Peugeot 307 1.6 (109 Hp) Automatic | Technical specs, data, fuel consumption, Dimensions

Key specs

Peugeot 307 1.6 (109 Hp) Automatic /Hatchback 2001 - 2005/

What is the body type of Peugeot 307?

Hatchback, 3-5 Doors, 5 Seats

What is the fuel consumption and economy of Peugeot 307 1.6 (109 Hp) Automatic?

7.9 l/100 km
29.8 US mpg
35.8 UK mpg
12.7 km/l

How environmentally friendly is Peugeot 307 1.6 (109 Hp) Automatic?

183 g/km CO₂
Euro 3

How fast is 2001 307 1.6 (109 Hp) Automatic?

183 km/h | 114 mph
0-100 km/h: 13.5 sec
0-60 mph: 12.8 sec

What is the power output of Peugeot 307 Hatchback 2001 1.6 (109 Hp) Automatic?

109 Hp, 147 Nm
108 lb.-ft.

What is the engine displacement of Peugeot 307 Hatchback 2001 1.6 (109 Hp) Automatic?

1.6 l
1587 cm³
96.84 cu. in.

What is the number of cylinders in 2001 Peugeot 1.6 (109 Hp) Automatic?

4, Inline

What is the drivetrain of Peugeot 307 Hatchback 2001 1.6 (109 Hp) Automatic?

Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle.

What is the length of 2001 Peugeot 307 Hatchback?

4202 mm
165.43 in.

What is the width of 2001 Peugeot 307 Hatchback?

1730 mm
68.11 in.

What is the kerb weight of 2001 Peugeot 307 1.6 (109 Hp) Automatic?

1212 kg
2672 lbs.

What is the maximum permissible mass of 2001 Peugeot 307 1.6 (109 Hp) Automatic?

1712 kg
3774 lbs.

What is the trunk (boot) capacity of 2001 Peugeot 307 Hatchback?

341 - 1328 l
12 - 46.9 cu. ft.

What is the number of gears in What is the gearbox type of 2001 Peugeot 307 1.6 (109 Hp) Automatic?

4, automatic transmission

Peugeot
- Peugeot 307
  - 307
    - 2.0 HDI (136 Hp)
    - 2.0 HDi (107 Hp)
    - 2.0 HDI (90 Hp)
    - 2.0 (136 Hp) Automatic
    - 2.0 (136 Hp)
    - 1.6 HDi (109 Hp)
    - 1.6 (109 Hp) Automatic
    - 1.6 (109 Hp)
    - 1.4 i 16V (88 Hp)
    - 1.4 HDi (68 Hp)
    - 1.4 (75 Hp)

Compare

General information

Brand

Peugeot

Model

307

Generation

307

Modification (Engine)

1.6 (109 Hp) Automatic

Start of production

2001 year

End of production

2005 year

Powertrain Architecture

Internal Combustion engine

Body type

Hatchback

Seats

Doors

3-5

Looking for Peugeot 307 on the used-car market?

Check its history →

Performance specs

Fuel consumption (economy) - urban

10.9 l/100 km 21.6 US mpg
25.9 UK mpg
9.2 km/l

Fuel consumption (economy) - extra urban

6.2 l/100 km 37.9 US mpg
45.6 UK mpg
16.1 km/l

Fuel consumption (economy) - combined

7.9 l/100 km 29.8 US mpg
35.8 UK mpg
12.7 km/l

CO₂ emissions

183 g/km

Fuel Type

Petrol (Gasoline)

Acceleration 0 - 100 km/h

13.5 sec

Acceleration 0 - 62 mph

13.5 sec

Acceleration 0 - 60 mph (Calculated by Auto-Data.net)

12.8 sec

Maximum speed

183 km/h 114 mph

Emission standard

Euro 3

Weight-to-power ratio

11.1 kg/Hp, 89.9 Hp/tonne

Weight-to-torque ratio

8.2 kg/Nm, 121.3 Nm/tonne

Engine specs

Power

109 Hp @ 5750 rpm.

Power per litre

68.7 Hp/l

Torque

147 Nm @ 3900 rpm. 108 lb.-ft. @ 3900 rpm.

Engine layout

Front, Transverse

Engine Model/Code

NFU TU5JP4

Engine displacement

1587 cm³ 96.84 cu. in.

Number of cylinders

Engine configuration

Inline

Cylinder Bore

78.5 mm 3.09 in.

Piston Stroke

82 mm 3.23 in.

Compression ratio

11:1

Number of valves per cylinder

Fuel injection system

Multi-port manifold injection

Engine aspiration

Naturally aspirated engine

Valvetrain

DOHC

Engine oil capacity

3.25 l 3.43 US qt | 2.86 UK qt

Engine oil specification

Coolant

6.7 l 7.08 US qt | 5.9 UK qt

Volume and weights

Kerb Weight

1212 kg 2672 lbs.

Max. weight

1712 kg 3774 lbs.

Max load

500 kg 1102 lbs.

Trunk (boot) space - minimum

341 l 12 cu. ft.

Trunk (boot) space - maximum

1328 l 46.9 cu. ft.

Fuel tank capacity

60 l 15.85 US gal | 13.2 UK gal

Permitted trailer load with brakes (12%)

1200 kg 2646 lbs.

Permitted trailer load without brakes

630 kg 1389 lbs.

Dimensions

Length

4202 mm 165.43 in.

Width

1730 mm 68.11 in.

Height

1510 mm 59.45 in.

Wheelbase

2608 mm 102.68 in.

Front track

1505 mm 59.25 in.

Rear (Back) track

1500 mm 59.06 in.

Ride height (ground clearance)

120 mm 4.72 in.

Drag coefficient (C_d)

0.31

Minimum turning circle (turning diameter)

11.13 m 36.52 ft.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) drives the front wheels of the vehicle.

Drive wheel

Front wheel drive

Number of gears and type of gearbox

4 gears, automatic transmission

Front suspension

Wishbone

Rear suspension

Trailing arm

Front brakes

Ventilated discs

Rear brakes

Disc

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Hydraulic Steering

Tires size

195/65 R15

Wheel rims size

Specs of Peugeot 307 1.6 (109 Hp) Automatic /2001, 2002, 2003, 2004, 2005/
