Lotus Elan II (M100) 1.6 i 16V (132 Hp) | Technical specs, data, fuel consumption, Dimensions

Key specs

Lotus Elan II (M100) 1.6 i 16V (132 Hp) /Cabriolet 1991 - 1993/

What is the body type of Lotus Elan II (M100)?

Cabriolet, 2 Doors, 2 Seats

What is the fuel consumption and economy of Lotus Elan II (M100) 1.6 i 16V (132 Hp)?

8 l/100 km
29.4 US mpg
35.3 UK mpg
12.5 km/l

How fast is 1991 Elan II (M100) 1.6 i 16V (132 Hp)?

196 km/h | 122 mph
0-100 km/h: 8.2 sec
0-60 mph: 7.8 sec

What is the power output of Lotus Elan Cabriolet 1991 1.6 i 16V (132 Hp)?

132 Hp, 142 Nm
105 lb.-ft.

What is the engine displacement of Lotus Elan Cabriolet 1991 1.6 i 16V (132 Hp)?

1.6 l
1588 cm³
96.91 cu. in.

What is the number of cylinders in 1991 Lotus 1.6 i 16V (132 Hp)?

4, Inline

What is the drivetrain of Lotus Elan II (M100) Cabriolet 1991 1.6 i 16V (132 Hp)?

Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle.

What is the length of 1991 Lotus Elan Cabriolet?

3900 mm
153.54 in.

What is the width of 1991 Lotus Elan Cabriolet?

1735 mm
68.31 in.

What is the kerb weight of 1991 Lotus Elan II (M100) 1.6 i 16V (132 Hp)?

995 kg
2194 lbs.

What is the number of gears in What is the gearbox type of 1991 Lotus Elan II (M100) 1.6 i 16V (132 Hp)?

5, manual transmission

Lotus
- Lotus Elan
  - Elan II (M100)
    - 1.6 i 16V Turbo (167 Hp)
    - 1.6 i 16V S2 (158 Hp)
    - 1.6 i 16V (132 Hp)

Compare

General information

Brand

Lotus

Model

Elan

Generation

Elan II (M100)

Modification (Engine)

1.6 i 16V (132 Hp)

Start of production

1991 year

End of production

1993 year

Powertrain Architecture

Internal Combustion engine

Body type

Cabriolet

Seats

Doors

Looking for Lotus Elan on the used-car market?

Check its history →

Performance specs

Fuel consumption (economy) - urban

10.9 l/100 km 21.6 US mpg
25.9 UK mpg
9.2 km/l

Fuel consumption (economy) - extra urban

6.9 l/100 km 34.1 US mpg
40.9 UK mpg
14.5 km/l

Fuel consumption (economy) - combined

8 l/100 km 29.4 US mpg
35.3 UK mpg
12.5 km/l

Fuel Type

Petrol (Gasoline)

Acceleration 0 - 100 km/h

8.2 sec

Acceleration 0 - 62 mph

8.2 sec

Acceleration 0 - 60 mph (Calculated by Auto-Data.net)

7.8 sec

Maximum speed

196 km/h 122 mph

Weight-to-power ratio

7.5 kg/Hp, 132.7 Hp/tonne

Weight-to-torque ratio

7 kg/Nm, 142.7 Nm/tonne

Engine specs

Power

132 Hp @ 7200 rpm.

Power per litre

83.1 Hp/l

Torque

142 Nm @ 4200 rpm. 105 lb.-ft. @ 4200 rpm.

Engine layout

Front, Transverse

Engine Model/Code

4XE1-M

Engine displacement

1588 cm³ 96.91 cu. in.

Number of cylinders

Engine configuration

Inline

Cylinder Bore

80 mm 3.15 in.

Piston Stroke

79 mm 3.11 in.

Compression ratio

10:1

Number of valves per cylinder

Fuel injection system

Multi-port manifold injection

Engine aspiration

Naturally aspirated engine

Valvetrain

DOHC

Engine oil capacity

3.5 l 3.7 US qt | 3.08 UK qt

Engine oil specification

Coolant

6.25 l 6.6 US qt | 5.5 UK qt

Volume and weights

Kerb Weight

995 kg 2194 lbs.

Fuel tank capacity

46 l 12.15 US gal | 10.12 UK gal

Dimensions

Length

3900 mm 153.54 in.

Width

1735 mm 68.31 in.

Height

1230 mm 48.43 in.

Wheelbase

2250 mm 88.58 in.

Front track

1485 mm 58.46 in.

Rear (Back) track

1485 mm 58.46 in.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) drives the front wheels of the vehicle.

Drive wheel

Front wheel drive

Number of gears and type of gearbox

5 gears, manual transmission

Front suspension

Coil spring

Rear suspension

Coil spring

Front brakes

Ventilated discs

Rear brakes

Ventilated discs

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Hydraulic Steering

Tires size

205/50 R15

Wheel rims size

Specs of Lotus Elan II (M100) 1.6 i 16V (132 Hp) /1991, 1992, 1993/
