Kia Ceed III Sportswagon 1.6 GDi (141 Hp) Plug-in Hybrid DCT | Technical specs, data, fuel consumption, Dimensions

Key specs

Kia Ceed III Sportswagon 1.6 GDi (141 Hp) Plug-in Hybrid DCT /Station wagon (estate) 2020 - 2021/

What is the body type of Kia Ceed III Sportswagon?

Station wagon (estate), 5 Doors, 5 Seats

What is the fuel consumption and economy of Kia Ceed III Sportswagon 1.6 GDi (141 Hp) Plug-in Hybrid DCT?

1.5 l/100 km
156.8 US mpg
188.3 UK mpg
66.7 km/l

How environmentally friendly is Kia Cee'd 1.6 GDi (141 Hp) Plug-in Hybrid DCT?

33 g/km CO₂
Euro 6d

What is the all-electric range of 1.6 GDi (141 Hp) Plug-in Hybrid DCT?

55-60 km
34 - 37 mi

What is the electricity consumption of Kia Ceed III Sportswagon 1.6 GDi (141 Hp) Plug-in Hybrid DCT?

9.3-11.3 kWh/100 km
14.97 - 18.19 kWh/100 mi
225 - 185 MPGe
10.8 - 8.8 km/kWh
6.7 - 5.5 mi/kWh

How fast is 2020 Ceed III Sportswagon 1.6 GDi (141 Hp) Plug-in Hybrid DCT?

171 km/h | 106 mph
0-100 km/h: 10.8 sec
0-60 mph: 10.5 sec

What is the power output of Kia Cee'd Station wagon (estate) 2020 1.6 GDi (141 Hp) Plug-in Hybrid DCT?

141 Hp, 265 Nm
195 lb.-ft.

What is the engine displacement of Kia Cee'd Station wagon (estate) 2020 1.6 GDi (141 Hp) Plug-in Hybrid DCT?

1.6 l
1580 cm³
96.42 cu. in.

What is the number of cylinders in 2020 Kia 1.6 GDi (141 Hp) Plug-in Hybrid DCT?

4, Inline

What is the drivetrain of Kia Ceed III Sportswagon Station wagon (estate) 2020 1.6 GDi (141 Hp) Plug-in Hybrid DCT?

Front wheel drive. PHEV (Plug-in Hybrid Electric Vehicle). The Internal combustion engine (ICE) and electric motor drive the front wheels of the car with the ability to work in full electric or mixed mode.

What is the length of 2020 Kia Cee'd Station wagon (estate)?

4605 mm
181.3 in.

What is the width of 2020 Kia Cee'd Station wagon (estate)?

1800 mm
70.87 in.

What is the kerb weight of 2020 Kia Ceed III Sportswagon 1.6 GDi (141 Hp) Plug-in Hybrid DCT?

1458-1526 kg
3214 - 3364 lbs.

What is the maximum permissible mass of 2020 Kia Ceed III Sportswagon 1.6 GDi (141 Hp) Plug-in Hybrid DCT?

2030 kg
4475 lbs.

What is the trunk (boot) capacity of 2020 Kia Cee'd Station wagon (estate)?

437 - 1506 l
15.4 - 53.2 cu. ft.

What is the number of gears in What is the gearbox type of 2020 Kia Ceed III Sportswagon 1.6 GDi (141 Hp) Plug-in Hybrid DCT?

6, automatic transmission DCT

Kia
- Kia Cee'd
  - Ceed III Sportswagon
    - 1.6 GDi (141 Hp) Plug-in Hybrid DCT
    - 1.6 CRDi (136 Hp) DCT
    - 1.6 CRDi (136 Hp)
    - 1.6 CRDi (115 Hp) Mild Hybrid DCT
    - 1.6 CRDi (115 Hp)
    - 1.5 T-GDI (160 Hp) Mild Hybrid DCT
    - 1.5 T-GDI (160 Hp)
    - 1.4 T-GDI (140 Hp) DCT
    - 1.4 T-GDI (140 Hp)
    - 1.4 (100 Hp)
    - 1.0 T-GDI (120 Hp)
    - 1.0 T-GDI (100 Hp)

Compare

General information

Brand

Kia

Model

Cee'd

Generation

Ceed III Sportswagon

Modification (Engine)

1.6 GDi (141 Hp) Plug-in Hybrid DCT

Start of production

January, 2020 year

End of production

September, 2021 year

Powertrain Architecture

PHEV (Plug-in Hybrid Electric Vehicle)

Body type

Station wagon (estate)

Seats

Doors

Looking for Kia Cee'd on the used-car market?

