Mazda EZ-60 77.94 kWh (258 Hp) Electric | Technical Specs, Battery, Electric range, Dimensions

Key specs

Mazda EZ-60 77.94 kWh (258 Hp) Electric /SUV 2025 - /

What is the body type of Mazda EZ-60?

SUV, 5 Doors, 5 Seats

What is the all-electric range of 77.94 kWh (258 Hp) Electric?

600 km
373 mi

What is the electricity consumption of Mazda EZ-60 77.94 kWh (258 Hp) Electric?

14.7 kWh/100 km
23.66 kWh/100 mi
142 MPGe
6.8 km/kWh
4.2 mi/kWh

How fast is 2025 EZ-60 77.94 kWh (258 Hp) Electric?

185 km/h | 115 mph

What is the power output of Mazda EZ-60 SUV 2025 77.94 kWh (258 Hp) Electric?

258 Hp, 290 Nm
214 lb.-ft.

What is the drivetrain of Mazda EZ-60 SUV 2025 77.94 kWh (258 Hp) Electric?

Rear wheel drive. BEV. One electric motor drives the rear wheels.

What is the length of 2025 Mazda EZ-60 SUV?

4850 mm
190.94 in.

What is the width of 2025 Mazda EZ-60 SUV?

1935 mm
76.18 in.

What is the kerb weight of 2025 Mazda EZ-60 77.94 kWh (258 Hp) Electric?

2180 kg
4806 lbs.

What is the maximum permissible mass of 2025 Mazda EZ-60 77.94 kWh (258 Hp) Electric?

2590 kg
5710 lbs.

What is the trunk (boot) capacity of 2025 Mazda EZ-60 SUV?

549 - 2036 l
19.4 - 71.9 cu. ft.

What are the number of gears and the gearbox type of 2025 Mazda EZ-60 77.94 kWh (258 Hp) Electric?

1, automatic transmission

Mazda EZ-60 77.94 kWh (258 Hp) Electric

Mazda
- Mazda EZ-60
  - EZ-60
    - 77.94 kWh (258 Hp) Electric
    - 1.5 31.37 kWh (258 Hp) Extended Range

Compare

General information

Brand

Mazda

Model

EZ-60

Generation

EZ-60

Modification (Engine)

77.94 kWh (258 Hp) Electric

Start of production

September, 2025

Powertrain Architecture

BEV (Electric Vehicle)

Body type

SUV (Sport Utility Vehicle)

Seats

Doors

Looking for Mazda EZ-60 on the used-car market?

Check its history →

Performance specs

Fuel Type

Electricity

Maximum speed

185 km/h 115 mph

Weight-to-power ratio

8.4 kg/Hp, 118.3 Hp/tonne

Weight-to-torque ratio

7.5 kg/Nm, 133 Nm/tonne

Electric and hybrid car specs

Gross battery capacity

77.94 kWh

Battery technology

Lithium iron phosphate (LiFePO₄)

Battery location

Below the floor

Electric range (CLTC)

600 km 373 mi

Average Energy consumption (CLTC)

14.7 kWh/100 km 23.66 kWh/100 mi
142 MPGe
6.8 km/kWh
4.2 mi/kWh

Charging ports

Charging times

Electric motor 1

Electric motor power

258 Hp

Electric motor Torque

290 Nm 214 lb.-ft.

Electric motor model/code

MSED08

Electric motor location

Rear axle, Transverse

Electric motor type

Synchronous

System power

258 Hp

System torque

290 Nm 214 lb.-ft.

Volume and weights

Kerb Weight

2180 kg 4806 lbs.

Max. weight

2590 kg 5710 lbs.

Max load

410 kg 904 lbs.

Trunk (boot) space - minimum

549 l 19.4 cu. ft.

Trunk (boot) space - maximum

2036 l 71.9 cu. ft.

Dimensions

Length

4850 mm 190.94 in.

Width

1935 mm 76.18 in.

Height

1620 mm 63.78 in.

Wheelbase

2902 mm 114.25 in.

Front track

1643 mm 64.69 in.

Rear (Back) track

1652 mm 65.04 in.

Approach angle

16°

Departure angle

20°

Drivetrain, brakes and suspension specs

Drivetrain Architecture

One electric motor drives the rear wheels.

Drive wheel

Rear wheel drive

Number of gears and type of gearbox

1 gears, automatic transmission

Front suspension

Independent, McPherson type with coil spring and anti-roll bar

Rear suspension

Independent multi-link spring suspension with anti-roll bar

Front brakes

Ventilated discs

Rear brakes

Disc

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Electric Steering

Tire size

235/55 R19; 255/40 R21

Wheel rim size

19; 21
