Mazda 5 II 2.5 (157 Hp) Automatic | Technical specs, data, fuel consumption, Dimensions

Key specs

Mazda 5 II 2.5 (157 Hp) Automatic /Minivan 2011 - 2017/

What is the body type of Mazda 5 II?

Minivan, 5 Doors, 6 Seats

What is the power output of Mazda 5 Minivan 2011 2.5 (157 Hp) Automatic?

157 Hp, 221 Nm
163 lb.-ft.

What is the engine displacement of Mazda 5 Minivan 2011 2.5 (157 Hp) Automatic?

2.5 l
2489 cm³
151.89 cu. in.

What is the number of cylinders in 2011 Mazda 2.5 (157 Hp) Automatic?

4, Inline

What is the drivetrain of Mazda 5 II Minivan 2011 2.5 (157 Hp) Automatic?

Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle.

What is the length of 2011 Mazda 5 Minivan?

4585 mm
180.51 in.

What is the width of 2011 Mazda 5 Minivan?

1750 mm
68.9 in.

What is the kerb weight of 2011 Mazda 5 II 2.5 (157 Hp) Automatic?

1568-1578 kg
3457 - 3479 lbs.

What is the maximum permissible mass of 2011 Mazda 5 II 2.5 (157 Hp) Automatic?

2125 kg
4685 lbs.

What is the trunk (boot) capacity of 2011 Mazda 5 Minivan?

1257 l
44.4 cu. ft.

What are the number of gears and the gearbox type of 2011 Mazda 5 II 2.5 (157 Hp) Automatic?

5, automatic transmission

Mazda
- Mazda 5
  - 5 II
    - 2.5 (157 Hp) Automatic
    - 2.5 (157 Hp)
    - 2.0i (150 Hp)
    - 2.0i (144 Hp) Automatic
    - 1.8i (115 Hp)
    - 1.6 CD (115 Hp)

Compare

General information

Brand

Mazda

Model

Generation

5 II

Modification (Engine)

2.5 (157 Hp) Automatic

Start of production

2011

End of production

2017

Powertrain Architecture

Internal Combustion engine

Body type

Minivan

Seats

Doors

Looking for Mazda 5 on the used-car market?

Check its history →

Performance specs

Fuel consumption (economy) - urban (EPA)

11.2 l/100 km 21 US mpg
25.2 UK mpg
8.9 km/l

Fuel consumption (economy) - extra urban (EPA)

8.4 l/100 km 28 US mpg
33.6 UK mpg
11.9 km/l

Fuel Type

Petrol (Gasoline)

Weight-to-power ratio

10 kg/Hp, 100.1 Hp/tonne

Weight-to-torque ratio

7.1 kg/Nm, 140.9 Nm/tonne

Engine specs

Power

157 Hp @ 6000 rpm.

Power per litre

63.1 Hp/l

Torque

221 Nm @ 4000 rpm. 163 lb.-ft. @ 4000 rpm.

Maximum engine speed

6200 rpm.

Engine layout

Front, Transverse

Engine Model/Code

L5-VE

Engine displacement

2489 cm³ 151.89 cu. in.

Number of cylinders

Engine configuration

Inline

Cylinder Bore

89 mm 3.5 in.

Piston Stroke

100 mm 3.94 in.

Compression ratio

9.7:1

Number of valves per cylinder

Fuel injection system

Multi-port manifold injection

Engine aspiration

Naturally aspirated engine

Valvetrain

DOHC, VVT

Engine oil capacity

5 l 5.28 US qt | 4.4 UK qt

Engine oil specification

Coolant

6.6 l 6.97 US qt | 5.81 UK qt

Volume and weights

Kerb Weight

1568-1578 kg 3457 - 3479 lbs.

Max. weight

2125 kg 4685 lbs.

Max load

547-557 kg 1206 - 1228 lbs.

Trunk (boot) space - minimum

1257 l 44.4 cu. ft.

Fuel tank capacity

60 l 15.85 US gal | 13.2 UK gal

Dimensions

Length

4585 mm 180.51 in.

Width

1750 mm 68.9 in.

Height

1615 mm 63.58 in.

Wheelbase

2750 mm 108.27 in.

Front track

1530 mm 60.24 in.

Rear (Back) track

1520 mm 59.84 in.

Ride height (ground clearance)

140 mm 5.51 in.

Minimum turning circle (turning diameter)

11.2 m 36.75 ft.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) drives the front wheels of the vehicle.

Drive wheel

Front wheel drive

Number of gears and type of gearbox

5 gears, automatic transmission

Front suspension

Independent, McPherson type with coil spring and anti-roll bar

Rear suspension

Independent multi-link spring suspension with anti-roll bar

Front brakes

Ventilated discs, 300 mm

Rear brakes

Disc, 302 mm

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Electric Steering

Tire size

205/55 R16; 205/50 R17

Wheel rim size

6.5J x 16; 6.5J x 17

Specs of Mazda 5 II 2.5 (157 Hp) Automatic /2011, 2012, 2013, 2014, 2015, 2016, 2017/
