JAC T9 Double Cab 2.0 TGDI (231 Hp) 4WD Automatic | Technical specs, data, fuel consumption, Dimensions

Key specs

JAC T9 Double Cab 2.0 TGDI (231 Hp) 4WD Automatic /Pick-up 2023 - /

What is the body type of JAC T9 Double Cab?

Pick-up, 4 Doors, 5 Seats

How fast is 2023 T9 Double Cab 2.0 TGDI (231 Hp) 4WD Automatic?

170 km/h | 106 mph

What is the power output of JAC T9 Pick-up 2023 2.0 TGDI (231 Hp) 4WD Automatic?

231 Hp, 380 Nm
280 lb.-ft.

What is the engine displacement of JAC T9 Pick-up 2023 2.0 TGDI (231 Hp) 4WD Automatic?

2.0 l
1998 cm³
121.93 cu. in.

What is the number of cylinders in 2023 JAC 2.0 TGDI (231 Hp) 4WD Automatic?

4, Inline

What is the drivetrain of JAC T9 Double Cab Pick-up 2023 2.0 TGDI (231 Hp) 4WD Automatic?

All wheel drive (4x4). Internal Combustion engine. The Internal combustion engine (ICE) drives the rear wheels permanently, and the front wheels are driven through an electrically or mechanically operated clutch if necessary.

What is the length of 2023 JAC T9 Pick-up?

5330 mm
209.84 in.

What is the width of 2023 JAC T9 Pick-up?

1965 mm
77.36 in.

What is the kerb weight of 2023 JAC T9 Double Cab 2.0 TGDI (231 Hp) 4WD Automatic?

2055 kg
4530 lbs.

What is the maximum permissible mass of 2023 JAC T9 Double Cab 2.0 TGDI (231 Hp) 4WD Automatic?

3100 kg
6834 lbs.

What are the number of gears and the gearbox type of 2023 JAC T9 Double Cab 2.0 TGDI (231 Hp) 4WD Automatic?

8, automatic transmission

JAC
- JAC T9
  - T9 Double Cab
    - EV 88.02 kWh (299 Hp) 4WD
    - 2.0 TGDI (231 Hp) Automatic
    - 2.0 TGDI (231 Hp) 4WD Automatic
    - 2.0 CTI (170 Hp) Automatic
    - 2.0 CTI (170 Hp) 4WD Automatic

Compare

General information

Brand

JAC

Model

Generation

T9 Double Cab

Modification (Engine)

2.0 TGDI (231 Hp) 4WD Automatic

Start of production

2023

Powertrain Architecture

Internal Combustion engine

Body type

Pick-up

Seats

Doors

Looking for JAC T9 on the used-car market?

Check its history →

Performance specs

Fuel Type

Petrol (Gasoline)

Maximum speed

170 km/h 106 mph

Weight-to-power ratio

8.9 kg/Hp, 112.4 Hp/tonne

Weight-to-torque ratio

5.4 kg/Nm, 184.9 Nm/tonne

Engine specs

Power

231 Hp @ 5500 rpm.

Power per litre

115.6 Hp/l

Torque

380 Nm @ 1900-3300 rpm. 280 lb.-ft. @ 1900-3300 rpm.

Engine layout

Front, Longitudinal

Engine Model/Code

N20TG

Engine displacement

1998 cm³ 121.93 cu. in.

Number of cylinders

Engine configuration

Inline

Number of valves per cylinder

Fuel injection system

Direct injection

Engine aspiration

Turbocharger, Intercooler

Valvetrain

DOHC

Engine systems

Start & Stop System

Volume and weights

Kerb Weight

2055 kg 4530 lbs.

Max. weight

3100 kg 6834 lbs.

Max load

1045 kg 2304 lbs.

Fuel tank capacity

76 l 20.08 US gal | 16.72 UK gal

Dimensions

Length

5330 mm 209.84 in.

Width

1965 mm 77.36 in.

Width with mirrors folded

1983 mm 78.07 in.

Width including mirrors

2186 mm 86.06 in.

Height

1920 mm 75.59 in.

Wheelbase

3110 mm 122.44 in.

Front track

1610 mm 63.39 in.

Rear (Back) track

1610 mm 63.39 in.

Front overhang

945 mm 37.2 in.

Rear overhang

1275 mm 50.2 in.

Ride height (ground clearance)

210 mm 8.27 in.

Minimum turning circle (turning diameter)

12.4 m 40.68 ft.

Approach angle

27°

Departure angle

23°

Climb angle

30°

Wading depth

650 mm 25.59 in.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) drives the rear wheels permanently, and the front wheels are driven through an electrically or mechanically operated clutch if necessary.

Drive wheel

All wheel drive (4x4)

Number of gears and type of gearbox

8 gears, automatic transmission

Front suspension

Double wishbone, Independent coil spring, Anti-roll bar

Rear suspension

Rigid axle suspension, Leaf spring

Front brakes

Ventilated discs

Rear brakes

Disc

Assisting systems

ABS (Anti-lock braking system)

Power steering

Electric Steering

Tire size

265/60 R18

Wheel rim size

8J x 18