Check its history →

Performance specs

Combined fuel consumption (WLTP)

1.5 l/100 km 156.8 US mpg
188.3 UK mpg
66.7 km/l

CO₂ emissions (WLTP)

33 g/km

Fuel consumption (economy) - combined (NEDC, WLTP equivalent)

1.1-1.3 l/100 km 213.8 - 180.9 US mpg
256.8 - 217.3 UK mpg
90.9 - 76.9 km/l

CO₂ emissions (NEDC, WLTP equivalent)

28-30 g/km

Fuel Type

Petrol / electricity

Acceleration 0 - 100 km/h

10.8 sec

Acceleration 0 - 62 mph

10.8 sec

Acceleration 0 - 60 mph

10.5 sec

Maximum speed

171 km/h 106 mph

Emission standard

Euro 6d

Weight-to-power ratio

10.3 kg/Hp, 96.7 Hp/tonne

Weight-to-torque ratio

5.5 kg/Nm, 181.8 Nm/tonne

Electric cars and hybrids specs

Gross battery capacity

8.9 kWh

Battery voltage

360 V

Battery technology

Lithium-polymer (LiPo)

Battery weight

117 kg 258 lbs.

Battery location

Under the rear seats
Under the trunk

Electric range (NEDC, WLTP equivalent)

55-60 km 34 - 37 mi

Average Energy consumption (NEDC, WLTP equivalent)

9.3-11.3 kWh/100 km 14.97 - 18.19 kWh/100 mi
225 - 185 MPGe
10.8 - 8.8 km/kWh
6.7 - 5.5 mi/kWh

Max speed (electric)

120 km/h 75 mph

Charging ports

Electric motor 1

Electric motor power

60 Hp @ 1798-2500 rpm.

Electric motor Torque

170 Nm @ 0-1798 rpm. 125 lb.-ft. @ 0-1798 rpm.

Electric motor location

Between the combustion engine and the transmission

System power

141 Hp @ 5700 rpm.

System torque

265 Nm @ 1000-2400 rpm. 195 lb.-ft. @ 1000-2400 rpm.

Internal combustion engine specs

Power

105 Hp @ 5700 rpm.

Power per litre

66.5 Hp/l

Torque

147 Nm @ 4000 rpm. 108 lb.-ft. @ 4000 rpm.

Engine layout

Front, Transverse

Engine Model/Code

Smartstream / G4LE

Engine displacement

1580 cm³ 96.42 cu. in.

Number of cylinders

Engine configuration

Inline

Cylinder Bore

72 mm 2.83 in.

Piston Stroke

97 mm 3.82 in.

Compression ratio

13:1

Number of valves per cylinder

Fuel injection system

Direct injection

Engine aspiration

Naturally aspirated engine

Valvetrain

DOHC, Dual CVVT

Engine oil capacity

3.8 l 4.02 US qt | 3.34 UK qt

Engine oil specification

Coolant

6.8 l 7.19 US qt | 5.98 UK qt

Engine systems

Start & Stop System
Particulate filter

Volume and weights

Kerb Weight

1458-1526 kg 3214 - 3364 lbs.

Max. weight

2030 kg 4475 lbs.

Max load

504-572 kg 1111 - 1261 lbs.

Trunk (boot) space - minimum

437 l 15.4 cu. ft.

Trunk (boot) space - maximum

1506 l 53.2 cu. ft.

Fuel tank capacity

37 l 9.77 US gal | 8.14 UK gal

Max. roof load

80 kg 176 lbs.

Permitted trailer load with brakes (12%)

1300 kg 2866 lbs.

Permitted trailer load without brakes

600 kg 1323 lbs.

Permitted towbar download

75 kg 165 lbs.

Dimensions

Length

4605 mm 181.3 in.

Width

1800 mm 70.87 in.

Width including mirrors

2055 mm 80.91 in.

Height

1465 mm 57.68 in.

Wheelbase

2650 mm 104.33 in.

Front track

1565-1573 mm 61.61 - 61.93 in.

Rear (Back) track

1559-1567 mm 61.38 - 61.69 in.

Front overhang

885 mm 34.84 in.

Rear overhang

1070 mm 42.13 in.

Minimum turning circle (turning diameter)

10.4 m 34.12 ft.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) and electric motor drive the front wheels of the car with the ability to work in full electric or mixed mode.

Drive wheel

Front wheel drive

Number of gears and type of gearbox

6 gears, automatic transmission DCT

Front suspension

Independent, McPherson type

Rear suspension

Independent multi-link suspension, Anti-roll bar

Front brakes

Ventilated discs, 305x25 mm

Rear brakes

Disc, 284x10 mm

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Electric Steering

Tires size

205/55 R16; 225/45 R17

Wheel rims size

6.5J x 16; 7J x 17

Specs of Kia Ceed III Sportswagon 1.6 GDi (141 Hp) Plug-in Hybrid DCT /2020, 2021/
