Nissan Z (RZ34) NISMO 3.0 V6 (420 Hp) Automatic | Technical specs, data, fuel consumption, Dimensions

Key specs

Nissan Z (RZ34) NISMO 3.0 V6 (420 Hp) Automatic /Coupe, Fastback 2023 - 2026/

What is the body type of Nissan Z (RZ34)?

Coupe, Fastback, 2 Doors, 2 Seats

How environmentally friendly is Nissan Z NISMO 3.0 V6 (420 Hp) Automatic?

LEV2-LEV. Tier2-Bin5

What is the power output of Nissan Z Coupe, Fastback 2023 NISMO 3.0 V6 (420 Hp) Automatic?

420 Hp, 521 Nm
384 lb.-ft.

What is the engine displacement of Nissan Z Coupe, Fastback 2023 NISMO 3.0 V6 (420 Hp) Automatic?

3.0 l
2997 cm³
182.89 cu. in.

What is the number of cylinders in 2023 Nissan NISMO 3.0 V6 (420 Hp) Automatic?

6, V-engine

What is the drivetrain of Nissan Z (RZ34) Coupe, Fastback 2023 NISMO 3.0 V6 (420 Hp) Automatic?

Rear wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the rear wheels of the vehicle.

What is the length of 2023 Nissan Z Coupe, Fastback?

4399 mm
173.19 in.

What is the width of 2023 Nissan Z Coupe, Fastback?

1869 mm
73.58 in.

What is the kerb weight of 2023 Nissan Z (RZ34) NISMO 3.0 V6 (420 Hp) Automatic?

1680 kg
3704 lbs.

What is the number of gears in 2023 Nissan Z (RZ34) NISMO 3.0 V6 (420 Hp) Automatic?

9, automatic transmission

Nissan
- Nissan Z
  - Z (RZ34)
    - NISMO 3.0 V6 (420 Hp) Automatic
    - 3.0 V6 (400 Hp) Automatic
    - 3.0 V6 (400 Hp)

Compare

General information

Brand

Nissan

Model

Generation

Z (RZ34)

Modification (Engine)

NISMO 3.0 V6 (420 Hp) Automatic

Start of production

July, 2023 year

End of production

2026 year

Powertrain Architecture

Internal Combustion engine

Body type

Coupe, Fastback

Seats

Doors

Looking for Nissan Z on the used-car market?

Check its history →

Performance specs

Fuel Type

Petrol (Gasoline)

Emission standard

LEV2-LEV. Tier2-Bin5

Weight-to-power ratio

4 kg/Hp, 250 Hp/tonne

Weight-to-torque ratio

3.2 kg/Nm, 310.1 Nm/tonne

Engine specs

Power

420 Hp @ 6400 rpm.

Power per litre

140.1 Hp/l

Torque

521 Nm @ 2000-5200 rpm. 384 lb.-ft. @ 2000-5200 rpm.

Maximum engine speed

6800 rpm.

Engine layout

Front, Longitudinal

Engine Model/Code

VR30DDTT

Engine displacement

2997 cm³ 182.89 cu. in.

Number of cylinders

Engine configuration

V-engine

Cylinder Bore

86 mm 3.39 in.

Piston Stroke

86 mm 3.39 in.

Compression ratio

10.3:1

Number of valves per cylinder

Fuel injection system

Direct injection

Engine aspiration

Twin Turbo, Intercooler

Valvetrain

DOHC, CVTCS

Engine oil capacity

5.3 l 5.6 US qt | 4.66 UK qt

Engine oil specification

Coolant

8.9 l 9.4 US qt | 7.83 UK qt

Volume and weights

Kerb Weight

1680 kg 3704 lbs.

Dimensions

Length

4399 mm 173.19 in.

Width

1869 mm 73.58 in.

Height

1316 mm 51.81 in.

Wheelbase

2550 mm 100.39 in.

Front track

1570 mm 61.81 in.

Rear (Back) track

1580 mm 62.2 in.

Ride height (ground clearance)

124 mm 4.88 in.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) drives the rear wheels of the vehicle.

Drive wheel

Rear wheel drive

Number of gears and type of gearbox

9 gears, automatic transmission

Front suspension

Double wishbone, Anti-roll bar

Rear suspension

Independent multi-link suspension, Anti-roll bar

Front brakes

Ventilated discs, 381x33.02 mm

Rear brakes

Ventilated discs, 350.52x20.32 mm

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Electric Steering

Tires size

Front wheel tires: 255/40 R19
Rear wheel tires: 285/35 R19

Wheel rims size

Front wheel rims: 10J x 19
Rear wheel rims: 10.5J x 19

Specs of Nissan Z (RZ34) NISMO 3.0 V6 (420 Hp) Automatic /2023, 2024, 2025, 2026/
