Mercedes-Benz A124 300 CE-24 CAT (220 Hp) | Technical specs, data, fuel consumption, Dimensions

Key specs

Mercedes-Benz A124 300 CE-24 CAT (220 Hp) /Cabriolet 1990 - 1993/

What is the body type of Mercedes-Benz A124?

Cabriolet, 2 Doors, 4 Seats

How fast is 1990 A124 300 CE-24 CAT (220 Hp)?

235 km/h | 146 mph
0-100 km/h: 9 sec
0-60 mph: 8.6 sec

What is the power output of Mercedes-Benz W124 Cabriolet 1990 300 CE-24 CAT (220 Hp)?

220 Hp, 265 Nm
195 lb.-ft.

What is the engine displacement of Mercedes-Benz W124 Cabriolet 1990 300 CE-24 CAT (220 Hp)?

3.0 l
2960 cm³
180.63 cu. in.

What is the number of cylinders in 1990 Mercedes-Benz 300 CE-24 CAT (220 Hp)?

6, Inline

What is the drivetrain of Mercedes-Benz A124 Cabriolet 1990 300 CE-24 CAT (220 Hp)?

Rear wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the rear wheels of the vehicle.

What is the length of 1990 Mercedes-Benz W124 Cabriolet?

4655 mm
183.27 in.

What is the width of 1990 Mercedes-Benz W124 Cabriolet?

1740 mm
68.5 in.

What is the kerb weight of 1990 Mercedes-Benz A124 300 CE-24 CAT (220 Hp)?

1710 kg
3770 lbs.

What is the maximum permissible mass of 1990 Mercedes-Benz A124 300 CE-24 CAT (220 Hp)?

2160 kg
4762 lbs.

What is the number of gears in What is the gearbox type of 1990 Mercedes-Benz A124 300 CE-24 CAT (220 Hp)?

5, manual transmission

Mercedes-Benz
- Mercedes-Benz W124
  - A124
    - 300 CE-24 CAT (220 Hp) Automatic
    - 300 CE-24 CAT (220 Hp)

Compare

General information

Brand

Mercedes-Benz

Model

W124

Generation

A124

Modification (Engine)

300 CE-24 CAT (220 Hp)

Start of production

August, 1990 year

End of production

July, 1993 year

Powertrain Architecture

Internal Combustion engine

Body type

Cabriolet

Seats

Doors

Performance specs

Fuel consumption (economy) - urban

15.4 l/100 km 15.3 US mpg
18.3 UK mpg
6.5 km/l

Fuel consumption (economy) - extra urban

8.6 l/100 km 27.4 US mpg
32.8 UK mpg
11.6 km/l

Fuel Type

Petrol (Gasoline)

Acceleration 0 - 100 km/h

9 sec

Acceleration 0 - 62 mph

9 sec

Acceleration 0 - 60 mph (Calculated by Auto-Data.net)

8.6 sec

Maximum speed

235 km/h 146 mph

Weight-to-power ratio

7.8 kg/Hp, 128.7 Hp/tonne

Weight-to-torque ratio

6.5 kg/Nm, 155 Nm/tonne

Engine specs

Power

220 Hp @ 6400 rpm.

Power per litre

74.3 Hp/l

Torque

265 Nm @ 4600 rpm. 195 lb.-ft. @ 4600 rpm.

Engine layout

Front, Longitudinal

Engine Model/Code

M 104 E 30 / 104.980

Engine displacement

2960 cm³ 180.63 cu. in.

Number of cylinders

Engine configuration

Inline

Cylinder Bore

88.5 mm 3.48 in.

Piston Stroke

80.2 mm 3.16 in.

Compression ratio

10:1

Number of valves per cylinder

Fuel injection system

Multi-port manifold injection

Engine aspiration

Naturally aspirated engine

Valvetrain

DOHC

Engine oil capacity

6.5 l 6.87 US qt | 5.72 UK qt

Engine oil specification

Coolant

9 l 9.51 US qt | 7.92 UK qt

Volume and weights

Kerb Weight

1710 kg 3770 lbs.

Max. weight

2160 kg 4762 lbs.

Max load

450 kg 992 lbs.

Fuel tank capacity

70 l 18.49 US gal | 15.4 UK gal

Dimensions

Length

4655 mm 183.27 in.

Width

1740 mm 68.5 in.

Height

1391 mm 54.76 in.

Wheelbase

2715 mm 106.89 in.

Front track

1501 mm 59.09 in.

Rear (Back) track

1491 mm 58.7 in.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) drives the rear wheels of the vehicle.

Drive wheel

Rear wheel drive

Number of gears and type of gearbox

5 gears, manual transmission

Front suspension

Wishbone

Rear suspension

Independent multi-link suspension

Front brakes

Ventilated discs

Rear brakes

Disc

Assisting systems

ABS (Anti-lock braking system)

Steering type

Cone worm with recirculation balls

Power steering

Hydraulic Steering

Tires size

Front wheel tires: 195/65 R15
Rear wheel tires: 195/65 R15

Wheel rims size

Front wheel rims: 6.5J x 15
Rear wheel rims: 6.5J x 15

Specs of Mercedes-Benz A124 300 CE-24 CAT (220 Hp) /1990, 1991, 1992, 1993/
