Lancia Phedra 2.2 Multijet (170 Hp) Automatic | Technical specs, data, fuel consumption, Dimensions

Key specs

Lancia Phedra 2.2 Multijet (170 Hp) Automatic /Minivan 2008 - 2010/

What is the body type of Lancia Phedra?

Minivan, 5 Doors, 8 Seats

What is the fuel consumption and economy of Lancia Phedra 2.2 Multijet (170 Hp) Automatic?

8.2 l/100 km
28.7 US mpg
34.4 UK mpg
12.2 km/l

How environmentally friendly is Lancia Phedra 2.2 Multijet (170 Hp) Automatic?

218 g/km CO₂
Euro 4

How fast is 2008 Phedra 2.2 Multijet (170 Hp) Automatic?

197 km/h | 122 mph
0-100 km/h: 10.8 sec
0-60 mph: 10.3 sec

What is the power output of Lancia Phedra Minivan 2008 2.2 Multijet (170 Hp) Automatic?

170 Hp, 370 Nm
273 lb.-ft.

What is the engine displacement of Lancia Phedra Minivan 2008 2.2 Multijet (170 Hp) Automatic?

2.2 l
2179 cm³
132.97 cu. in.

What is the number of cylinders in 2008 Lancia 2.2 Multijet (170 Hp) Automatic?

4, Inline

What is the drivetrain of Lancia Phedra Minivan 2008 2.2 Multijet (170 Hp) Automatic?

Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle.

What is the length of 2008 Lancia Phedra Minivan?

4750 mm
187.01 in.

What is the width of 2008 Lancia Phedra Minivan?

1863 mm
73.35 in.

What is the kerb weight of 2008 Lancia Phedra 2.2 Multijet (170 Hp) Automatic?

1875-2017 kg
4134 - 4447 lbs.

What is the maximum permissible mass of 2008 Lancia Phedra 2.2 Multijet (170 Hp) Automatic?

2570 kg
5666 lbs.

What is the trunk (boot) capacity of 2008 Lancia Phedra Minivan?

324 - 2948 l
11.4 - 104.1 cu. ft.

What are the number of gears and the gearbox type of 2008 Lancia Phedra 2.2 Multijet (170 Hp) Automatic?

6, automatic transmission

Lancia
- Lancia Phedra
  - Phedra
    - 3.0 i V6 24V (204 Hp)
    - 2.2 Multijet (170 Hp) Automatic
    - 2.2 Multijet (170 Hp)
    - 2.2 JTD (128 Hp)
    - 2.0 Multijet 16v (136 Hp) DPF
    - 2.0 JTD 16v (109 Hp)
    - 2.0 JTD (107 Hp)
    - 2.0 16V (136 Hp) Automatic
    - 2.0 16V (136 Hp)

Compare

General information

Brand

Lancia

Model

Phedra

Generation

Phedra

Modification (Engine)

2.2 Multijet (170 Hp) Automatic

Start of production

April, 2008

End of production

August, 2010

Powertrain Architecture

Internal Combustion engine

Body type

Minivan

Seats

Doors

Looking for Lancia Phedra on the used-car market?

Check its history →

Performance specs

Fuel consumption (economy) - urban

11 l/100 km 21.4 US mpg
25.7 UK mpg
9.1 km/l

Fuel consumption (economy) - extra urban

6.6 l/100 km 35.6 US mpg
42.8 UK mpg
15.2 km/l

Fuel consumption (economy) - combined

8.2 l/100 km 28.7 US mpg
34.4 UK mpg
12.2 km/l

CO₂ emissions

218 g/km

Fuel Type

Diesel

Acceleration 0 - 100 km/h

10.8 sec

Acceleration 0 - 62 mph

10.8 sec

Acceleration 0 - 60 mph (Calculated by Auto-Data.net)

10.3 sec

Maximum speed

197 km/h 122 mph

Emission standard

Euro 4

Weight-to-power ratio

11 kg/Hp, 90.7 Hp/tonne

Weight-to-torque ratio

5.1 kg/Nm, 197.3 Nm/tonne

Engine specs

Power

170 Hp @ 4000 rpm.

Power per litre

78 Hp/l

Torque

370 Nm @ 1500 rpm. 273 lb.-ft. @ 1500 rpm.

Engine layout

Front, Transverse

Engine Model/Code

4HT/4HS

Engine displacement

2179 cm³ 132.97 cu. in.

Number of cylinders

Engine configuration

Inline

Compression ratio

16.5:1

Number of valves per cylinder

Fuel injection system

Diesel Commonrail

Engine aspiration

Turbocharger, Intercooler

Valvetrain

DOHC

Engine oil capacity

4.75 l 5.02 US qt | 4.18 UK qt

Engine oil specification

Coolant

9 l 9.51 US qt | 7.92 UK qt

Engine systems

Particulate filter

Volume and weights

Kerb Weight

1875-2017 kg 4134 - 4447 lbs.

Max. weight

2570 kg 5666 lbs.

Max load

553-695 kg 1219 - 1532 lbs.

Trunk (boot) space - minimum

324 l 11.4 cu. ft.

Trunk (boot) space - maximum

2948 l 104.1 cu. ft.

Fuel tank capacity

80 l 21.13 US gal | 17.6 UK gal

Max. roof load

100 kg 220 lbs.

Permitted trailer load with brakes (12%)

1850 kg 4079 lbs.

Permitted trailer load without brakes

750 kg 1653 lbs.

Permitted towbar download

75 kg 165 lbs.

Dimensions

Length

4750 mm 187.01 in.

Width

1863 mm 73.35 in.

Height

1759 mm 69.25 in.

Wheelbase

2823 mm 111.14 in.

Front track

1570 mm 61.81 in.

Rear (Back) track

1548 mm 60.94 in.

Minimum turning circle (turning diameter)

11.6 m 38.06 ft.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) drives the front wheels of the vehicle.

Drive wheel

Front wheel drive

Number of gears and type of gearbox

6 gears, automatic transmission

Front suspension

Independent, McPherson type with coil spring and anti-roll bar

Rear suspension

Twist-beam axle

Front brakes

Ventilated discs, 310 mm

Rear brakes

Disc, 272 mm

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Hydraulic Steering

Tire size

215/60 R16

Specs of Lancia Phedra 2.2 Multijet (170 Hp) Automatic /2008, 2009, 2010/
