NIO EL8 Standard Range 73.5 kWh (653 Hp) E-AWD | Technical specs, data, battery, electric range, Dimensions

Key specs

NIO EL8 Standard Range 73.5 kWh (653 Hp) E-AWD /SUV 2024 - /

What is the body type of NIO EL8?

SUV, 5 Doors, 6 Seats

What is the all-electric range of Standard Range 73.5 kWh (653 Hp) E-AWD?

375-390 km
233 - 242 mi

What is the electricity consumption of NIO EL8 Standard Range 73.5 kWh (653 Hp) E-AWD?

22.0-23.1 kWh/100 km
35.41 - 37.18 kWh/100 mi
95 - 91 MPGe
4.5 - 4.3 km/kWh
2.8 - 2.7 mi/kWh

How fast is 2024 EL8 Standard Range 73.5 kWh (653 Hp) E-AWD?

200 km/h | 124 mph
0-100 km/h: 4.1 sec
0-60 mph: 3.9 sec

What is the power output of NIO EL8 SUV 2024 Standard Range 73.5 kWh (653 Hp) E-AWD?

653 Hp, 850 Nm
627 lb.-ft.

What is the drivetrain of NIO EL8 SUV 2024 Standard Range 73.5 kWh (653 Hp) E-AWD?

All wheel drive (4x4). BEV (Electric Vehicle). One electric motor drives the front wheels, one electric motor drives the rear wheels.

What is the length of 2024 NIO EL8 SUV?

5099 mm
200.75 in.

What is the width of 2024 NIO EL8 SUV?

2073 mm
81.61 in.

What is the kerb weight of 2024 NIO EL8 Standard Range 73.5 kWh (653 Hp) E-AWD?

2538 kg
5595 lbs.

What is the maximum permissible mass of 2024 NIO EL8 Standard Range 73.5 kWh (653 Hp) E-AWD?

3190 kg
7033 lbs.

What are the number of gears and the gearbox type of 2024 NIO EL8 Standard Range 73.5 kWh (653 Hp) E-AWD?

1, automatic transmission

NIO
- NIO EL8
  - EL8
    - Standard Range 73.5 kWh (653 Hp) E-AWD
    - Long Range 90 kWh (653 Hp) E-AWD

Compare

General information

Brand

NIO

Model

EL8

Generation

EL8

Modification (Engine)

Standard Range 73.5 kWh (653 Hp) E-AWD

Start of production

June, 2024

Powertrain Architecture

BEV (Electric Vehicle)

Body type

SUV

Seats

Doors

Looking for NIO EL8 on the used-car market?

Check its history →

Performance specs

Fuel Type

Electricity

Acceleration 0 - 100 km/h

4.1 sec

Acceleration 0 - 62 mph

4.1 sec

Acceleration 0 - 60 mph (Calculated by Auto-Data.net)

3.9 sec

Maximum speed

200 km/h 124 mph

100 km/h - 0

34.3 m

Weight-to-power ratio

3.9 kg/Hp, 257.3 Hp/tonne

Weight-to-torque ratio

3 kg/Nm, 334.9 Nm/tonne

Electric and hybrid car specs

Net (usable) battery capacity

73.5 kWh

Battery technology

Lithium-ion (Li-Ion)

Battery location

Below the floor

Electric range (WLTP)

375-390 km 233 - 242 mi

Average Energy consumption (WLTP)

22.0-23.1 kWh/100 km 35.41 - 37.18 kWh/100 mi
95 - 91 MPGe
4.5 - 4.3 km/kWh
2.8 - 2.7 mi/kWh

Charging ports

Charging times

Electric motor 1

Electric motor location

Front axle, Transverse

Electric motor type

Synchronous

Electric motor 2

Electric motor location

Rear axle, Transverse

Electric motor type

Asynchronous

System power

653 Hp

System torque

850 Nm 627 lb.-ft.

Volume and weights

Kerb Weight

2538 kg 5595 lbs.

Max. weight

3190 kg 7033 lbs.

Max load

652 kg 1437 lbs.

Max. roof load

75 kg 165 lbs.

Dimensions

Length

5099 mm 200.75 in.

Width with mirrors folded

2073 mm 81.61 in.

Width including mirrors

2199 mm 86.57 in.

Height

1750 mm 68.9 in.

Wheelbase

3070 mm 120.87 in.

Front track

1692 mm 66.61 in.

Rear (Back) track

1702 mm 67.01 in.

Ride height (ground clearance)

160 mm 6.3 in.

Drag coefficient (C_d)

0.25

Minimum turning circle (turning diameter)

12.4 m 40.68 ft.

Approach angle

17°

Departure angle

20°

Ramp-over (breakover) angle

16.6°

Wading depth

450 mm 17.72 in.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

One electric motor drives the front wheels, one electric motor drives the rear wheels.

Drive wheel

All wheel drive (4x4)

Number of gears and type of gearbox

1 gears, automatic transmission

Front suspension

Double wishbone, Air suspension - optional

Rear suspension

Independent multi-link suspension, Air suspension - optional

Front brakes

Ventilated discs

Rear brakes

Ventilated discs

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Electric Steering

Tire size

255/50 R20; 265/45 R21; 265/40 R22

Wheel rim size

20; 21; 22
