Mini Aceman (J05) JCW 54.2 kWh (258 Hp) Electric | Technical specs, data, battery, electric range, Dimensions

Key specs

Mini Aceman (J05) JCW 54.2 kWh (258 Hp) Electric /SUV, Crossover 2025 - /

What is the body type of Mini Aceman (J05)?

SUV, Crossover, 5 Doors, 5 Seats

What is the all-electric range of JCW 54.2 kWh (258 Hp) Electric?

355 km
221 mi

What is the electricity consumption of Mini Aceman (J05) JCW 54.2 kWh (258 Hp) Electric?

16-16.4 kWh/100 km
25.75 - 26.39 kWh/100 mi
131 - 128 MPGe
6.3 - 6.1 km/kWh
3.9 - 3.8 mi/kWh

How fast is 2025 Aceman (J05) JCW 54.2 kWh (258 Hp) Electric?

200 km/h | 124 mph
0-100 km/h: 6.4 sec
0-60 mph: 6.1 sec

What is the power output of Mini Aceman SUV, Crossover 2025 JCW 54.2 kWh (258 Hp) Electric?

258 Hp, 350 Nm
258 lb.-ft.

What is the drivetrain of Mini Aceman (J05) SUV, Crossover 2025 JCW 54.2 kWh (258 Hp) Electric?

Front wheel drive. BEV (Electric Vehicle). One electric motor drives the front wheels.

What is the length of 2025 Mini Aceman SUV, Crossover?

4079 mm
160.59 in.

What is the width of 2025 Mini Aceman SUV, Crossover?

1754 mm
69.06 in.

What is the kerb weight of 2025 Mini Aceman (J05) JCW 54.2 kWh (258 Hp) Electric?

1750 kg
3858 lbs.

What is the maximum permissible mass of 2025 Mini Aceman (J05) JCW 54.2 kWh (258 Hp) Electric?

2355 kg
5192 lbs.

What is the trunk (boot) capacity of 2025 Mini Aceman SUV, Crossover?

300 - 1005 l
10.6 - 35.5 cu. ft.

What is the number of gears in What is the gearbox type of 2025 Mini Aceman (J05) JCW 54.2 kWh (258 Hp) Electric?

1, automatic transmission

Mini
- Mini Aceman
  - Aceman (J05)
    - SE 49.2 kWh (218 Hp) Electric
    - JCW 54.2 kWh (258 Hp) Electric
    - E 38.5 kWh (184 Hp) Electric

Compare

General information

Brand

Mini

Model

Aceman

Generation

Aceman (J05)

Modification (Engine)

JCW 54.2 kWh (258 Hp) Electric

Start of production

January, 2025 year

Powertrain Architecture

BEV (Electric Vehicle)

Body type

SUV, Crossover

Seats

Doors

Looking for Mini Aceman on the used-car market?

Check its history →

Performance specs

Fuel Type

Electricity

Acceleration 0 - 100 km/h

6.4 sec

Acceleration 0 - 62 mph

6.4 sec

Acceleration 0 - 60 mph (Calculated by Auto-Data.net)

6.1 sec

Maximum speed

200 km/h 124 mph

Weight-to-power ratio

6.8 kg/Hp, 147.4 Hp/tonne

Weight-to-torque ratio

5 kg/Nm, 200 Nm/tonne

Electric cars and hybrids specs

Gross battery capacity

54.2 kWh

Net (usable) battery capacity

49.2 kWh

Battery voltage

398.2 V

Battery technology

Lithium-ion (Li-Ion)

Battery location

Below the floor

Electric range (WLTP)

355 km 221 mi

Average Energy consumption (WLTP)

16-16.4 kWh/100 km 25.75 - 26.39 kWh/100 mi
131 - 128 MPGe
6.3 - 6.1 km/kWh
3.9 - 3.8 mi/kWh

Charging ports

Electric motor 1

Electric motor power

258 Hp @ 5000 rpm.

Electric motor Torque

350 Nm @ 50-5000 rpm. 258 lb.-ft. @ 50-5000 rpm.

Electric motor model/code

HC0002N0

Electric motor location

Front axle, Transverse

Electric motor type

Synchronous

System power

258 Hp @ 5000 rpm.

System torque

350 Nm @ 50-5000 rpm. 258 lb.-ft. @ 50-5000 rpm.

Volume and weights

Kerb Weight

1750 kg 3858 lbs.

Max. weight

2355 kg 5192 lbs.

Max load

605 kg 1334 lbs.

Trunk (boot) space - minimum

300 l 10.6 cu. ft.

Trunk (boot) space - maximum

1005 l 35.5 cu. ft.

Max. roof load

75 kg 165 lbs.

Permitted trailer load with brakes (12%)

750 kg 1653 lbs.

Permitted trailer load without brakes

750 kg 1653 lbs.

Dimensions

Length

4079 mm 160.59 in.

Width

1754 mm 69.06 in.

Height

1514 mm 59.61 in.

Wheelbase

2606 mm 102.6 in.

Front track

1519 mm 59.8 in.

Rear (Back) track

1515 mm 59.65 in.

Ride height (ground clearance)

143 mm 5.63 in.

Minimum turning circle (turning diameter)

11.1 m 36.42 ft.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

One electric motor drives the front wheels.

Drive wheel

Front wheel drive

Number of gears and type of gearbox

1 gears, automatic transmission

Front suspension

Suspension strut, Anti-roll bar

Rear suspension

Independent multi-link spring suspension with anti-roll bar

Front brakes

Ventilated discs

Rear brakes

Ventilated discs

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Electric Steering

Tires size

225/40 R19

Wheel rims size

7.5J x 19

Specs of Mini Aceman (J05) JCW 54.2 kWh (258 Hp) Electric /2025, 2026/
