| What is the body type, Mercedes-Benz G-class Long (W463)? | Off-road vehicle, 5 Doors, 5 Seats |
|---|---|
| How ECO is the car, Mercedes-Benz G-class 500 GE V8 (241 Hp) 4MATIC Automatic? | Euro 1 |
| How fast is the car, 1993 G-class Long (W463) 500 GE V8 (241 Hp) 4MATIC Automatic? | 175 km/h | 108.74 mph 0-100 km/h: 10.5 sec 0-60 mph: 10 sec |
| How much power, Mercedes-Benz G-class Off-road vehicle 1993 500 GE V8 (241 Hp) 4MATIC Automatic? | 241 Hp, 375 Nm 276.59 lb.-ft. |
| What is the engine size, Mercedes-Benz G-class Off-road vehicle 1993 500 GE V8 (241 Hp) 4MATIC Automatic? | 5.0 l 4973 cm3 303.47 cu. in. |
| How many cylinders, 1993 Mercedes-Benz 500 GE V8 (241 Hp) 4MATIC Automatic? | 8, V-engine |
| What is the drivetrain, Mercedes-Benz G-class Long (W463) Off-road vehicle 1993 500 GE V8 (241 Hp) 4MATIC Automatic? | All wheel drive (4x4). Internal Combustion engine. The Internal combustion engine (ICE) drives permanently the four wheels of the vehicle. |
| How long is this vehicle, 1993 Mercedes-Benz G-class Off-road vehicle? | 4670 mm 183.86 in. |
| How wide is the vehicle, 1993 Mercedes-Benz G-class Off-road vehicle? | 1810 mm 71.26 in. |
| What is the curb weight, 1993 Mercedes-Benz G-class Long (W463) 500 GE V8 (241 Hp) 4MATIC Automatic? | 2370 kg 5224.96 lbs. |
| What is the gross weight, 1993 Mercedes-Benz G-class Long (W463) 500 GE V8 (241 Hp) 4MATIC Automatic? | 3050 kg 6724.1 lbs. |
| How much trunk (boot) space, 1993 Mercedes-Benz G-class Off-road vehicle? | 480 - 2250 l 16.95 - 79.46 cu. ft. |
| How many gears, What type is the gearbox, 1993 Mercedes-Benz G-class Long (W463) 500 GE V8 (241 Hp) 4MATIC Automatic? | 4, automatic transmission |
| General information | |
|---|---|
| Brand | Mercedes-Benz |
| Model | G-class |
| Generation | G-class Long (W463) |
| Modification (Engine) | 500 GE V8 (241 Hp) 4MATIC Automatic |
| Start of production | January, 1993 year |
| End of production | December, 1993 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Off-road vehicle |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 - 100 km/h | 10.5 sec |
| Acceleration 0 - 62 mph | 10.5 sec |
| Acceleration 0 - 60 mph (Calculated by Auto-Data.net) | 10 sec |
| Maximum speed | 175 km/h 108.74 mph |
| Emission standard | Euro 1 |
| Weight-to-power ratio | 9.8 kg/Hp, 101.7 Hp/tonne |
| Weight-to-torque ratio | 6.3 kg/Nm, 158.2 Nm/tonne |
| Engine specs | |
| Power | 241 Hp @ 5000 rpm. |
| Power per litre | 48.5 Hp/l |
| Torque | 375 Nm @ 3500 rpm. 276.59 lb.-ft. @ 3500 rpm. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | M 117.965 |
| Engine displacement | 4973 cm3 303.47 cu. in. |
| Number of cylinders | 8 |
| Engine configuration | V-engine |
| Cylinder Bore | 96.5 mm 3.8 in. |
| Piston Stroke | 85 mm 3.35 in. |
| Compression ratio | 10:1 |
| Number of valves per cylinder | 2 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | SOHC |
| Engine oil capacity | 8.2 l 8.66 US qt | 7.21 UK qt |
| Engine oil specification |  Log in to see. |
| Space, Volume and weights | |
| Kerb Weight | 2370 kg 5224.96 lbs. |
| Max. weight | 3050 kg 6724.1 lbs. |
| Max load | 680 kg 1499.14 lbs. |
| Trunk (boot) space - minimum | 480 l 16.95 cu. ft. |
| Trunk (boot) space - maximum | 2250 l 79.46 cu. ft. |
| Fuel tank capacity | 96 l 25.36 US gal | 21.12 UK gal |
| Max. roof load | 200 kg 440.92 lbs. |
| Permitted trailer load with brakes (12%) | 3050 kg 6724.1 lbs. |
| Permitted trailer load without brakes | 750 kg 1653.47 lbs. |
| Dimensions | |
| Length | 4670 mm 183.86 in. |
| Width | 1810 mm 71.26 in. |
| Height | 1963 mm 77.28 in. |
| Wheelbase | 2850 mm 112.2 in. |
| Front track | 1475 mm 58.07 in. |
| Rear (Back) track | 1475 mm 58.07 in. |
| Ride height (ground clearance) | 210 mm 8.27 in. |
| Minimum turning circle (turning diameter) | 13.3 m 43.64 ft. |
| Approach angle | 36° |
| Departure angle | 27° |
| Climb angle | 38.7° |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives permanently the four wheels of the vehicle. |
| Drive wheel | All wheel drive (4x4) |
| Number of gears and type of gearbox | 4 gears, automatic transmission |
| Front suspension | Coil spring, Rigid axle suspension, Trailing arm |
| Rear suspension | Rigid axle suspension, Trailing arm, Coil spring |
| Front brakes | Ventilated discs |
| Rear brakes | Drum |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Cone worm with recirculation balls |
| Power steering | Hydraulic Steering |
| Tires size | 265/70 R 16 |
| Wheel rims size | 7.5 J x 16 |
