94 in.

What is the width of 1986 Porsche 911 Coupe?

1652 mm
65.04 in.

What is the kerb weight of 1986 Porsche 911 Coupe (G) 3.2 Carrera CAT (217 Hp)?

1210 kg
2668 lbs.

What is the maximum permissible mass of 1986 Porsche 911 Coupe (G) 3.2 Carrera CAT (217 Hp)?

1530 kg
3373 lbs.

What is the number of gears in What is the gearbox type of 1986 Porsche 911 Coupe (G) 3.2 Carrera CAT (217 Hp)?

5, manual transmission

Porsche
- Porsche 911
  - 911 Coupe (G)
    - 3.2 Carrera (231 Hp)
    - 3.2 Carrera CAT (217 Hp)
    - 3.2 Carrera CAT (207 Hp)
    - 3.0 SC (204 Hp)
    - 3.0 SC (188 Hp)
    - 3.0 SC (180 Hp)
    - 3.0 Carrera (200 Hp)
    - 2.7 S (175 Hp)
    - 2.7 Carrera (210 Hp)
    - 2.7 (165 Hp)
    - 2.7 (150 Hp)

Compare

General information

Brand

Porsche

Model

911

Generation

911 Coupe (G)

Modification (Engine)

3.2 Carrera CAT (217 Hp)

Start of production

1986 year

End of production

1989 year

Powertrain Architecture

Internal Combustion engine

Body type

Coupe

Seats

Doors

Looking for Porsche 911 on the used-car market?

Check its history →

Performance specs

Fuel consumption (economy) - urban

14.9 l/100 km 15.8 US mpg
19 UK mpg
6.7 km/l

Fuel consumption (economy) - extra urban

7.9 l/100 km 29.8 US mpg
35.8 UK mpg
12.7 km/l

Fuel Type

Petrol (Gasoline)

Acceleration 0 - 100 km/h

6.3 sec

Acceleration 0 - 62 mph

6.3 sec

Acceleration 0 - 60 mph (Calculated by Auto-Data.net)

6 sec

Maximum speed

240 km/h 149 mph

Weight-to-power ratio

5.6 kg/Hp, 179.3 Hp/tonne

Weight-to-torque ratio

4.6 kg/Nm, 219 Nm/tonne

Engine specs

Power

217 Hp @ 5900 rpm.

Power per litre

68.6 Hp/l

Torque

265 Nm @ 4800 rpm. 195 lb.-ft. @ 4800 rpm.

Engine layout

Rear, Longitudinal

Engine Model/Code

930.25

Engine displacement

3164 cm³ 193.08 cu. in.

Number of cylinders

Engine configuration

Boxer

Cylinder Bore

95 mm 3.74 in.

Piston Stroke

74.4 mm 2.93 in.

Compression ratio

9.5:1

Number of valves per cylinder

Fuel injection system

Multi-port manifold injection

Engine aspiration

Naturally aspirated engine

Valvetrain

SOHC

Engine oil capacity

10 l 10.57 US qt | 8.8 UK qt

Engine oil specification

Volume and weights

Kerb Weight

1210 kg 2668 lbs.

Max. weight

1530 kg 3373 lbs.

Max load

320 kg 705 lbs.

Fuel tank capacity

85 l 22.45 US gal | 18.7 UK gal

Dimensions

Length

4291 mm 168.94 in.

Width

1652 mm 65.04 in.

Height

1320 mm 51.97 in.

Wheelbase

2272 mm 89.45 in.

Front track

1372 mm 54.02 in.

Rear (Back) track

1405 mm 55.31 in.

Ride height (ground clearance)

130 mm 5.12 in.

Minimum turning circle (turning diameter)

10.35 m 33.96 ft.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) drives the rear wheels of the vehicle.

Drive wheel

Rear wheel drive

Number of gears and type of gearbox

5 gears, manual transmission

Front suspension

Suspension strut, Wishbone

Rear suspension

Trailing arm

Front brakes

Ventilated discs

Rear brakes

Ventilated discs

Steering type

Steering rack and pinion

Tires size

Front wheel tires: 205/55 R16
Rear wheel tires: 225/50 R16

Wheel rims size

Front wheel rims: 6J x 16
Rear wheel rims: 8J x 16

Specs of Porsche 911 Coupe (G) 3.2 Carrera CAT (217 Hp) /1986, 1987, 1988, 1989/
