Hyundai Sonata II (Y2) 2.0 (102 Hp) CAT | Technical specs, data, fuel consumption, Dimensions

Key specs

Hyundai Sonata II (Y2) 2.0 (102 Hp) CAT /Sedan 1988 - 1991/

What is the body type of Hyundai Sonata II (Y2)?

Sedan, 4 Doors, 5 Seats

What is the fuel consumption and economy of Hyundai Sonata II (Y2) 2.0 (102 Hp) CAT?

8.6 l/100 km
27.4 US mpg
32.8 UK mpg
11.6 km/l

How fast is 1988 Sonata II (Y2) 2.0 (102 Hp) CAT?

185 km/h | 115 mph

What is the power output of Hyundai Sonata Sedan 1988 2.0 (102 Hp) CAT?

102 Hp, 159 Nm
117 lb.-ft.

What is the engine displacement of Hyundai Sonata Sedan 1988 2.0 (102 Hp) CAT?

2.0 l
1997 cm³
121.86 cu. in.

What is the number of cylinders in 1988 Hyundai 2.0 (102 Hp) CAT?

4, Inline

What is the drivetrain of Hyundai Sonata II (Y2) Sedan 1988 2.0 (102 Hp) CAT?

Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle.

What is the length of 1988 Hyundai Sonata Sedan?

4680 mm
184.25 in.

What is the width of 1988 Hyundai Sonata Sedan?

1750 mm
68.9 in.

What is the trunk (boot) capacity of 1988 Hyundai Sonata Sedan?

473 l
16.7 cu. ft.

What are the number of gears and the gearbox type of 1988 Hyundai Sonata II (Y2) 2.0 (102 Hp) CAT?

5, manual transmission

Hyundai
- Hyundai Sonata
  - Sonata II (Y2)

Compare

General information

Brand

Hyundai

Model

Sonata

Generation

Sonata II (Y2)

Modification (Engine)

2.0 (102 Hp) CAT

Start of production

1988

End of production

1991

Powertrain Architecture

Internal Combustion engine

Body type

Sedan

Seats

Doors

Looking for Hyundai Sonata on the used-car market?

Check its history →

Performance specs

Fuel consumption (economy) - combined

8.6 l/100 km 27.4 US mpg
32.8 UK mpg
11.6 km/l

Fuel Type

Petrol (Gasoline)

Maximum speed

185 km/h 115 mph

Engine specs

Power

102 Hp @ 5000 rpm.

Power per litre

51.1 Hp/l

Torque

159 Nm @ 4000 rpm. 117 lb.-ft. @ 4000 rpm.

Engine layout

Front, Transverse

Engine displacement

1997 cm³ 121.86 cu. in.

Number of cylinders

Engine configuration

Inline

Cylinder Bore

85 mm 3.35 in.

Piston Stroke

88 mm 3.46 in.

Compression ratio

8.6:1

Number of valves per cylinder

Fuel injection system

Multi-port manifold injection

Engine aspiration

Naturally aspirated engine

Valvetrain

OHC

Volume and weights

Trunk (boot) space - minimum

473 l 16.7 cu. ft.

Fuel tank capacity

60 l 15.85 US gal | 13.2 UK gal

Dimensions

Length

4680 mm 184.25 in.

Width

1750 mm 68.9 in.

Height

1410 mm 55.51 in.

Wheelbase

2650 mm 104.33 in.

Front track

1461 mm 57.52 in.

Rear (Back) track

1440 mm 56.69 in.

Drivetrain, brakes and suspension specs

Drivetrain Architecture

The Internal combustion engine (ICE) drives the front wheels of the vehicle.

Drive wheel

Front wheel drive

Number of gears and type of gearbox

5 gears, manual transmission

Front suspension

Independent, McPherson type with coil spring and anti-roll bar

Rear suspension

Coil spring

Front brakes

Ventilated discs

Rear brakes

Disc

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Hydraulic Steering

Tire size

185/70 R14

Wheel rim size

Specs of Hyundai Sonata II (Y2) 2.0 (102 Hp) CAT /1988, 1989, 1990, 1991/
