Lynk & Co Z20 61.47 kWh (340 Hp) | Technical specs, data, battery, electric range, Dimensions

Key specs

Lynk & Co Z20 61.47 kWh (340 Hp) /SUV 2024 - /

What is the body type of Lynk & Co Z20?

SUV, 5 Doors, 5 Seats

What is the all-electric range of 61.47 kWh (340 Hp)?

530 km
329 mi

What is the electricity consumption of Lynk & Co Z20 61.47 kWh (340 Hp)?

12.9 kWh/100 km
20.76 kWh/100 mi
162 MPGe
7.8 km/kWh
4.8 mi/kWh

How fast is 2024 Z20 61.47 kWh (340 Hp)?

190 km/h | 118 mph
0-100 km/h: 5.3 sec
0-60 mph: 5 sec

What is the power output of Lynk & Co Z20 SUV 2024 61.47 kWh (340 Hp)?

340 Hp, 373 Nm
275 lb.-ft.

What is the drivetrain of Lynk & Co Z20 SUV 2024 61.47 kWh (340 Hp)?

Rear wheel drive. BEV (Electric Vehicle). One electric motor drives the rear wheels.

What is the length of 2024 Lynk & Co Z20 SUV?

4460 mm
175.59 in.

What is the width of 2024 Lynk & Co Z20 SUV?

1845 mm
72.64 in.

What is the kerb weight of 2024 Lynk & Co Z20 61.47 kWh (340 Hp)?

1899-1919 kg
4187 - 4231 lbs.

What is the maximum permissible mass of 2024 Lynk & Co Z20 61.47 kWh (340 Hp)?

2310 kg
5093 lbs.

What is the trunk (boot) capacity of 2024 Lynk & Co Z20 SUV?

450 - 1410 l
15.9 - 49.8 cu. ft.

What is the number of gears in What is the gearbox type of 2024 Lynk & Co Z20 61.47 kWh (340 Hp)?

1, automatic transmission

Lynk & Co
- Lynk & Co Z20
  - Z20
    - 61.47 kWh (340 Hp)
    - 51.2 kWh (238 Hp)

Compare

General information

Brand

Lynk & Co

Model

Z20

Generation

Z20

Modification (Engine)

61.47 kWh (340 Hp)

Start of production

December, 2024 year

Powertrain Architecture

BEV (Electric Vehicle)

Body type

SUV

Seats

Doors

Looking for Lynk & Co Z20 on the used-car market?

Check its history →

Performance specs

Fuel Type

Electricity

Acceleration 0 - 100 km/h

5.3 sec

Acceleration 0 - 62 mph

5.3 sec

Acceleration 0 - 60 mph (Calculated by Auto-Data.net)

5 sec

Maximum speed

190 km/h 118 mph

Weight-to-power ratio

5.6 kg/Hp, 179 Hp/tonne

Weight-to-torque ratio

5.1 kg/Nm, 196.4 Nm/tonne

Electric cars and hybrids specs

Gross battery capacity

61.47 kWh

Battery technology

Lithium iron phosphate (LiFePO₄)

Battery location

Below the floor

Electric range (CLTC)

530 km 329 mi

Average Energy consumption (CLTC)

12.9 kWh/100 km 20.76 kWh/100 mi
162 MPGe
7.8 km/kWh
4.8 mi/kWh

Charging ports

Electric motor 1

Electric motor power

340 Hp

Electric motor Torque

373 Nm 275 lb.-ft.

Electric motor model/code

TZ220XYA01

Electric motor location

Rear axle, Transverse

Electric motor type

Synchronous

System power

340 Hp

System torque

373 Nm 275 lb.-ft.

Volume and weights

Kerb Weight

1899-1919 kg 4187 - 4231 lbs.

Max. weight

2310 kg 5093 lbs.

Max load

391-411 kg 862 - 906 lbs.

Trunk (boot) space - minimum

450 l 15.9 cu. ft.

Trunk (boot) space - maximum

1410 l 49.8 cu. ft.

Dimensions

Length

4460 mm 175.59 in.

Width

1845 mm 72.64 in.

Height

1573 mm 61.93 in.

Wheelbase

2755 mm 108.46 in.

Front track

1595 mm 62.8 in.

Rear (Back) track

1600 mm 62.99 in.

Ride height (ground clearance)

191 mm 7.52 in.

Drag coefficient (C_d)

0.25

Approach angle

18°

Departure angle

21°

Drivetrain, brakes and suspension specs

Drivetrain Architecture

One electric motor drives the rear wheels.

Drive wheel

Rear wheel drive

Number of gears and type of gearbox

1 gears, automatic transmission

Front suspension

Independent, McPherson type with coil spring and anti-roll bar

Rear suspension

Independent multi-link spring suspension with anti-roll bar

Front brakes

Ventilated discs

Rear brakes

Ventilated discs

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Electric Steering

Tires size

235/50 R19; 245/45 R20

Wheel rims size

19; 20

Specs of Lynk & Co Z20 61.47 kWh (340 Hp) /2024, 2025, 2026/
