Mitsubishi Grandis 2.4 i 16V MIVEC (165 Hp) | Technical specs, data, fuel consumption, Dimensions

Key specs

Mitsubishi Grandis 2.4 i 16V MIVEC (165 Hp) /Minivan 2003 - 2011/

What is the body type of Mitsubishi Grandis?

Minivan, 5 Doors, 7 Seats

What is the fuel consumption and economy of Mitsubishi Grandis 2.4 i 16V MIVEC (165 Hp)?

9.3 l/100 km
25.3 US mpg
30.4 UK mpg
10.8 km/l

How fast is 2003 Grandis 2.4 i 16V MIVEC (165 Hp)?

200 km/h | 124 mph
0-100 km/h: 10 sec
0-60 mph: 9.5 sec

What is the power output of Mitsubishi Grandis Minivan 2003 2.4 i 16V MIVEC (165 Hp)?

165 Hp, 217 Nm
160 lb.-ft.

What is the engine displacement of Mitsubishi Grandis Minivan 2003 2.4 i 16V MIVEC (165 Hp)?

2.4 l
2378 cm³
145.11 cu. in.

What is the number of cylinders in 2003 Mitsubishi 2.4 i 16V MIVEC (165 Hp)?

4, Inline

What is the drivetrain of Mitsubishi Grandis Minivan 2003 2.4 i 16V MIVEC (165 Hp)?

Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle.

What is the length of 2003 Mitsubishi Grandis Minivan?

4765 mm
187.6 in.

What is the width of 2003 Mitsubishi Grandis Minivan?

1795 mm
70.67 in.

What is the kerb weight of 2003 Mitsubishi Grandis 2.4 i 16V MIVEC (165 Hp)?

1645 kg
3627 lbs.

What is the maximum permissible mass of 2003 Mitsubishi Grandis 2.4 i 16V MIVEC (165 Hp)?

2250 kg
4960 lbs.

What are the number of gears and the gearbox type of 2003 Mitsubishi Grandis 2.4 i 16V MIVEC (165 Hp)?

5, manual transmission

Mitsubishi
- Mitsubishi Grandis
  - Grandis
    - 2.4 i 16V MIVEC (165 Hp) Automatic
    - 2.4 i 16V MIVEC (165 Hp)
    - 2.0 DI-D (136 Hp) Automatic
    - 2.0 DI-D (136 Hp)

Compare

General information

Brand

Mitsubishi

Model

Grandis

Generation

Grandis

Modification (Engine)

2.4 i 16V MIVEC (165 Hp)

Start of production

2003

End of production

2011

Powertrain Architecture

Internal Combustion engine

Body type

Minivan

Seats

Doors

Looking for Mitsubishi Grandis on the used-car market?

Check its history →

Performance specs

Fuel consumption (economy) - urban

12.6 l/100 km 18.7 US mpg
22.4 UK mpg
7.9 km/l

Fuel consumption (economy) - extra urban

7.3 l/100 km 32.2 US mpg
38.7 UK mpg
13.7 km/l

Fuel consumption (economy) - combined

9.3 l/100 km 25.3 US mpg
30.4 UK mpg
10.8 km/l

Fuel Type

Petrol (Gasoline)

Acceleration 0 - 100 km/h

10 sec

Acceleration 0 - 62 mph

10 sec

Acceleration 0 - 60 mph (Calculated by Auto-Data.net)

9.5 sec

Maximum speed

200 km/h 124 mph

Weight-to-power ratio

10 kg/Hp, 100.3 Hp/tonne

Weight-to-torque ratio

7.6 kg/Nm, 131.9 Nm/tonne

Engine specs

Power

165 Hp @ 6000 rpm.

Power per litre

69.4 Hp/l

Torque

217 Nm @ 4000 rpm. 160 lb.-ft. @ 4000 rpm.

Engine layout

Front, Transverse

Engine Model/Code

4G69

Engine displacement

2378 cm³ 145.11 cu. in.

Number of cylinders

Engine configuration

Inline

Cylinder Bore

87 mm 3.43 in.

Piston Stroke

100 mm 3.94 in.

Compression ratio

9.5:1

Number of valves per cylinder

Fuel injection system

Multi-port manifold injection

Engine aspiration

Naturally aspirated engine

Valvetrain

DOHC

Engine oil capacity

4.3 l 4.54 US qt | 3.78 UK qt

Engine oil specification

Coolant

8 l 8.45 US qt | 7.04 UK qt

Volume and weights

Kerb Weight

1645 kg 3627 lbs.

Max. weight

2250 kg 4960 lbs.

Max load

605 kg 1334 lbs.

Fuel tank capacity

65 l 17.17 US gal | 14.3 UK gal

Dimensions

Length

4765 mm 187.6 in.

Width

1795 mm 70.67 in.

Height

1655 mm 65.16 in.

Wheelbase

2830 mm 111.42 in.

Front track

1550 mm 61.02 in.

Rear (Back) track

1555 mm 61.22 in.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) drives the front wheels of the vehicle.

Drive wheel

Front wheel drive

Number of gears and type of gearbox

5 gears, manual transmission

Front suspension

Suspension strut

Rear suspension

Anti-roll bar

Front brakes

Ventilated discs

Rear brakes

Disc

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Tire size

215/60 R16

Wheel rim size

6.5J x 16

Specs of Mitsubishi Grandis 2.4 i 16V MIVEC (165 Hp) /2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011/
