Nissan Patrol VI (Y62) 5.6 V8 (400 Hp) 4x4 Automatic | Technical specs, data, fuel consumption, Dimensions

Key specs

Nissan Patrol VI (Y62) 5.6 V8 (400 Hp) 4x4 Automatic /SUV 2010 - 2014/

What is the body type of Nissan Patrol VI (Y62)?

SUV, 5 Doors, 8 Seats

What is the power output of Nissan Patrol SUV 2010 5.6 V8 (400 Hp) 4x4 Automatic?

400 Hp, 560 Nm
413 lb.-ft.

What is the engine displacement of Nissan Patrol SUV 2010 5.6 V8 (400 Hp) 4x4 Automatic?

5.6 l
5552 cm³
338.8 cu. in.

What is the number of cylinders in 2010 Nissan 5.6 V8 (400 Hp) 4x4 Automatic?

8, V-engine

What is the drivetrain of Nissan Patrol VI (Y62) SUV 2010 5.6 V8 (400 Hp) 4x4 Automatic?

All wheel drive (4x4). Internal Combustion engine. The Internal combustion engine (ICE) drives permanently the four wheels of the vehicle.

What is the length of 2010 Nissan Patrol SUV?

5140 mm
202.36 in.

What is the width of 2010 Nissan Patrol SUV?

1995 mm
78.54 in.

What is the number of gears in What is the gearbox type of 2010 Nissan Patrol VI (Y62) 5.6 V8 (400 Hp) 4x4 Automatic?

7, automatic transmission

Nissan
- Nissan Patrol
  - Patrol VI (Y62)
    - 5.6 V8 (400 Hp) 4x4 Automatic
    - 5.6 V8 (317 Hp) 4x4 Automatic

Compare

General information

Brand

Nissan

Model

Patrol

Generation

Patrol VI (Y62)

Modification (Engine)

5.6 V8 (400 Hp) 4x4 Automatic

Start of production

2010 year

End of production

2014 year

Powertrain Architecture

Internal Combustion engine

Body type

SUV

Seats

Doors

Looking for Nissan Patrol on the used-car market?

Check its history →

Performance specs

Fuel Type

Petrol (Gasoline)

Engine specs

Power

400 Hp @ 5800 rpm.

Power per litre

72 Hp/l

Torque

560 Nm @ 4000 rpm. 413 lb.-ft. @ 4000 rpm.

Engine layout

Front, Longitudinal

Engine Model/Code

VK56VD

Engine displacement

5552 cm³ 338.8 cu. in.

Number of cylinders

Engine configuration

V-engine

Cylinder Bore

98 mm 3.86 in.

Piston Stroke

92 mm 3.62 in.

Compression ratio

9.8:1

Number of valves per cylinder

Fuel injection system

Direct injection

Engine aspiration

Naturally aspirated engine

Valvetrain

DOHC, CVTCS

Engine oil capacity

6.5 l 6.87 US qt | 5.72 UK qt

Engine oil specification

Coolant

15.1 l 15.96 US qt | 13.29 UK qt

Volume and weights

Fuel tank capacity

100 l 26.42 US gal | 22 UK gal

Dimensions

Length

5140 mm 202.36 in.

Width

1995 mm 78.54 in.

Height

1940 mm 76.38 in.

Wheelbase

3075 mm 121.06 in.

Front track

1695-1706 mm 66.73 - 67.17 in.

Rear (Back) track

1695-1706 mm 66.73 - 67.17 in.

Ride height (ground clearance)

275 mm 10.83 in.

Minimum turning circle (turning diameter)

12.5 m 41.01 ft.

Approach angle

35°

Departure angle

26°

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) drives permanently the four wheels of the vehicle.

Drive wheel

All wheel drive (4x4)

Number of gears and type of gearbox

7 gears, automatic transmission

Front suspension

Double wishbone

Rear suspension

Double wishbone

Front brakes

Ventilated discs

Rear brakes

Ventilated discs

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Hydraulic Steering

Tires size

265/70 R18; 275/60 R20

Wheel rims size

8J x 18; 8J x 20

Specs of Nissan Patrol VI (Y62) 5.6 V8 (400 Hp) 4x4 Automatic /2010, 2011, 2012, 2013, 2014/
