McLaren F1 GTR 6.1 V12 (600 Hp) | Technical specs, data, fuel consumption, Dimensions

Key specs

McLaren F1 GTR 6.1 V12 (600 Hp) /Coupe 1996 - 1996/

What is the body type of McLaren F1 GTR?

Coupe, 2 Doors, 1 Seats

How fast is 1996 F1 GTR 6.1 V12 (600 Hp)?

330 km/h | 205 mph

What is the power output of McLaren F1 Coupe 1996 6.1 V12 (600 Hp)?

600 Hp, 527 Nm
389 lb.-ft.

What is the engine displacement of McLaren F1 Coupe 1996 6.1 V12 (600 Hp)?

6.1 l
6064 cm³
370.05 cu. in.

What is the number of cylinders in 1996 McLaren 6.1 V12 (600 Hp)?

12, V-engine

What is the drivetrain of McLaren F1 GTR Coupe 1996 6.1 V12 (600 Hp)?

Rear wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the rear wheels of the vehicle.

What is the length of 1996 McLaren F1 Coupe?

4367 mm
171.93 in.

What is the width of 1996 McLaren F1 Coupe?

1900 mm
74.8 in.

What is the kerb weight of 1996 McLaren F1 GTR 6.1 V12 (600 Hp)?

1012 kg
2231 lbs.

What are the number of gears and the gearbox type of 1996 McLaren F1 GTR 6.1 V12 (600 Hp)?

6, manual transmission

McLaren
- McLaren F1
  - F1 GTR
    - 6.1 V12 (600 Hp)
    - 6.1 V12 (600 Hp)
    - 6.0 V12 (600 Hp)

Compare

General information

Brand

McLaren

Model

Generation

F1 GTR

Modification (Engine)

6.1 V12 (600 Hp)

Start of production

1996

End of production

1996

Powertrain Architecture

Internal Combustion engine

Body type

Coupe

Seats

Doors

Looking for McLaren F1 on the used-car market?

Check its history →

Performance specs

Fuel Type

Petrol (Gasoline)

Maximum speed

330 km/h 205 mph

Weight-to-power ratio

1.7 kg/Hp, 592.9 Hp/tonne

Weight-to-torque ratio

1.9 kg/Nm, 520.8 Nm/tonne

Engine specs

Power

600 Hp @ 7500 rpm.

Power per litre

98.9 Hp/l

Torque

527 Nm @ 5600 rpm. 389 lb.-ft. @ 5600 rpm.

Engine layout

Middle, Longitudinal

Engine Model/Code

S70/2

Engine displacement

6064 cm³ 370.05 cu. in.

Number of cylinders

Engine configuration

V-engine

Cylinder Bore

86 mm 3.39 in.

Piston Stroke

87 mm 3.43 in.

Compression ratio

11:1

Number of valves per cylinder

Fuel injection system

Multi-port manifold injection

Engine aspiration

Naturally aspirated engine

Valvetrain

DOHC

Engine oil specification

Volume and weights

Kerb Weight

1012 kg 2231 lbs.

Fuel tank capacity

100 l 26.42 US gal | 22 UK gal

Dimensions

Length

4367 mm 171.93 in.

Width

1900 mm 74.8 in.

Height

1090 mm 42.91 in.

Wheelbase

2718 mm 107.01 in.

Front track

1558 mm 61.34 in.

Rear (Back) track

1488 mm 58.58 in.

Front overhang

1050 mm 41.34 in.

Rear overhang

599 mm 23.58 in.

Ride height (ground clearance)

60 mm 2.36 in.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) drives the rear wheels of the vehicle.

Drive wheel

Rear wheel drive

Number of gears and type of gearbox

6 gears, manual transmission

Front suspension

Coil spring, Double wishbone, Anti-roll bar

Rear suspension

Double wishbone, Coil spring

Front brakes

Ventilated discs, 380x36 mm

Rear brakes

Ventilated discs, 355x36 mm

Steering type

Steering rack and pinion

Wheel rim size
