Mercedes-Benz W100 600 V8 (250 Hp) Automatic | Technical specs, data, fuel consumption, Dimensions

Key specs

Mercedes-Benz W100 600 V8 (250 Hp) Automatic /Sedan 1964 - 1981/

What is the body type of Mercedes-Benz W100?

Sedan, 4 Doors, 5-6 Seats

How fast is 1964 W100 600 V8 (250 Hp) Automatic?

205 km/h | 127 mph
0-100 km/h: 9.7 sec
0-60 mph: 9.2 sec

What is the power output of Mercedes-Benz W100 Sedan 1964 600 V8 (250 Hp) Automatic?

250 Hp, 500 Nm
369 lb.-ft.

What is the engine displacement of Mercedes-Benz W100 Sedan 1964 600 V8 (250 Hp) Automatic?

6.3 l
6332 cm³
386.4 cu. in.

What is the number of cylinders in 1964 Mercedes-Benz 600 V8 (250 Hp) Automatic?

8, V-engine

What is the drivetrain of Mercedes-Benz W100 Sedan 1964 600 V8 (250 Hp) Automatic?

Rear wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the rear wheels of the vehicle.

What is the length of 1964 Mercedes-Benz W100 Sedan?

5540 mm
218.11 in.

What is the width of 1964 Mercedes-Benz W100 Sedan?

1950 mm
76.77 in.

What is the kerb weight of 1964 Mercedes-Benz W100 600 V8 (250 Hp) Automatic?

2475 kg
5456 lbs.

What is the maximum permissible mass of 1964 Mercedes-Benz W100 600 V8 (250 Hp) Automatic?

3055 kg
6735 lbs.

What is the trunk (boot) capacity of 1964 Mercedes-Benz W100 Sedan?

580 l
20.5 cu. ft.

What are the number of gears and the gearbox type of 1964 Mercedes-Benz W100 600 V8 (250 Hp) Automatic?

4, automatic transmission

Mercedes-Benz
- Mercedes-Benz W100
  - W100
    - 600 V8 (250 Hp) Automatic

Compare

General information

Brand

Mercedes-Benz

Model

W100

Generation

W100

Modification (Engine)

600 V8 (250 Hp) Automatic

Start of production

September, 1964

End of production

June, 1981

Powertrain Architecture

Internal Combustion engine

Body type

Sedan

Seats

5-6

Doors

Looking for Mercedes-Benz W100 on the used-car market?

Check its history →

Performance specs

Fuel consumption (economy) - extra urban

17.8 l/100 km 13.2 US mpg
15.9 UK mpg
5.6 km/l

Fuel Type

Petrol (Gasoline)

Acceleration 0 - 100 km/h

9.7 sec

Acceleration 0 - 62 mph

9.7 sec

Acceleration 0 - 60 mph (Calculated by Auto-Data.net)

9.2 sec

Maximum speed

205 km/h 127 mph

Weight-to-power ratio

9.9 kg/Hp, 101 Hp/tonne

Weight-to-torque ratio

5 kg/Nm, 202 Nm/tonne

Engine specs

Power

250 Hp @ 4000 rpm.

Power per litre

39.5 Hp/l

Torque

500 Nm @ 2800 rpm. 369 lb.-ft. @ 2800 rpm.

Maximum engine speed

4800 rpm.

Engine layout

Front, Longitudinal

Engine Model/Code

M 100.980

Engine displacement

6332 cm³ 386.4 cu. in.

Number of cylinders

Engine configuration

V-engine

Cylinder Bore

103 mm 4.06 in.

Piston Stroke

95 mm 3.74 in.

Compression ratio

9:1

Number of valves per cylinder

Fuel injection system

Multi-port manifold injection

Engine aspiration

Naturally aspirated engine

Valvetrain

SOHC

Volume and weights

Kerb Weight

2475 kg 5456 lbs.

Max. weight

3055 kg 6735 lbs.

Max load

580 kg 1279 lbs.

Trunk (boot) space - minimum

580 l 20.5 cu. ft.

Fuel tank capacity

112 l 29.59 US gal | 24.64 UK gal

Dimensions

Length

5540 mm 218.11 in.

Width

1950 mm 76.77 in.

Height

1485 mm 58.46 in.

Wheelbase

3200 mm 125.98 in.

Front track

1587 mm 62.48 in.

Rear (Back) track

1581 mm 62.24 in.

Ride height (ground clearance)

200-250 mm 7.87 - 9.84 in.

Minimum turning circle (turning diameter)

12.4 m 40.68 ft.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) drives the rear wheels of the vehicle.

Drive wheel

Rear wheel drive

Number of gears and type of gearbox

4 gears, automatic transmission

Front suspension

Double wishbone, Anti-roll bar, Air suspension

Rear suspension

Air suspension, Anti-roll bar

Front brakes

Disc

Rear brakes

Disc

Steering type

Recirculating-ball steering

Power steering

Hydraulic Steering

Wheel rim size

6.5J x 15

Specs of Mercedes-Benz W100 600 V8 (250 Hp) Automatic /1964, 1965, 1966, 1967, 1968, 1969, 1970, 1971, 1972, 1973, 1974, 1975, 1976, 1977, 1978, 1979, 1980, 1981/
