Nissan Note I (E11) 1.5 dCi (86 Hp) | Technical Specs, Fuel consumption, Dimensions

Key specs

Nissan Note I (E11) 1.5 dCi (86 Hp) /Hatchback 2005 - 2009/

What is the body type of Nissan Note I (E11)?

Hatchback, 5 Doors, 5 Seats

How fast is 2005 Note I (E11) 1.5 dCi (86 Hp)?

168 km/h | 104 mph
0-100 km/h: 13 sec
0-60 mph: 12.4 sec

What is the power output of Nissan Note Hatchback 2005 1.5 dCi (86 Hp)?

86 Hp, 200 Nm
148 lb.-ft.

What is the engine displacement of Nissan Note Hatchback 2005 1.5 dCi (86 Hp)?

1.5 l
1461 cm³
89.16 cu. in.

What is the number of cylinders in 2005 Nissan 1.5 dCi (86 Hp)?

4, Inline

What is the drivetrain of Nissan Note I (E11) Hatchback 2005 1.5 dCi (86 Hp)?

Front wheel drive. ICE. The Internal combustion engine (ICE) drives the front wheels of the vehicle.

What is the length of 2005 Nissan Note Hatchback?

4083 mm
160.75 in.

What is the width of 2005 Nissan Note Hatchback?

1690 mm
66.54 in.

What is the kerb weight of 2005 Nissan Note I (E11) 1.5 dCi (86 Hp)?

1165 kg
2568 lbs.

What is the maximum permissible mass of 2005 Nissan Note I (E11) 1.5 dCi (86 Hp)?

1610 kg
3549 lbs.

What is the trunk (boot) capacity of 2005 Nissan Note Hatchback?

280 - 1332 l
9.9 - 47 cu. ft.

What are the number of gears and the gearbox type of 2005 Nissan Note I (E11) 1.5 dCi (86 Hp)?

5, manual transmission

Nissan Note I (E11) 1.5 dCi (86 Hp)

Nissan
- Nissan Note
  - Note I (E11)
    - 1.6i 16V (110 Hp) Automatic
    - 1.6 i 16V (110 Hp)
    - 1.5 dCi (86 Hp)
    - 1.5 dCi (68 Hp)
    - 1.4 i 16V (88 Hp)

Compare

General information

Brand

Nissan

Model

Note

Generation

Note I (E11)

Modification (Engine)

1.5 dCi (86 Hp)

Start of production

2005

End of production

2009

Powertrain Architecture

Internal Combustion engine

Body type

Hatchback

Seats

Doors

Looking for Nissan Note on the used-car market?

Check its history →

Performance specs

Fuel consumption (economy) - urban

5.8 l/100 km 40.6 US mpg
48.7 UK mpg
17.2 km/l

Fuel consumption (economy) - extra urban

4.6 l/100 km 51.1 US mpg
61.4 UK mpg
21.7 km/l

Fuel Type

Diesel

Acceleration 0 - 100 km/h

13 sec

Acceleration 0 - 62 mph

13 sec

Acceleration 0 - 60 mph (Calculated by Auto-Data.net)

12.4 sec

Maximum speed

168 km/h 104 mph

Weight-to-power ratio

13.5 kg/Hp, 73.8 Hp/tonne

Weight-to-torque ratio

5.8 kg/Nm, 171.7 Nm/tonne

Engine specs

Power

86 Hp @ 3750 rpm.

Power per litre

58.9 Hp/l

Torque

200 Nm @ 2000 rpm. 148 lb.-ft. @ 2000 rpm.

Engine layout

Front, Transverse

Engine Model/Code

K9K 276, K9K 400

Engine displacement

1461 cm³ 89.16 cu. in.

Number of cylinders

Engine configuration

Inline

Cylinder Bore

76 mm 2.99 in.

Piston Stroke

80.5 mm 3.17 in.

Compression ratio

18.8:1

Number of valves per cylinder

Fuel injection system

Diesel Commonrail

Engine aspiration

Turbocharger, Intercooler

Valvetrain

OHC

Engine oil capacity

4.4 l 4.65 US qt | 3.87 UK qt

Engine oil specification

Coolant

6 l 6.34 US qt | 5.28 UK qt

Volume and weights

Kerb Weight

1165 kg 2568 lbs.

Max. weight

1610 kg 3549 lbs.

Max load

445 kg 981 lbs.

Trunk (boot) space - minimum

280 l 9.9 cu. ft.

Trunk (boot) space - maximum

1332 l 47 cu. ft.

Fuel tank capacity

46 l 12.15 US gal | 10.12 UK gal

Dimensions

Length

4083 mm 160.75 in.

Width

1690 mm 66.54 in.

Height

1550 mm 61.02 in.

Wheelbase

2600 mm 102.36 in.

Front track

1470 mm 57.87 in.

Rear (Back) track

1460 mm 57.48 in.

Minimum turning circle (turning diameter)

11 m 36.09 ft.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) drives the front wheels of the vehicle.

Drive wheel

Front wheel drive

Number of gears and type of gearbox

5 gears, manual transmission

Front suspension

Suspension strut

Rear suspension

Torsion bar

Front brakes

Disc

Rear brakes

Drum

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Tire size

185/55 R16
