Hongqi E-QM5 54 kWh (190 Hp) | Technical specs, data, battery, electric range, Dimensions

Key specs

Hongqi E-QM5 54 kWh (190 Hp) /Sedan 2022 - 2025/

What is the body type of Hongqi E-QM5?

Sedan, 4 Doors, 4-5 Seats

What is the all-electric range of 54 kWh (190 Hp)?

431-445 km
268 - 277 mi

What is the electricity consumption of Hongqi E-QM5 54 kWh (190 Hp)?

13.5 kWh/100 km
21.73 kWh/100 mi
155 MPGe
7.4 km/kWh
4.6 mi/kWh

How fast is 2022 E-QM5 54 kWh (190 Hp)?

160 km/h | 99 mph

What is the power output of Hongqi E-QM5 Sedan 2022 54 kWh (190 Hp)?

190 Hp, 320 Nm
236 lb.-ft.

What is the drivetrain of Hongqi E-QM5 Sedan 2022 54 kWh (190 Hp)?

Front wheel drive. BEV (Electric Vehicle). One electric motor drives the front wheels.

What is the length of 2022 Hongqi E-QM5 Sedan?

5040 mm
198.43 in.

What is the width of 2022 Hongqi E-QM5 Sedan?

1910 mm
75.2 in.

What is the kerb weight of 2022 Hongqi E-QM5 54 kWh (190 Hp)?

1810 kg
3990 lbs.

What is the maximum permissible mass of 2022 Hongqi E-QM5 54 kWh (190 Hp)?

2260 kg
4982 lbs.

What is the trunk (boot) capacity of 2022 Hongqi E-QM5 Sedan?

433 l
15.3 cu. ft.

What are the number of gears and the gearbox type of 2022 Hongqi E-QM5 54 kWh (190 Hp)?

1, automatic transmission

Hongqi
- Hongqi E-QM5
  - E-QM5
    - 82 kWh (190 Hp)
    - 74.9 kWh (190 Hp)
    - 56 kWh (136 Hp) Battery Swap
    - 54 kWh (190 Hp)
    - 54 kWh (136 Hp)

Compare

General information

Brand

Hongqi

Model

E-QM5

Generation

E-QM5

Modification (Engine)

54 kWh (190 Hp)

Start of production

March, 2022

End of production

2025

Powertrain Architecture

BEV (Electric Vehicle)

Body type

Sedan

Seats

4-5

Doors

Looking for Hongqi E-QM5 on the used-car market?

Check its history →

Performance specs

Fuel Type

Electricity

Maximum speed

160 km/h 99 mph

Weight-to-power ratio

9.5 kg/Hp, 105 Hp/tonne

Weight-to-torque ratio

5.7 kg/Nm, 176.8 Nm/tonne

Electric and hybrid car specs

Gross battery capacity

54 kWh

Battery technology

Lithium iron phosphate (LiFePO₄)

Battery location

Below the floor

Electric range

431-445 km 268 - 277 mi

Average Energy consumption

13.5 kWh/100 km 21.73 kWh/100 mi
155 MPGe
7.4 km/kWh
4.6 mi/kWh

Charging ports

Charging times

Electric motor 1

Electric motor power

190 Hp

Electric motor Torque

320 Nm 236 lb.-ft.

Electric motor model/code

CAM210PT5

Electric motor location

Front axle, Transverse

Electric motor type

Synchronous

System power

190 Hp

System torque

320 Nm 236 lb.-ft.

Volume and weights

Kerb Weight

1810 kg 3990 lbs.

Max. weight

2260 kg 4982 lbs.

Max load

450 kg 992 lbs.

Trunk (boot) space - minimum

433 l 15.3 cu. ft.

Dimensions

Length

5040 mm 198.43 in.

Width

1910 mm 75.2 in.

Height

1569 mm 61.77 in.

Wheelbase

2990 mm 117.72 in.

Front track

1630 mm 64.17 in.

Rear (Back) track

1630 mm 64.17 in.

Minimum turning circle (turning diameter)

11.76 m 38.58 ft.

Approach angle

14°

Departure angle

18°

Drivetrain, brakes and suspension specs

Drivetrain Architecture

One electric motor drives the front wheels.

Drive wheel

Front wheel drive

Number of gears and type of gearbox

1 gears, automatic transmission

Front suspension

Independent, McPherson type with coil spring and anti-roll bar

Rear suspension

Independent multi-link spring suspension with anti-roll bar

Front brakes

Ventilated discs

Rear brakes

Disc

Assisting systems

ABS (Anti-lock braking system)

Steering type

Steering rack and pinion

Power steering

Electric Steering

Tire size

235/50 R18

Wheel rim size
