Kia EV9 GT 99.8 kWh (508 Hp) AWD Electric 6 Seat | Technical specs, data, battery, electric range, Dimensions

Key specs

Kia EV9 GT 99.8 kWh (508 Hp) AWD Electric 6 Seat /SUV 2025 - /

What is the body type of Kia EV9?

SUV, 5 Doors, 6 Seats

What is the all-electric range of GT 99.8 kWh (508 Hp) AWD Electric 6 Seat?

505 km
314 mi

What is the electricity consumption of Kia EV9 GT 99.8 kWh (508 Hp) AWD Electric 6 Seat?

22.8 kWh/100 km
36.69 kWh/100 mi
92 MPGe
4.4 km/kWh
2.7 mi/kWh

How fast is 2025 EV9 GT 99.8 kWh (508 Hp) AWD Electric 6 Seat?

220 km/h | 137 mph
0-100 km/h: 4.6 sec
0-60 mph: 4.4 sec

What is the power output of Kia EV9 SUV 2025 GT 99.8 kWh (508 Hp) AWD Electric 6 Seat?

508 Hp, 740 Nm
546 lb.-ft.

What is the drivetrain of Kia EV9 SUV 2025 GT 99.8 kWh (508 Hp) AWD Electric 6 Seat?

All wheel drive (4x4). BEV (Electric Vehicle). One electric motor drives the front wheels, one electric motor drives the rear wheels.

What is the length of 2025 Kia EV9 SUV?

5015 mm
197.44 in.

What is the width of 2025 Kia EV9 SUV?

1980 mm
77.95 in.

What is the kerb weight of 2025 Kia EV9 GT 99.8 kWh (508 Hp) AWD Electric 6 Seat?

2573-2674 kg
5672 - 5895 lbs.

What is the maximum permissible mass of 2025 Kia EV9 GT 99.8 kWh (508 Hp) AWD Electric 6 Seat?

3190 kg
7033 lbs.

What is the trunk (boot) capacity of 2025 Kia EV9 SUV?

333 - 2393 l
11.8 - 84.5 cu. ft.

What is the number of gears in What is the gearbox type of 2025 Kia EV9 GT 99.8 kWh (508 Hp) AWD Electric 6 Seat?

1, automatic transmission

Kia
- Kia EV9
  - EV9
    - GT 99.8 kWh (508 Hp) AWD Electric 7 Seat
    - GT 99.8 kWh (508 Hp) AWD Electric 6 Seat
    - 99.8 kWh (380 Hp) AWD Electric
    - 99.8 kWh (201 Hp) Electric
    - 76.1 kWh (215 Hp) Electric

Compare

General information

Brand

Kia

Model

EV9

Generation

EV9

Modification (Engine)

GT 99.8 kWh (508 Hp) AWD Electric 6 Seat

Start of production

May, 2025 year

Powertrain Architecture

BEV (Electric Vehicle)

Body type

SUV

Seats

Doors

Looking for Kia EV9 on the used-car market?

Check its history →

Performance specs

Fuel Type

Electricity

Acceleration 0 - 100 km/h

4.6 sec

Acceleration 0 - 62 mph

4.6 sec

Acceleration 0 - 60 mph (Calculated by Auto-Data.net)

4.4 sec

Maximum speed

220 km/h 137 mph

Weight-to-power ratio

5.1 kg/Hp, 197.4 Hp/tonne

Weight-to-torque ratio

3.5 kg/Nm, 287.6 Nm/tonne

Electric cars and hybrids specs

Gross battery capacity

99.8 kWh

Battery technology

Lithium nickel manganese cobalt oxides (Li-NMC)

Battery weight

566 kg 1248 lbs.

Battery location

Below the floor

Electric range (WLTP)

505 km 314 mi

Average Energy consumption (WLTP)

22.8 kWh/100 km 36.69 kWh/100 mi
92 MPGe
4.4 km/kWh
2.7 mi/kWh

Charging ports

Electric motor 1

Electric motor location

Front axle, Transverse

Electric motor type

Synchronous

Electric motor 2

Electric motor location

Rear axle, Transverse

Electric motor type

Synchronous

System power

508 Hp

System torque

740 Nm 546 lb.-ft.

Volume and weights

Kerb Weight

2573-2674 kg 5672 - 5895 lbs.

Max. weight

3190 kg 7033 lbs.

Max load

516-617 kg 1138 - 1360 lbs.

Trunk (boot) space - minimum

333-828 l 11.8 - 29.2 cu. ft.

Trunk (boot) space - maximum

2393 l 84.5 cu. ft.

Max. roof load

70 kg 154 lbs.

Permitted trailer load with brakes (12%)

2500 kg 5512 lbs.

Permitted trailer load without brakes

750 kg 1653 lbs.

Permitted towbar download

125 kg 276 lbs.

Dimensions

Length

5015 mm 197.44 in.

Width

1980 mm 77.95 in.

Width with mirrors folded

2047 mm 80.59 in.

Width including mirrors

2263 mm 89.09 in.

Height

1755 mm 69.09 in.

Wheelbase

3100 mm 122.05 in.

Front track

1692 mm 66.61 in.

Rear (Back) track

1703 mm 67.05 in.

Front overhang

875 mm 34.45 in.

Rear overhang

1040 mm 40.94 in.

Ride height (ground clearance)

177 mm 6.97 in.

Minimum turning circle (turning diameter)

12.4 m 40.68 ft.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

One electric motor drives the front wheels, one electric motor drives the rear wheels.

Drive wheel

All wheel drive (4x4)

Number of gears and type of gearbox

1 gears, automatic transmission

Front suspension

Independent, McPherson type

Rear suspension

Independent multi-link suspension

Front brakes

Ventilated discs, 380 mm

Rear brakes

Ventilated discs, 380 mm

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Electric Steering

Tires size

285/45 R21 113V

Wheel rims size

9J x 21 ET58.5

Specs of Kia EV9 GT 99.8 kWh (508 Hp) AWD Electric 6 Seat /2025, 2026/
