Jaecoo J7 1.6 TGDI (194 Hp) AWD DCT | Technical specs, data, fuel consumption, Dimensions

Key specs

Jaecoo J7 1.6 TGDI (194 Hp) AWD DCT /SUV (Sport Utility Vehicle) 2023 - /

What is the body type of Jaecoo J7?

SUV (Sport Utility Vehicle), 5 Doors, 5 Seats

What is the fuel consumption and economy of Jaecoo J7 1.6 TGDI (194 Hp) AWD DCT?

7.48 l/100 km
31.4 US mpg
37.8 UK mpg
13.4 km/l

How fast is 2023 J7 1.6 TGDI (194 Hp) AWD DCT?

0-100 km/h: 8 sec
0-60 mph: 7.6 sec

What is the power output of Jaecoo J7 SUV (Sport Utility Vehicle) 2023 1.6 TGDI (194 Hp) AWD DCT?

194 Hp, 290 Nm
214 lb.-ft.

What is the engine displacement of Jaecoo J7 SUV (Sport Utility Vehicle) 2023 1.6 TGDI (194 Hp) AWD DCT?

1.6 l
1598 cm³
97.52 cu. in.

What is the number of cylinders in 2023 Jaecoo 1.6 TGDI (194 Hp) AWD DCT?

4, Inline

What is the drivetrain of Jaecoo J7 SUV (Sport Utility Vehicle) 2023 1.6 TGDI (194 Hp) AWD DCT?

All wheel drive (4x4). Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels permanently, and the rear wheels are driven through an electrically or mechanically operated clutch if necessary.

What is the length of 2023 Jaecoo J7 SUV (Sport Utility Vehicle)?

4500 mm
177.17 in.

What is the width of 2023 Jaecoo J7 SUV (Sport Utility Vehicle)?

1865 mm
73.43 in.

What is the kerb weight of 2023 Jaecoo J7 1.6 TGDI (194 Hp) AWD DCT?

1709 kg
3768 lbs.

What is the maximum permissible mass of 2023 Jaecoo J7 1.6 TGDI (194 Hp) AWD DCT?

2024 kg
4462 lbs.

What is the trunk (boot) capacity of 2023 Jaecoo J7 SUV (Sport Utility Vehicle)?

412 l
14.5 cu. ft.

What are the number of gears and the gearbox type of 2023 Jaecoo J7 1.6 TGDI (194 Hp) AWD DCT?

7, automatic transmission DCT

Jaecoo
- Jaecoo J7
  - J7
    - SHS 1.5 TGDI (347 Hp) Plug-in Hybrid DHT
    - 1.6 TGDI (194 Hp) AWD DCT
    - 1.6 TGDI (147 Hp) DCT
    - 1.6 TGDI (147 Hp) AWD DCT

Compare

General information

Brand

Jaecoo

Model

Generation

Modification (Engine)

1.6 TGDI (194 Hp) AWD DCT

Start of production

2023

Powertrain Architecture

Internal Combustion engine

Body type

SUV (Sport Utility Vehicle)

Seats

Doors

Looking for Jaecoo J7 on the used-car market?

Check its history →

Performance specs

Combined fuel consumption (WLTP)

7.48 l/100 km 31.4 US mpg
37.8 UK mpg
13.4 km/l

Fuel Type

Petrol (Gasoline)

Acceleration 0 - 100 km/h

8 sec

Acceleration 0 - 62 mph

8 sec

Acceleration 0 - 60 mph (Calculated by Auto-Data.net)

7.6 sec

Weight-to-power ratio

8.8 kg/Hp, 113.5 Hp/tonne

Weight-to-torque ratio

5.9 kg/Nm, 169.7 Nm/tonne

Engine specs

Power

194 Hp

Power per litre

121.4 Hp/l

Torque

290 Nm 214 lb.-ft.

Engine layout

Front, Transverse

Engine Model/Code

SQRF4J16C

Engine displacement

1598 cm³ 97.52 cu. in.

Number of cylinders

Engine configuration

Inline

Cylinder Bore

77 mm 3.03 in.

Piston Stroke

85.8 mm 3.38 in.

Number of valves per cylinder

Fuel injection system

Direct injection

Engine aspiration

Turbocharger, Intercooler

Valvetrain

DOHC

Engine systems

Start & Stop System

Volume and weights

Kerb Weight

1709 kg 3768 lbs.

Max. weight

2024 kg 4462 lbs.

Max load

315 kg 694 lbs.

Trunk (boot) space - minimum

412 l 14.5 cu. ft.

Max. roof load

75 kg 165 lbs.

Permitted trailer load with brakes (12%)

1300 kg 2866 lbs.

Dimensions

Length

4500 mm 177.17 in.

Width

1865 mm 73.43 in.

Height

1680 mm 66.14 in.

Wheelbase

2672 mm 105.2 in.

Front track

1582 mm 62.28 in.

Rear (Back) track

1604 mm 63.15 in.

Front overhang

906 mm 35.67 in.

Rear overhang

922 mm 36.3 in.

Ride height (ground clearance)

200 mm 7.87 in.

Minimum turning circle (turning diameter)

11 m 36.09 ft.

Approach angle

21°

Departure angle

29°

Wading depth

600 mm 23.62 in.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) drives the front wheels permanently, and the rear wheels are driven through an electrically or mechanically operated clutch if necessary.

Drive wheel

All wheel drive (4x4)

Number of gears and type of gearbox

7 gears, automatic transmission DCT

Front suspension

Independent, McPherson type with coil spring and anti-roll bar

Rear suspension

Independent multi-link spring suspension with anti-roll bar

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Electric Steering

Tire size

235/50 R19

Wheel rim size

7J x 19

Specs of Jaecoo J7 1.6 TGDI (194 Hp) AWD DCT /2023, 2024, 2025, 2026/
